SETUP GUIDE
Wireless Repeater Mode
RANGER SERIES
DG-BR4000N/E
V1.0
2013-02-04

Advertisement

loading
Need help?

Need help?

Do you have a question about the RANGER SERIES DG-BR4000N/E and is the answer not in the manual?

Questions and answers

Related Manuals for Digisol RANGER SERIES DG-BR4000N/E

Summary of Contents for Digisol RANGER SERIES DG-BR4000N/E

  • Page 1 SETUP GUIDE Wireless Repeater Mode RANGER SERIES DG-BR4000N/E V1.0 2013-02-04...
  • Page 2 Trademarks DIGISOL™ is a trademark of Smartlink Network Systems Ltd. All other trademarks are the property of the respective manufacturers.
  • Page 3 SETUP GUIDE Wireless Repeater Mode DG-BR4000N/E can be configured in Repeater mode with Access Point when the AP is configured in WDS with AP mode. Network devices used in this setup: DG-BR4000N/E DG-WA1000N or DG-WA3000N or DG-WA3000NP or DG-WA3002NP Wireless Laptop Network Setup: In the Following setup, DG-WA3000N (AP) is connected in the existing LAN and we are connecting DG- BR4000N/E (Router) to extend the wireless range of the AP.
  • Page 4 SETUP GUIDE Wireless Repeater Mode Step 1 : Configure the AP Access the web GUI of the AP. The default IP of the AP is 192.168.2.1 and the user name is “admin” and password is “1234”. Click on “Basic Settings” on the left hand side and select the mode to “AP Bridge-WDS”. In the “MAC address 1:”...
  • Page 5 SETUP GUIDE Wireless Repeater Mode Step 2 : Configure the routers LAN IP address Access the web GUI of the router, default IP is 192.168.2.1 and the username is “admin” and the password is “1234”. If the router IP is default then we need to change it to some other IP other than the AP IP address. In the following screen, we will assign an IP 192.168.2.2 to the router.
  • Page 6 SETUP GUIDE Wireless Repeater Mode Step 3 : Configure the Wireless Settings on router To configure the wireless settings on the router, click on “Wireless Settings > Wireless Basic Settings”. Configure the desired SSID and then set the “Channel” to one which is configured on the Access Point. In this setup the channel on AP was set to 11, hence we will set the same channel on router.
  • Page 7 AP Verification: On the wireless client seach for the wireless network and select and connect to “DIGISOL” SSID. Once connected then ping to the LAN IP of DG-BR4000N/E i.e 192.168.2.2. If you get reply then ping to 192.168.2.1 i.e.
  • Page 8 SETUP GUIDE Wireless Repeater Mode...
