Milesight-Troubleshooting Hardware Reset of NVR...
Page 2
Update 2019.1.7 The following will introduce how to reset NVR via hardware. 1. Position of Reset Button Series-1000: 100x/1009-UT: There is a hole on the back, use a pin or something like that to push the button deeper inside the hole. 1009-UPT/UNT: Slide and open the shell, an orange button on the inside like the figure shown below.
Page 3
Series-5000: 50XX: Slide and open the right panel, a black button on the inside like the figure shown below. 50XX-UH/UT: Slide and open the panel, a black button on the inside like the figure shown below.
Page 4
5016-UPT: Slide and open the panel, a black button on the inside like the figure shown below. Series-7000: 70XX: Slide and open the front panel, a reset button on the left side of the front panel. 70XX-UH: Slide and open the panel, a black button on the inside like the figure shown below.
Page 5
7032-UPH: Slide and open the panel, a black button on the inside like the figure shown below. Series-8000: 80XX: Open the front panel, a hole on the right side of the front panel like the figure shown below, use a pin or something like that to push the button deeper inside the hole.
Page 6
2. Reset Steps For NVRs whose software version is before 7x.9.0.2-r3, or 61.x.x.xx/ 30.x.x.xx/ 1.x.x.xx/ 2.x.x.xx, please refer to the steps below: Step1: Turn off the power; Step2: Press the reset button; Step3: Keep pressing the reset button and power on the NVR at the same time; Step4: You will hear several short “beep”...
