- Page 1 ITEM NO HO925200TX “FRANCION” MISSION DESK For assistance with assembly contact: Assembly Instructions Southern Enterprises, Inc. Customer Service 1-800-633-5096 service@seidal.com wwww.seidal.com...
- Page 2 “FRANCION” MISSION DESK Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage.Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below. You may receive extra hardware with your unit.
- Page 3 “FRANCION” MISSION DESK Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage.Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below. You may receive extra hardware with your unit.
- Page 4 “FRANCION” MISSION DESK Assembly Instructions Assembly Instructions: Wood may scratch easily, Be careful when assembling. Do not scratch. Step 1 Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated front page.
- Page 5 “FRANCION” MISSION DESK Assembly Instructions Connect the Side Frame (E),Back Frame (C) and Drawer Frame (D) with 8pcs Bolts (1). Figure 4 Assemble the drawer (F/G) by using 2pcs Hinge (9). Tighten the hinge with 12pcs Screws (8). Figure 5 Attach the Plastic Drawer Stopper (10) to the Keyboard Drawer (F) with 6pcs Wood Screws (7).
- Page 6 “FRANCION” MISSION DESK Assembly Instructions Put the Keyboard Drawer to the right position. Figure 7 Attach 2pcs Plastic Drawer Stoppers the Keyboard Drawer (F) (11) to with 4pcs Wood Screws (7) as shown. Figure 8 Connect the Left and Right Side Panel (I,J),the Bottom Panel (H) with 4pcs Wood Dowels(5),2pcs Cam Bolts(14) and 2pcs Cam...
- Page 7 “FRANCION” MISSION DESK Assembly Instructions Connect the hutch divider (L,K) with 8pcs Wood Dowels (5) 2pcs Cam Bolts (14),2pcs Cam Locks (15). Figure 10 Put the Hutch Back Panel (M) to the right position. Figure 11 Connect the Hutch Top Panel with 12pcs Wood Panels (5),4pcs Cam Bolts (14) and 4pcs Cam Locks(15)
- Page 8 “FRANCION” MISSION DESK Assembly Instructions Attach the unit assembled at STEP12 to the Desk Top (A) with 2pcs Bolt (2). Figure 13 Fix the Handle (13) to the Hutch Drawer Front (O) with 2pcs Bolt (3) as figure shown. Connect the Hutch Drawer Sides (P) ,Drawer backs (Q), Drawer bottoms (R) and Front Drawer Panel(O) with 8pcs Wood Screws...
-
Page 9: Parts Replacement Form
Parts will be sent if available from SEI We'd love to hear from you! Email us photos of our products in your home at sei@seidal.com and we might feature it on our site or use it to model one of our inspirational photos.
