Lennox Signature Shoreline Installation Instructions

INSTALLATION INSTRUCTIONS FOR INSTALLING REFRACTORY BRICK PANEL
KITS FOR USE wITH THE SHORELINE™ GAS FIREPLACE INSERT
KIT CONTENTS (See Figure 2):
Please ensure that all these parts are in the packaging.
1 ea. Front Bottom Panel ( A )
1 ea. Rear Panel (B)
1 ea. Left Side Panel (C)
1 ea. Right Side Panel (D)
1 ea. Top Panel (E)
2 ea. Mounting Brackets (F) (
1 ea. Instruction Sheet
f i r e - p a r t s . c o m
Shoreline Refractory Brick Panel Kits
Cat. No. Model
H7987 SHR-BRK-STD
H7988 SHR-BRK-RED
H7989 SHR-BRK-ARCHSTONE
IMPORTANT NOTE: A refractory brick panel kit is required for proper
operation (sold separately). Never operate this appliance without
all the refractory brick panels properly installed.
TOOLS NEEDED
5/32" Allen Wrench
Standard
Brick
Red
Brick
Architectural
Stone
Figure 1
see note in Figure 2)
Description
Brick Panel Set, Tan
Brick Panel Set, Red
Brick Panel Set, Architectural
(shown)
NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE
775,263M
Rev. A, 06/2010
C
Figure 2
GENERAL INFORMATION
All of these parts may scratch and bend, great care should be used
in handling them.
If you encounter any problems, need clarification of these instructions
or are not qualified to properly install this kit, contact you local distribu-
tor or dealer.
Read this instruction sheet in its entirety before beginning the installation.
ALL wARNINGS AND PRECAUTIONS IN THE INSTALLATION AND
OPERATION MANUAL PROVIDED wITH THE APPLIANCE APPLY TO
THESE INSTRUCTIONS.
TURN OFF THE FIREPLACE INSERT AND ALLOw IT TO COMPLETELY
COOL BEFORE PROCEEDING.
Before you install the refractory brick panels and log
set, the insert should be installed in the fireplace, the
venting attached, the gas line connected and tested
for leaks and the initial burner operation checked.
