- Page 1 ASTROJET 2650P/2800P PRINTER OPERATOR MANUAL Astro Machine Corp. 630 Lively Blvd. Elk Grove Village, IL 60007 Phone: (847) 364-6363 Fax: (847) 364-9898 www.astromachine.com...
- Page 2 SAFETY PRECAUTIONS THIS EQUIPMENT PRESENTS NO PROBLEM WHEN USED PROPERLY. HOWEVER, CERTAIN SAFETY RULES SHOULD BE OBSERVED WHEN OPERATING THE ASTROJET 2650P/2800P PRINTER. BEFORE USING THE PRINTER, YOU SHOULD READ THIS MANUAL CAREFULLY AND FOLLOW THE RECOMMENDED PROCEDURES, SAFETY WARNINGS, AND INSTRUCTIONS: ...
-
Page 3: Table Of Contents
Connecting the AstroJet 2650P/2800P Connecting the Computer Installing the Inkjet Cartridges Setting up the Feed Installing the Printer Driver Section 3 – Operating the AstroJet 2650P/2800P Printer Operation Printer Driver Properties Printing from Microsoft Word Section 4 – Maintenance The Inkjet Cartridge... - Page 4 TABLE OF CONTENTS Notes...
-
Page 5: Section 1 - Getting Acquainted
Exit Guides – Help the media to exit the Printer. Printhead Assembly – AstroJet 2650P has six Printheads arranged on two rails and can print an image up to 3" wide. AstroJet 2800P has eight Printheads arranged on two rails and can print and image up to 4" wide. -
Page 6: Rear View
SECTION 1 GETTING ACQUAINTED AstroJet 2650P Shown Rear View Main Power Switch and Power Receptacle – Power cord plugs in here. Switch turns the Printer ON and OFF. Main Power Fuse – Protects all of the electronic circuits in the Printer. -
Page 7: Control Panel
Printheads to compensate for different media thickness. ON LINE key – Indicator lights when data is sent to the ASTROJET 2650P/2800P and printing is ready to begin. Also turns the Printer offline to access the Menu Mode. - Page 8 SECTION 1 GETTING ACQUAINTED Notes...
-
Page 9: Section 2 - Installing The Printer
Printer and latch the two locking clips. USB Port: You may also connect the Printer through a USB connection if you are using Windows ME, 2000, NT, or XP. The cable used to connect the AstroJet 2650P/2800P to the computer must not exceed 6 feet long. -
Page 10: Installing The Inkjet Cartridges
SECTION 2 INSTALLING THE PRINTER Install the Inkjet Cartridges The AstroJet 2650P can be configured with six Inkjet Cartridges. The AstroJet 2800P can be configured with eight Inkjet Cartridges. To install the Cartridges: Remove the Inkjet Cartridge from its packaging, taking care not to touch the copper contacts, the metal plate, or the gold printhead. -
Page 11: Installing The Printer Driver
Exit Guides do not track over any printed information. Media Thickness Dial Setting 7. Turn the AstroJet 2650P/2800P on and then turn the .004" to 1/32" 0 to 2 Media Thickness Knob to set the initial Printhead 1/32"... - Page 12 5. Select printer port LPT1. Then click Next>. The “Add Printer Wizard” will appear. Select your printer from the table below, then click Next> Printer Driver AJ 2650P AstroJet 2650 AJ 2800P AstroJet 2800 6. The next screen allows you to “Name Your Printer”.
-
Page 13: Section 3 - Operating The Astrojet 2650P/2800P
Microsoft Word. Other types of applications and database management software will work in a similar manner using the ASTROJET 2650P/2800P Driver. This Section further assumes that you have connected the ASTROJET 2650P/2800P to your computer. Printer Operation When you first turn the Printer ON, the ON LINE key light will blink. - Page 14 SECTION 3 OPERATING THE ASTROJET 2650P/2800P Press Enter to Purge – The purging function is useful to clear the Printhead Nozzles when the machine has been sitting idle for a time. To activate the purge, press the ENTER key to feed one piece of media. To purge the Printheads additional times, press the ENTER key for each additional purge.
-
Page 15: Printer Driver Properties
BIOS Version – Press the “+” key to display the version of the BIOS. Bulk Ink – This feature is not used on the AstroJet desktop printers. No provisions are made to install the larger cartridges. + / - key Used to step through the options in various Menu Modes. - Page 16 To start printing, click on File, then Print. The “Print” window will open. If you wish to print the job, click OK. To use the special features built into the AstroJet 2650P/2800P Drivers, clicking on the Properties Button will open the Properties Window in Windows 98, 2000, XP, or ME.
- Page 17 SECTION 3 OPERATING THE ASTROJET 2650P/2800P Resolution Speeds available 150 DPI Low, Medium, Medium High, and High 200 DPI Low, Medium, and Medium High 300 DPI Low, and Medium 600 DPI The Feed Delay can be used to put more space between the pieces as they are being printed.
- Page 18 Inverse Printing The Paper Tab contains one element that is used to reverse or invert the printing on the AstroJet 2650P/2800P. In normal operation the printing is read from the operator side of the Printer. It is sometimes necessary to turn the printing direction 180 degrees from the normal direction.
-
Page 19: Printing From Microsoft Word
Once the page layout is set, you might want to save it as a template for use later. When you have completed the steps above the layout for an AstroJet 2650P should look like the one below. NOTE: When setting up a layout for the ASTROJET Printers, be aware that the Printheads are aligned in two banks on the AJ2650P and these banks can be aligned so that you can print up to 3"... - Page 20 SECTION 3 OPERATING THE ASTROJET 2650P/2800P Click on Tools and then Mail Merge. The “Mail Merge Helper” window will open. Click On Create, then Envelopes. The “Microsoft Word” window will open. Click on the Active Window button, and then click on the Get Data button.
-
Page 21: Section 4 - Maintenance
SECTION 4 MAINTENANCE Section 4 - Maintenance This section covers how to care for the Ink Cartridges, clear paper jams, replace the Sheet Separators, and perform routine maintenance on the Printer. The Inkjet Cartridge The Inkjet Cartridges must be replaced when out of ink, when print quality is poor, or when purging and cleaning have not helped the image quality. - Page 22 SECTION 4 MAINTENANCE Storage Short-term Storage (less than 2 days or less than 1 day in a hot and dry environment) Leave the Cartridge in the Printer for short periods of time, 1 day or less. The next time that the Printer is used, the Printhead may have to be cleaned and purged. Long-term Storage (more than 2 days or more than 1 day in a hot and dry environment) Place the Cartridges in the Cartridge Docking Station located at the rear of the Printer, or ®...
-
Page 23: Jams In The Printer
Nozzles. White streaks will then show up in the printed text or graphic. In order to obtain better print quality, these ink plugs need to be forced out or purged. A Purge routine is built into the Astrojet 2650P/2800P Printer. -
Page 24: Replacing The Feed Rollers
SECTION 4 MAINTENANCE Replacing the Feed Rollers To replace the Feed Rollers on the AstroJet Printer follow the steps below: Before removing the Feed Roller Access Plate, unplug the power to the Printer. 2. Using a Phillips screwdriver, remove the three screws from the Feed Roller Access Plate. -
Page 25: Cleaning
SECTION 4 MAINTENANCE Cleaning WARNING THE PRINTER IS A PRECISION MACHINE THAT SHOULD BE CLEANED REGULARLY TO INSURE MANY YEARS OF SERVICE. BEFORE PERFORMING ANY MAINTENANCE, DISCONNECT THE MACHINE FROM ITS POWER SOURCE! The Printer must be cleaned regularly of accumulated paper dust and ink. Depending on the types of media that are run, paper dust may accumulate within the Printer and on the Transport. - Page 26 SECTION 4 MAINTENANCE Notes...
-
Page 27: Section 5 -Troubleshooting
The following Troubleshooting Guides are provided to assist you in solving any problems that might occur with the Astrojet 2600P/2800P Printer or its software. We have tried to make them as complete as possible. The best advice we can offer is to make sure that the system is setup properly, plugged in, that it has an adequate supply of ink before attempting to troubleshoot any problem. -
Page 28: The Printer
Printheads. Adjust the positioning of the two Printheads in relationship to each other using the Head Alignment Tool in the AstroJet Software Control Panel or in the Properties window of the PCL version Driver. Uneven split line of type... -
Page 29: Appendices
APPENDIX A Appendix A – ASTROJET 2650P/2800P Specifications AstroJet 2650P Inkjet, 6 HP 45 High Capacity Inkjet Cartridges PRINT TECHNOLOGY AstroJet 2800P Inkjet, 8 HP 45 High Capacity Inkjet Cartridges Up to 26,000/hr - #10 Envelopes ADDRESS SPEED High Quality... -
Page 30: Appendix B - Supplies And Optional Hardware
APPENDIX B Appendix B – Supplies and Optional Hardware The following supply items and optional hardware are available from your Astro Machine Dealer: Supplies Red Inkjet Cartridge HPC6168A Green Inkjet Cartridge HPC6169A Blue Inkjet Cartridge HPC6170A Yellow Inkjet Cartridge HPC6173A Versatile Black HPC8842A General Black (works on high gloss... -
Page 31: Index
INDEX - Key 3, 11 Installing Cartridges 6, 10 + Key 3, 11 Installing New Printheads Installing Printer Driver Inverse Printing Accessory Connector Address Recovery Adjusting Resolution Jams 19, 24 Adjusting Speed Jam Recovery Adjusting, Printheads 13, 14 Automatic Feed Layout Batch Counter Mail Merge... - Page 32 INDEX Rear Media Guide Rear Paper Support Recovering from Jam Removing Jams Replacing Cartridges Replacing Feed Rollers Replacing Separators Reset Key 3, 11 Resolution Safety Inside Front Cover Safety Cover Separator Locking Knob Setup Feed Setup Media Thickness Setup Overlay Setup Page Sheet Separators 6, 19...
- Page 34 Copyright © 2013 ASTRO MACHINE CORP. Elk Grove Village, IL 60007 09/05/2013 Part Number: 200-AJ2650/2800PCL Rev. D...
