Note: It is highly recommended to change the default
password. Make sure the new password is noted and
kept in a secure place.
QS Rule
What To Do Next
1. Connect IT equipment to the outlet(s) on the PRO3X.
2. Using the web browser:
(on page 1).
Interface
3. Choose Device Settings > Date/Time to configure the PRO3X
with the proper date and time or synchronize it with an NTP
server. The PRO3X device's time must be in sync with the LDAP
server to use LDAP authentication.
Note: If you are using Sunbird's Power IQ to manage the
PRO3X, you must configure Power IQ and the PRO3X to
have the same date/time or NTP settings.
4. To change network settings, choose Device Settings > Network.
Tip: You can enable both wired and wireless networking so
that the PRO3X can be accessed via either a wired or
wireless IP address.
5. The outlet control state is defaulted to ON so when the unit
boots the outlets will sequence ON.
6. Use the menu located on the left to configure user profiles,
privileges, security, or outlet thresholds.
QS Rule
Appendix A: Configuration via a Mobile Device or
PDView
An iOS or Android mobile device, such as a smartphone or tablet,
can function as a local display of PRO3X. Note that the Android
device must support USB "On-The-Go" (OTG), or this function
does not work.
Step 1: Download the "PDView" App
PDView", a free app for both Server Technology and Raritan PDUs,
is required for the mobile device to function as a local display.
To download PDView:
1. Visit either Apple App or Google Play Store.
https://itunes.apple.com/app/raritan-pdview/id780382738
Server Technology PRO3X Network Setup Guide
v01 QSG-PRO3X
Step 2: Log in to the PRO3X Web
https://play.google.com/store/apps/details?id=com.raritan.
android.pdview
2. Install PDView.
Step 2: Connect the Mobile Device to PRO3X
The USB cable and USB port to connect are determined by your
mobile operating system.
To connect your mobile device to PRO3X:
1. Get an appropriate USB cable for your mobile device.
iOS: Use the regular USB cable shipped with your iOS
mobile device.
Android: Use an USB OTG adapter cable.
2. Connect the mobile device to the appropriate USB port on the
PRO3X.
iOS: USB-A port.
Android: USB-B port
Step 3: Launch PDView
You can access the PRO3X web interface via PDView to view
or change the settings.
To access the PRO3X web interface:
1. Launch PDView on your mobile device.
2. Wait until PDView detects the connected PRO3X and shows
the word "Connected".
3. Enter default admn/admn credentials
