Item Qty. Part No. Description
1
1
900634 Top Pole Section
2
1
901035 Middle Pole Section
3
1
900641 Bottom Pole Section
4
2
202800 Ground Sleeve Half
5
1
202801 Ground Sleeve Cap
6
1
203279 Anti-Skid Tape
7
2
208668 Bolt, Hex, 3/8-16 x 5.50 Long
8
1
903601 Rebar, Reinforcement Bar
9
2
204159 Clip, Plastic, Rebar Holder
10
2
203063 Nut, Ny-lock, 3/8-16
1
108163 Pole Mount Bracket
11
12
1
206990 Reinforcement Bracket
2
203053 Bolt, Carriage, 5/16-18 x 4.0 Long
13
14
1
204583IG Label, Height Adjustment
1
918153 Tube Assembly w/Handle, Adjustment, Outer
15
1
901034 Tube, Adjustment, Inner
16
1
203099 Nut, Nylock, 5/16-18
17
1
202739 Bolt, Hex, 5/16-18 x 1.75 Long
18
19
6*
203100 Nut, Hex-Flange, 5/16-18
206244 Bolt, Hex, 1/2-13 x 8 Long
20
5
21
5
206340 Nut, Ny-lock, 1/2-13
4
206311 Spacer 0.530 I.D. x 0.75 O.D. x .50 Long
22
2
200520 Screw, #8 x 3/4 Long
23
24
2
204838 Spring, Elevator
PARTS LIST - See Hardware Identifier
NOTE
Hardware kit is designed for more than
one style of basketball system. In some
models not all hardware will be used.
Some models may not include all hardware
listed in Parts List.
Item Qty. Part No. Description
25
2
901675 Elevator Tube, Upper
26
2
901676 Elevator Tube, Lower
27
4
208892 Bolt, Hex-Head, 5/16-18 x 1.625" Long
28
1
206048 T-Bolt, 3/8-16 x 3.25" Long
29
1
900033 Bracket, Slam Jam
207641 Spacer 0.530 I.D. x 0.75 O.D. x 1.61 Long
30
2
31
1
600137 Pole Cap
32
1
Rim
33
1
200318 Bracket, S/J Reinforcement
34
1
208760 Spring, Black, Slam Jam
35
1
203470 Washer, Flat, Slam Jam
36
1
203795 Nut, Special, Slam Jam
38
1
Net
1
200503 Cover, Black or
39
200504 Cover, Red
208813 Spacer 0.39 I.D. x 0.75 O.D. x .50 Long
40
4
20279501 Label, NBA
41
1
42
1
206275 Spacer 0.510 I.D. x 0.75 O.D. x 4.563 Long
* You may have extra parts with this model.
10
