For proper installation and best possible fit, please read all instructions BEFORE you begin.
For technical assistance or to obtain missing parts, please call Customer Relations at 1-800-241-7219.
Important Safety Information
• CAUTION - Before driving, ensure that the vent visor is properly secured to vehicle.
• Do not use automatic "brush-style" car washes.
• Do not use cleaning solvents of any kind.
• Periodically check all components for tightness.
Contents - 2 Piece Set
Front Driver
Side Visor
Contents - 4 Piece Set
Front Driver
Side Visor
Tools Required
Car Wash Supplies
Preparation Before Painting / Installation
• A trial fit is recommended to ensure proper positioning and fit.
• Check fit of parts before painting as we will not accept the return of modified or painted parts.
• Wash and dry your vehicle to remove any debris and/or dirt from the installation area.
Installation Steps
Lower window. Use a putty knife to grasp and pull down the rubber window channel. Clean the inside of the window
rubber window channel
1
Installation Instructions
Ventshade
Front Passenger
Side Visor
Rear Passenger's
Front Passenger
Side Visor
Clean Towel
Phillips Screwdriver
NOTE: Actual application may vary slightly from illustrations.
channel with an alcohol pad.
Without Post
Deflector
®
TapeTabs x10
Rear Driver's
Visor
Tape Tabs x18
Visor
Putty Knife
rubber window channel
Page 1 of 3
I - Sheet Number VS04 Rev.A
Alcohol Pad x2
Alcohol Pad x4
Screws x2
Punch
Drill
With Post
