WELCOME
The vehicle presents you a challenge to master the machine, a challenge to adventure. You
ride through the wind, linked to the road by a vehicle that responds to your commands as
no other does. Unlike an automobile, there is no metal cage around you. Like an air plane,
a pre-ride inspection and regular maintenance are essential to your safety. Your reward is
freedom.
To meet the challenges safely, and to enjoy the adventure fully, you should become
thoroughly familiar with this owner's manual BEFORE YOU RIDE THE VEHICLE.
As you read this manual, you will find information that is preceded by a
symbol.
This information is intended to help you avoid damage to your vehicle, other property, or
the environment.
When service is required, remember that your Honda dealer knows your vehicle. If you
have the required mechanical "know-how" and tools, your dealer can supply you an official
Honda shop manual on paid basis to help you perform many maintenance and repair tasks.
Accessories shown in the illustration are not part of the standard equipment.
For any query or assistance, please call Customer Care No.:
1800 103 3434 (Toll free)
Pleasant riding, and thank you for choosing a Honda!
● The specifications may vary with each locale.
© 2019 Honda Motor Co., Ltd.
CD110 Dream DX
Honda Motorcycle & Scooter India Pvt. Ltd.
Advertisement
Table of Contents
Related Manuals for Honda Dream DX CD110
Summary of Contents for Honda Dream DX CD110
- Page 1 “know-how” and tools, your dealer can supply you an official Honda shop manual on paid basis to help you perform many maintenance and repair tasks. Accessories shown in the illustration are not part of the standard equipment.
- Page 2 All information in this publication is based on the latest production information available at the time of approval for printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
-
Page 3: Table Of Contents
(Important information to operate this Storage Compartment & First Aid Kit --- 27 vehicle) Headlight Aim Vertical Adjustment ----- 27 Brakes ------------------------------------ 12 Rear Carrier ------------------------------ 27 Clutch ------------------------------------- 15 Fuel --------------------------------------- 16 CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 4 Removal From Storage ------------------ 66 Engine Oil -------------------------------- 38 SPECIFICATIONS ---------------------67 Crankcase Breather ---------------------- 40 WARRANTY POLICY ------------------71 Spark Plug -------------------------------- 41 Valve Clearance -------------------------- 42 Idle Speed -------------------------------- 44 CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 5: Catalytic Converter
• Keep the engine tuned-up. • Have your vehicle diagnosed and replaced if it is misfiring, backfiring stalling or otherwise not running properly. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 6: A Few Words About Safety
● Safety Section – such as vehicle Safety. ● Instructions – how to use this vehicle correctly and safely. This entire manual is filled with important safety information–please read it carefully. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 7: Vehicle Safety
Never gloves, and other protective gear (page 4). exceed load limits, and only use accessories that have been approved by Honda for this vehicle. See page 6 for more details. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 8: Protective Apparel
Be sure you and your pillion rider always avoid loose clothes that could get caught wear a helmet, eye protection and other on any part of your vehicle. protective apparel when you ride. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 9: Load Limits And Guidelines
If you wish to carry more cargo, check with your Honda dealer for safety. Anytime you ride with a pillion rider or cargo you should be aware of the advice, and be sure to read the information following information. - Page 10 Before you consider making any modifications steering travel, alter your riding position or adding an accessory, be sure to read the or interfere with operating any controls. following information. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 11: Anti-Theft Tips
Owner’s Manuals. Removing modifying your lights, NAME: mufflers, emission control system or other ADDRESS: equipment can also make your vehicle illegal. PHONE NO: CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 12: Parts Location
Headlight dimmer switch Rear view mirror Rear view mirror Fuel gauge Speedometer Throttle grip Clutch lever Front brake lever Turn signal switch Starter button Horn button Ignition switch Fuel filler cap CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 13 (4) Pillion rider foot peg (12) Rear carrier (5) Storage compartment (13) Side stand (6) Battery (14) Centre stand (7) Main fuse (15) Engine oil drain plug (8) Kick starter (16) Gearshift pedal CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 14: Serial Numbers
Record the numbers here for your reference. FRAME NO._________________________ ENGINE NO.________________________ (1) Speedometer (2) Odometer (3) Fuel Meter (4) High Beam Indicator (5) Turn Signal Indicator (6) Neutral Indicator (1) Frame Number (2) Engine Number CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 15 The amount of fuel left in the tank with the vehicle set upright when the needle enters the red band is approximately. 1.4 L (0.36 US gal, 0.30 Imp gal) (1) Fuel meter (2) Red Band CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 16: Major Components
Measured at the tip of the “Front Brake Lever” (1), freeplay should be maintained 10-20 mm (0.4-0.8 in) 10-20 mm (2) Front Brake Adjustment Nut Decrease Freeplay Increase Freeplay (3) Brake Arm Pin CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 17 5. Push the brake arm by hand to confirm If proper adjustment cannot be obtained by that it has freeplay and front wheel this method, see your Honda dealer. rotate smoothly. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 18 4. Apply the brake several times and check for free wheel rotation after the brake pedal is released. (1) Rear Brake Pedal If proper adjustment cannot be obtained by this method, see your Honda dealer. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 19: Clutch
Normal clutch lever freeplay is: vehicle should begin to move smoothly 10-20 mm (0.4-0.8 in) and accelerate gradually. 10-20 mm (2) Lock nut (1) Clutch lever (3) Adjusting nut Decrease Freeplay Increase Freeplay CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 20: Fuel
ON position each time you refuel. If the knob is left in RES position, you may not notice when you run out of fuel with no (1) Fuel knob reserve. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 21 Push the fuel fill cap into the filler misuse, and damage caused by misuse is neck until it snaps closed and gets locked. not covered by Honda’s Limited Warranty. Remove the key. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 22: Evaporative Emission Control System
When certain types of petrol containing atmosphere. Rather than venting a gas alcohol are used, problem such as hard tank to the atmosphere. starting, poor performance, etc. may If the problem occurs, contact your Honda occur. dealer. • If you notice any undesirable operating... -
Page 23: Engine Oil
If engine oil level is below from ‘Min.’ mark, (1) Upper Level Mark please contact Honda Authorised Dealer. (2) Lower Level Mark (3) Oil Filler Cap/Dipstick CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 24: Tyres
Air Pressure given below. If you do the tyres will be Keeping your tyres properly inflated under inflated. provides the best combination of handling, tread life and riding comfort. Generally CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 25 For this reason, even though they remain fully inflated, it is important to regularly check the tyre for embedded objects. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 26 CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 27: Essential Individual Components
Engine can be operated. Key cannot be removed Turn signal and horn can be operated. The Headlight, taillight, position light and meter lights glow only when the engine is running CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 28: Right Handlebar Control
See page 29 for the starting procedure. while riding. “Automatic Headlamp ON” feature of your vehicle helps other to recognize your vehicle position in foggy/ dusty environment condition. (1) Start Button CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 29: Features
(1) Ignition Key (1) Headlight Dimmer Switch (A) Push In (2) Turn Signal Switch (B) Turn to LOCK (C) Turn to OFF (3) Horn Button CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 30: Right Side Cover
Installation: • Installation can be done in the reverse order of removal (1) Screw (1) Right Side Cover (2) Left Side Cover (2) Grommet (3) Grommet (3) Lugs (4) Lugs CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 31: Storage Compartment & First Aid Kit
3 Kg (6.6 lbs) (1) Storage Compartment (2) First Aid Kit HEADLIGHT AIM VERTICAL ADJUSTMENT Vertical adjustment can be made by moving the headlight assembly, as necessary. (1) Rear Carrier CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 32: Operation
(page 12-13). than 5 seconds at a time. Release the start 4. Tyres – check condition and pressure button for approximately 10 seconds before (page 20 –22). pressing it again. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 33 With the throttle slightly open, press the starter button. b <Using the kickstarter pedal> Lightly depress the kickstarter until (1) Choke Lever resistance is felt. (A) Fully ON (B) Halfway Position (C) Fully OFF CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 34 ON and open the it runs smoothly and responds to the throttle slightly, start the engine using the throttle when the choke lever is at fully OFF (C). kick-starter. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 35: Running-In
SHIFTING engine speed by opening the throttle. Proper shifting can prevent damaging the Coordination of the throttle and clutch engine and transmission. lever will assure a smooth positive start. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 36: Braking
• When descending a long, steep grade, 3. Lock the steering (page 25) to help use engine compression braking by prevent theft . down-shifting with intermittent CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 37: Maintenance
If your vehicle overturns or becomes technician or other qualified mechanic; instructions are included in this manual only involved in a crash, be sure your Honda to assist in emergency service. dealer inspects all major parts, even if you are able to make some repairs. -
Page 38: Safety Precautions
• Burns from hot parts. reliability, only genuine Let the engine and exhaust system Honda parts or their equivalents for cool before touching. repair and replacement. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 39: Maintenance Schedule
Should be serviced by your Honda dealer, unless the owner has the proper tools and service data and is mechanically qualified. Refer to the Official Honda Shop Manual. ** In the interest of safety, we recommend these items be serviced only by your Honda dealer. - Page 40 SECONDARY AIR SUPPLY SYSTEM The vehicle must be serviced at every 4000 kms or within 4 months whichever is earlier from the date of previous service. For NOTES refer page 35. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 41 ** STEERING HEAD BEARINGS The vehicle must be serviced at every 4000 kms or within 4 months whichever is earlier from the date of previous service. For NOTES refer page 35. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 42: Tool Kit
Engine Oil Good engine many desirable qualities. Use only high detergent, quality motor oil certified on the container to meet or exceed requirements for API Service Classification MA (1) Tool Kit CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 43 Do not throw it in the trash (1) Oil Drain Bolt (2) Sealing Washer or pour it on the ground or down a drain. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 44: Crankcase Breather
24 N.m (2.4 kgf.m, 17 Ibf.ft) Service more frequently when riding in If a torque wrench is not used for this installation, see your Honda dealer as soon rain,or at full throttle. as possible to verify proper assembly. 4. Fill the crankcase with recommended grade oil;... -
Page 45: Spark Plug
“Spanner” (3) furnished in the tool kit. (4) Spark Plug Gap (5) Side Electrode 5. Make sure the plug washer is in good (1) Spark Plug Cap condition. (2) Plug Wrench (3) Spanner CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 46: Valve Clearance
Refer to the Safety Precautions on Page 34. threading. Should be serviced by your Honda dealer, 7. Tighten the spark plug: unless the owner has the proper tools and • If the old plug is good service data and is mechanically qualified. - Page 47 If they are tight and the valves are Finally, recheck the clearance to make sure open, rotate the flywheel 360 degree and realign the “T” mark to the index mark. that adjusting has not been disturbed. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 48: Idle Speed
3. Adjust idle speed with the “Throttle Stop Screw” (1). Idle speed (In neutral): 1400±100 min (rpm) (1) Lock nut (2) Adjuster (1) Throttle Stop Screw (A) Decrease (B) Increase (A) Increase (B) Decrease CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 49: Air Cleaner
Using the wrong 3. Remove the “Air Cleaner Cover” (2). Honda air cleaner element or a non- Honda air cleaner element which is not of 4. Take out the “Air Cleaner Element” (3) equivalent quality may cause premature and replace. -
Page 50: Drive Chain
Drive chain slack should (1) Inspection Cap be adjusted approximately to allow the (2) Drive Chain following vertical movement by hand: Chain slack should be: 25-35 mm (0.98 - 1.38 in) CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 51 (3) Upper Chain Case 7. Install the upper case into the swingarm (4) Lower Chain Case by prefiting all claws of the upper case with ones of the lower case. (5) Claws CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 52 4. Turn both “Drive Chain Adjusting Nuts” (4) Index Marks (3) an equal number of turns until the (5) Rear Edge Of Adjusting Slot correct drive chain slack is obtained. (6) Drive Chain Lock Nuts CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 53 54 N.m (5.5 kgf.m, 40 lbf.ft) chain cases (page 47). If the torque wrench is not used for this 2. For drive chain cleaning use Honda installation, see your Honda dealer as soon recommended chain cleaner. as possible to verify proper assembly.
- Page 54 (1) Drive Chain Wear Indicator Label Improper maintenance of chain can lead (2) Index Mark to premature wear of sprockets and chain (3) Drive Chain Adjuster drive. (4) Red Zone CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 55: Front And Rear Suspension
Cable” (4) from the “Brake Arm” (5). the pivot area and lubricate the pivot bolt Drum CBS: Remove “Adjusting Nut with clean engine oil. A” (6), “Adjusting Nut B” (7) and CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 56 (4) Front Brake Cable (5) Brake Arm (6) Adjusting Nut A (8) Tang (7) Adjusting Nut B (8) Combi Brake Cable (9) Slot (9) Front Axle Nut (10) Front Axle Shaft CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 57 If a torque wrench was not used for installation, see your Honda dealer as soon as possible to verify proper assembly. Improper assembly may lead to loss of braking capacity.
- Page 58 Honda dealer as To install the rear wheel, reverse the soon as possible to verify proper assembly. removal procedure. Improper assembly may lead to loss of braking capacity. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 59: Brake Shoe Wear
Battery contains lead, which is a hazardous (4) Brake Panel material and if improperly disposed, can be harmful to the environment and human health. Always return the used maintenance-free battery to the Honda dealer. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 60 (+) terminal first, then the negative (-) 5. Disconnect the “Positive (+) Terminal terminal. Lead” (4). 2. Check all bolts and other fasteners are secure. 6. Pull out the “Battery” (5) from the battery box. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 61: Fuse Replacement
The “Spare Fuse” (2) is attached or engine power. to the fuse holder. Turn the ignition switch OFF before checking replacing fuses prevent accidental short-circuit. Blown fuse (1) Fuse Holder (2) Spare Fuse CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 62 Installation leave the blown fuse in that circuit and have your vehicle checked by your Honda dealer. Push MAIN FUSE The main fuse is located near the battery.
-
Page 63: Brakelight Switch Adjustment
(2) Wire Connector (3) Relay Comp Start - Self Drum (4) Spare Main Fuse 5. Reconnect the wire connection and (1) Brakelight Switch (2) Adjusting Nut install the right side cover. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 64: Bulb Replacement
Do not use bulbs other than those specified. • After installing a new bulb, check that the light operates properly. (1) Front Cowl (2) Screws Headlight Connector (4) Position Light Bulb CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 65 (1) Dust Cover side may cause damage to the lugs. (2) Bulb Before installing the cowl, ensure all 3 (3) Locking Pin clips are fitted on to their lugs. (4) ”Top” Mark CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 66 Removal: Pull down tail light lens (1) Screws (2) Taillight Lens (3) Bulb (4) Tabs Pull out tail (5) Rear Cowl Groove light lens CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 67: Cleaning
High pressure water (or air) can damage certain parts of the vehicle. Washing the vehicle (1) Turn Signal Lens (2) Screw 1. Rinse the vehicle thoroughly with cool (3) Bulb water to remove loose dirt. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 68 5. Dry the vehicle, start the engine, and let was sprayed with in winter, and the seawater it run for several minutes. becomes the cause which rust occurs in. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 69: Storage Guide
2. Empty the fuel tank into an approved the cap to any convenient plastic body petrol container using a commercially part so that it is positioned away from available hand siphon or an equivalent the spark plug. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 70: Removal From Storage
7. Inflate the tyres to their recommended Test ride the vehicle at low speeds in a safe pressures. Place the vehicle on blocks riding area away from traffic. to raise both tyres off the ground. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. -
Page 71: Specifications
Fuel tank ---------------------------------------- 8 liter (2.1 US gal,1.76 lmp gal) Fuel tank reserve ------------------------------- 1.4 liter (0.39 US gal, 0.32 lmp gal) Passenger capacity ----------------------------- Operator and one pillion rider Maximum weight capacity ---------------------- 170 Kg (375 lbs) CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd. - Page 72 Front ----------------- 80/100-18M/C 47P Rear ------------------ 80/100-18M/C 54P POWER TRANSMISSION Primary reduction ------------------------------- 3.722 Gear ratio, 1st -------------------- 3.181 2nd ------------------- 1.764 3rd -------------------- 1.190 4th -------------------- 0.916 Final reduction ---------------------------------- 2.928 CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 73 High beam indicator ---------------------------- 12 V – 1.7 W x 1 Neutral indicator -------------------------------- 12 V – 1.7 W x 1 FUSE Main fuse ---------------------------------------- 10 A Sub fuse ----------------------------------------- 7 A CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 74 CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
-
Page 75: Warranty Policy
Valid in India only Warranty Policy Honda Motorcycle & Scooter India (Pvt.) Ltd. (HMSI) gives the following warranty in respect of vehicle “CD110 Dream DX” manufactured by them. Proper care and precaution has been taken to ensure the best quality in respect of the material and workmanship in manufacturing “CD110 Dream DX”. - Page 76 8. If there is any damage caused due to usage of items like brake shoes, Clutch Disc, Chain, improper oil/grease, non genuine parts. Chain Sprocket, Wheel Rim (in case of CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 77 HMSI reserves the right to make any the authorized service center shall take such changes in design or to add any improvement CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 78 Owner’s Manual shall be failure of the vehicle to meet the emission charged as per actuals. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 79 9. All the parts removed for replacement under Owner’s Manual for use of the vehicle. warranty will property b. Under all circumstances uses lubricants manufacturer. fuel recommended manufacturer. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 80 A vehicle, or parts thereof, which has been Motor Vehicle Rules. altered, tampered with modified Produces the Owner’s Manual and Log replaced in an unauthorized manner. book for verification details. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
- Page 81 Owner’s Manual and all conditions described there in will apply in addition to those exclusively stipulated in this warranty. CD110 Dream DX Honda Motorcycle & Scooter India Pvt. Ltd.
