- Page 1 VE0601-A/VE0602-A User Manual All software & files can be downloaded from https://www.milesight.com/support/download/ Milesight www.milesight.com...
- Page 2 Table of Contents 1.Packing List……………………………………………………………………........2.Hardware Overview……………………………………………………………………......3.Interfaces…………………………………………………………………........4.Installation…………………………………………............…… 5.Device Connection Topology……………………...………...........… 6.Ready to Start……………………...………...........…....... www.milesight.com...
- Page 3 4-Power LED 7-4*2.5Gbps LAN 2. Hardware Introduction 2-DP Port 5-HDMI Port 8-Audio 3-2*USB 3.0 6-CLRCMOS Button 9-Power 4.Installation Step1: Using a cross screwdriver to remove the screws at the rear panel in an anticlockwise direction. Power Button 440mm www.milesight.com www.milesight.com...
- Page 4 Using the screwdriver to remove two screws in the middle of HDD bracket in an anticlockwise direction. Step5: Secure the HDD with 4 screws. Don’t screw tight and leave about 1mm distance at the side of each screw nut. As the enlarged drawing shows: www.milesight.com www.milesight.com...
- Page 5 Then connect the power cable and data cable to each HDD. with screwdriver. Step7: Repeat the above steps to install HDD in the bracket. Remember to check if you have screwed tight. Step9: Pull down the upper casing and slide it to the left. www.milesight.com www.milesight.com...
- Page 6 Step10: 5.Device Connection Topology 6. Ready to Start When Machine is connected to a power source, it will power up automatical- ly(Power up recovery is enabled by default). www.milesight.com...
