Summary of Contents for CAME A 3024
- Page 1 1 19 D U92E N AUTOMATION FOR SWING GATES INSTALLATION MANUAL A 3024 - A 3124 A 5024 - A 5124 English...
- Page 2 • Use this product only for the specifi c purpose for which it is designed. Any Special instructions and recommendations for everyone other use is therefore improper and dangerous. CAME S.p.A. is not liable for • Keep away from the hinges and any moving mechanical parts • Stay out any damage due to improper, erroneous and unreasonable use •...
-
Page 3: Legend Of Symbols
3 Reference Standards The company: CAME S.p.A. is ISO 9001 quality certified; is has also obtained the ISO 14001 environmental safeguarding certification. Came engineers and manufactures all of its products in Italy. This product complies with the following standards: see declaration of compliance. -
Page 4: Overall Dimensions
4.4 Overall dimensions Measurements in mm A 3024 - A 3124 Gate leaf width Gate leaf weight 2.00 2.50 3.00 We suggest you always fit an electrolock onto swing gates for a more Travel reliable closure. Fitting electrolocks onto reversible operators makes for anti-intrusion security. -
Page 5: Standard Installation
5.2 Tools and materials Make sure you have all the tools and materials you will need for the installation at hand to work in total safety and compliance with the current standards and regulations. The following figure illustrates the minimum equipment needed by the installer. 5.3 Cable list and minimum thickness Length of cable Length of cable... - Page 6 5.5 Mounting The following are just example applications, given that the space for securing the operator and accessories may vary depending on the dimensions. It is thus up to the installer to choose the most suitable solution. Tab. 3 Pillar Gate leaves up to 3 m Hinge C max...
- Page 7 Unscrew the two securing screws and remove the carter. Carter Stem Unscrew the two securing screws and remove the stem. M8 self-locking nut Endless screw Begin mounting the gearmotor to the two brackets. M8x10 M8x50 N.B.: we suggest lubricating (using neutral grease) the endless screw and the bushing upon installation. 5.6 Electrical connections to the ZL19 control panel Motor terminal block Control panel terminal block...
- Page 8 5.7 Adjusting the deceleration microswitches for opening and closure Gate jamb Deceleration microswitch for closure Support plate Worm-gear microswitch Cable holder Microswitch unit for Microswitch actuation slowing and stopping runner during opening Fixing screws screw-nut Screw-nut DURING OPENING: DURING CLOSURE: Release the gearmotor and move the wing to the maximum Move the wing to no closer than 100 mm from the end stop desired open position, unscrew the fi...
- Page 9 5.8 Adjusting the STOP microswitch for the opening movement Microswitch actuation runner Support plate microswitch Worm-gear Screw-nut Fixing screw Microswitch unit Release the gearmotor and move the door to the maximum desired open position.Loosen the fi xing screws of the microswitch unit.
-
Page 10: Manutenzione Periodica
5.10 Application for outside openings TAB. A A 3024 - A 3124 A 5024 - A 5124 130 mm 200 mm 130 mm 200 mm 720 mm 920 mm Outside Insoide Supplementary bracket - Measure the lenght of “A” and “B”... -
Page 11: Extraordinary Maintenance
7.2 Trouble shooting MALFUNCTIONS POSSIBLE CAUSES CHECK AND REMEDIES The gate will not open • There is no power • Check that the power is up nor close • The gearmotor is released • Call assistance • The transmitter’s batteries are run down •... - Page 12 CAME S.p.A. employs a UNI EN ISO 14001 certified and compliant environmental protection system at its plants, to ensure that environmental safeguarding. We ask you to keep protecting the environment, as CAME deems it to be one of the fundamental points of its market operations strategies, by simply following these brief guidelines when disposing: DISPOSING THE PACKING MATERIALS The packing components (cardboard, plastic, etc.) are solid urban waste and may be disposed of without any particular difficulty, by...
