Summary of Contents for Digisol Ranger Series
- Page 6 Users can verify Wireless Repeater status from the LED indicators on the front panel. Below given is the LED description. Color LED Status Description Good signal reception Steady ON (signal strength 100% ~ 50%). Normal signal reception Slow blinking (50% ~ 25%) Signal Amber Blinking...
- Page 7 WPS button WPS LED...
- Page 9 Signal LED...
- Page 10 Software Installation:- Insert the Setup CD into your CD-ROM drive of notebook/desktop computer. Explore the CD and execute the “APWizard.exe” file. Screen given below will be displayed. Click ‘Next’ to continue.
- Page 11 C onnect one end of the netw ork cable to the LA N port on the repeater and the other end to the PC ’s Ethernet port. Pow er on the repeater and ensure that all the LED ’s on the repeater are on.
- Page 12 Note : Till the log in, the utility configuration procedure is the same for AP mode, Repeater mode and client mode. Below are the instructions for the respective modes after the login is done. AP Mode Configure the SSID and Channel Number. Click ‘Next’ to continue.
- Page 13 Verify the settings you have configured and click ‘Restart’. This will take 60 Seconds. Then Press ‘OK’. Once you click on OK, a system restart screen will appear which will also take 60 seconds.
- Page 14 Click ‘Finish’ to complete the installation. Repeater Mode Click on ‘Site Survey’, “Wireless Site Survey” window will appear. Select the wireless router or AP you wish to connect and click ‘Connect’, or enter your wireless network’s SSID manually. Click ‘Next’ to continue.
- Page 16 To configure Root AP’s SSID Click on ‘Site Survey’, a “Wireless Site Survey” window will appear. Select the wireless router or AP you wish to repeat and click ‘Connect’. Next, configure a network name in Main SSID for the repeater to be identified.
- Page 17 Configure the wireless security settings. Then click ‘Next’. Verify the settings you have configured and click ‘Restart’.
- Page 18 This will take 60 Seconds. Then Press ‘OK’. Once you click on OK, a system restart screen will appear which will also take 60 seconds. Click ‘Finish’ to complete the installation.
- Page 19 Client Mode Click on ‘Site Survey’, “Wireless Site Survey” window will appear. Select the wireless router or AP you wish to connect and click ‘Connect’, or enter your wireless network’s SSID manually. Click ‘Next’ to continue. Configure the wireless security settings. Then click ‘Next’.
- Page 20 Verify the settings you have configured and click ‘Restart’. Note: Next, Follow the same step to restart the repeater as done in previous two modes and click finish to complete the installation . Congratulations! Your Repeater Installation is now finished.
