- Page 1 HO872400TX WRITING DESK -MODERN EXOTIC For assistance with assembly contact: Southern Enterprises Inc. Assembly Instruction Customer Service 1-800-633-5096 service@seidal.com www.seidal.com Page 1...
-
Page 2: Parts List
HO872400TX WRITING DESK -MODERN EXOTIC Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. - Page 3 2pcs 2pcs Top Drawer Left Side Leg Across Panel Top Drawer Front Panel Panel 2pcs 2pcs 2pcs Top Drawer Right Side Panel Top Drawer Back Panel Top Drawer Shelf 2pcs 2pcs 2pcs Bottom Drawer Left Side Bottom Drawer Right Side Bottom Drawer Front Panel Panel Panel...
- Page 4 14pcs 4pcs Bolt 1/4”x 1-1/4” Allen Wrench 1/4” Bolt 5/16”x 1-3/4” 32pcs 4pcs Allen Wrench 5/16” Screw 5/32”x1” handle 8pcs 4pcs 16pcs Bolts 5/32”x 3/4” Aluminum rail Spring Washer 1/4” 10pcs 2pcs 2pcs Flat washer 1/4”x3/4” T nut 1/4” Bolt 1/4”x 2-1/4” 4pcs 4pcs Spring Washer 5/16”...
- Page 5 HO872400TX WRITING DESK -MODERN EXOTIC Assembly Instructions Step 1: PLEASE DO NOT OVER-TIGHTEN CAMBOLTS. PLEASE STOP WHEN YOU FEEL TIGHT Attached Side panel (D/E) to Across Panel (F/G) by using 6pcs bolt (4), and 6pcs Lock Washer (12) , 6pcs wood Dowel(3) Wrench(5) as shown.
- Page 6 ( 1) ( 2) Step 3: Attached Side panel (B/D) to Back Panel (I) and Across Panel(H) Bottom Panel(J) by "Please do not over tighten cambolts. Please stop using 4pcs bolt (4), and 4pcs when you feel tight" Lock Washer (12) 4pcs Flat washer (13) 4pcs wood Dowel(3) Wrench(5) as shown.
- Page 7 Step 5: Attached Left /Right foot (L/K) to Across Panel(M) Bottom Panel(J) by using 2pcs bolt (15), and 2pcs Lock Washer (12) 2pcs Flat washer (13) 2pcs washer (14) 2pcs wood Dowel(3)Wrench(5) as shown. Attached Left /Right foot (L/K) to Bottom Panel(J) by using 4pcs bolt (6), and 4pcs Lock Washer (16) 4pcs Flat washer (17) 4pcs wood Dowel(3)
- Page 8 Step 7: Assemble the Medium drawer (N/O/P/Q/R) by using 8pcs Wood Screws (8). Fix the Handle (9) to the Drawer Front Panel (N) with 2pcs Bolt (10) by using the Screwdriver. Step8: Insert the drawer as shown. Now you production is ready to use.
- Page 9 Parts Replacement Form Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
- Page 10 representative for issues involving damages or replacement parts. Please ask for technical assistance representative for any issues with product and assembly/construction. Please contact the retailer that you purchased from for returns. Customer Service 1-800-633-5096 service@seidal.com Southern Enterprises, Inc. 600 Freeport Parkway, Suite 200...
