Page 1 Operation Manual Model GFC7001T Carbon Monoxide Analyzer P/N M90914 DATE 12/01/14 TELEDYNE ELECTRONIC TECHNOLOGIES Analytical Instruments 16830 Chestnut Street City of Industry, CA 91748 Telephone: (626) 934-1500 Fax: (626) 961-2538 Web: www.teledyne-ai.com Teledyne Analytical Instruments...
Page 2 Any safeguards required such as locks, labels, or redundancy, must be provided by the user or specifically requested of Teledyne at the time the order is placed.
Page 3: About This Manual
Model GFC7001T Carbon Monoxide Analyzer ABOUT THIS MANUAL This manual describes operation, specifications, and maintenance for the Model GFC 7001T. In addition this manual contains important SAFETY messages for this instrument. It is strongly recommended that you read that operation manual in its entirety before operating the instrument.
Page 4 Model GFC7001T Carbon Monoxide Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 5: Important Safety Information
NEVER use any gas analyzer to sample combustible gas(es). Technical Assistance regarding the use and maintenance of the Note GFC7001T or any other Teledyne product can be obtained by contacting Teledyne Customer Service Department: Phone: 888-789-8168 Email: ask_tai@teledyne.com...
Page 6: Consignes De Sécurité
Safety Information Model GFC7001T Carbon Monoxide Analyzer CONSIGNES DE SÉCURITÉ Des consignes de sécurité importantes sont fournies tout au long du présent manuel dans le but d’éviter des blessures corporelles ou d’endommager les instruments. Veuillez lire attentivement ces consignes. Chaque consigne de sécurité...
Page 7: Table Of Contents
2.3.2. EmC ............................... 30 2.3.3. Other Type Certifications ........................30 3. GETTING STARTED ......................31 3.1. Unpacking the GFC7001T/GFC7001TM Analyzer ..................31 3.1.1. Ventilation Clearance ..........................32 3.2. Instrument Layout ............................33 3.2.1. Front Panel ............................33 ...
Page 8: Table Of Contents
5.9.3.7. Manual Adjustment of Current Loop Output Span and Offset .............125 5.9.3.8. Turning an Analog Output Over-Range Feature ON/OFF ............128 5.9.3.9. Adding a Recorder Offset to an Analog Output ................129 5.9.3.10. AIN Calibration ...........................130 5.9.3.11. Analog Inputs (XIN1…XIN8) Option Configuration ..............131 Teledyne Analytical Instruments viii...
Page 9 5.9.8.1. Selecting a Test Channel Function for Output A4 ................133 5.10. SETUP MORE ALRM (Option): Using the Gas Concentration Alarms ...........134 5.10.1. Setting the GFC7001T Concentration Alarm Limits ................135 6. COMMUNICATIONS SETUP AND OPERATION ............. 137 6.1. Data Terminal/Communication Equipment (DTE DCE) ................137 ...
Page 10 ACAL: Programming and AUTO CAL Sequence ...............199 9.4.1.1. AutoCal with Auto or Dual Reporting Ranges Modes Selected ...........201 9.5. CO Calibration Quality ..........................202 9.6. Calibration of the GFC7001T/GFC7001TM Electronic Subsystems ............203 9.6.1. Dark Calibration Test ...........................203 9.6.2. Pressure Calibration ..........................204 ...
Page 11 11.3.2.1. Pressure Leak Check .........................233 11.3.3. Performing a Sample Flow Check .....................233 11.3.4. Cleaning the Optical Bench .......................234 11.3.5. Cleaning Exterior Surfaces of the GFC7001T/GFC7001TM .............234 12. TROUBLESHOOTING AND SERVICE ................235 12.1. General Troubleshooting .........................235 ...
Page 12 13.4.3.5. Electric Test Switch ........................291 13.4.4. Relay Board ............................291 13.4.4.1. Heater Control ..........................291 13.4.4.2. GFC Wheel Motor Control ......................291 13.4.4.3. Zero/Span Valve Options ......................292 13.4.4.4. IR Source ............................292 13.4.4.5. Status LEDs ..........................292 Teledyne Analytical Instruments...
Page 13: List Of Figures
14.4.2.3. Transferring Components from Rack to Bench and Back ............306 14.4.2.4. Opening Shipments from Teledyne Customer Service ..............307 14.4.2.5. Packing Components for Return to Teledyne Customer Service ..........308 GLOSSARY LIST OF APPENDICES APPENDIX A - VERSION SPECIFIC SOFTWARE DOCUMENTATION...
Page 14 Front Panel Display ........................83 Figure 4-2: Viewing GFC7001T/GFC7001TM Test Functions ............... 85 Figure 4-3: Viewing and Clearing GFC7001T/GFC7001TM WARNING Messages ........88 Figure 5-1: Analog Output Connector Pin Out ....................93 Figure 5-2: COMM–...
Page 15 Table of ContentsTeledyne API – Model T300/T300M CO Analyzer Figure 12-11: GFC7001T/GFC7001TM – Internal Pneumatics with O Sensor Option 65A ......250 Figure 12-12: GFC7001T/GFC7001TM – Internal Pneumatics with CO Sensor Option 67A ......251 Figure 12-13: Location of Diagnostic LEDs onCO Sensor PCA ..............266...
Page 16 NIST-SRM's Available for Traceability of CO Calibration Gases ..........69 Table 3-13: Possible Warning Messages at Start-Up ..................71 Table 3-14: Possible Startup Warning Messages – GFC7001T Analyzers with Options ....... 72 Table 4-1: Analyzer Operating Modes ......................84 Table 4-2: Test Functions Defined ........................
Page 17 Analog Output Test Function - Nominal Values Voltage Outputs ..........264 Table 12-12: Status Outputs Check ........................264 Table 13-1: Absorption Path Lengths for GFC7001T and GFC7001TM ............276 Table 13-2: Sync DEMOD Sample and Hold Circuits ...................290 Table 13-3: Sync/Demod Status LED Activity ....................290...
Page 18 Table of ContentsTeledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments xviii...
Page 19: Part I General Information
Part I General Information Teledyne API – Model T300/T300M CO Analyzer PART I GENERAL INFORMATION Teledyne Analytical Instruments...
Page 20 Part I General Information Teledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 21: Introduction, Features And Options
IntroductionTeledyne API – Model T300/T300M CO Analyzer INTRODUCTION, FEATURES AND OPTIONS This section provides an overview of the Model GFC7001T or GFC7001TM Analyzer, its features and its options, followed by a description of how this user manual is arranged. 1.1. GFC7001T FAMILY OVERVIEW The family includes the GFC7001T and the GFC7001TM Gas Filter Correlation Carbon Monoxide Analyzer.
Page 22: Features
IntroductionTeledyne API – Model T300/T300M CO Analyzer 1.2. FEATURES Some of the common features of your GFC7001T family of analyzers include: • LCD color graphics with touch screen interface • Microprocessor controlled for versatility • Multi-tasking software allows viewing of test variables during operation •...
Page 23: Table 1-1: Analyzer Options
Cannot be used with rack mount slides. CAUTION - GENERAL SAFETY HAZARD A fully loaded GFC7001T with valve options weighs about 18 kg or 40 lbs. (GFC7001TM weighs 22.7 kg or 50 lbs). To avoid personal injury we recommend that two persons lift and carry the analyzer.
Page 24 Each instrument in the multidrop network requires this card and a and 5.7.1 communications cable (Option 60B). Second Gas Sensors Choice of one additional gas sensor. • Sections 3.3.1.3 Oxygen (O ) Sensor and 9.7.1 • Sections 3.3.1.3 Carbon Dioxide (CO ) Sensor and 9.7.2 Teledyne Analytical Instruments...
Page 25 5.4.5 method used to remove the gas from the stack dilutes the gas. Call Customer Service for activation. Refer to page iii in this manual for configuration and specific options included with this instrument. Teledyne Analytical Instruments...
Page 26 IntroductionTeledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 27: Specifications And Approvals
SpecificationsTeledyne API – Model T300/T300M CO Analyzer SPECIFICATIONS AND APPROVALS This section presents specifications for the GFC7001T/GFC7001TM analyzer and for its second gas sensor options, EPA equivalency designation, and compliance statements. 2.1. SPECIFICATIONS Table 2-1: GFC7001T/GFC7001TM Basic Unit Specifications Parameter...
Page 28: Table 2-2: O 2 Sensor Option Specifications
4 digital alarm outputs (2 opto-isolated and 2 dry contact) Multidrop RS232 3 4-20mA current outputs Temperature Range 5 - 40°C operating, 10 - 40°C EPA Equivalency (GFC7001T only) Humidity Range 0-95% RH, Non-Condensing < 0.05 % per °C (minimum 50 ppb/°C)
Page 29: Epa Equivalency Designation
Option 51C – Sample/Cal valves with span shutoff & flow control • 4-20mA, isolated output 2.3. APPROVALS AND CERTIFICATIONS The TAI Model GFC7001T/GFC7001TM analyzer was tested and certified for Safety and Electromagnetic Compatibility (EMC). This section presents the compliance statements for those requirements and directives. Teledyne Analytical Instruments...
Page 30: Safety
EN 55011 (CISPR 11), Group 1, Class A Emissions FCC 47 CFR Part 15B, Class A Emissions CE: 2004/108/EC, Electromagnetic Compatibility Directive 2.3.3. OTHER TYPE CERTIFICATIONS MCERTS: Sira MC 050069/04 For additional certifications, please contact Customer Service. Teledyne Analytical Instruments...
Page 31: Getting Started
GETTING STARTED This section first introduces you to the instrument, then presents the procedures for getting started, i.e., unpacking and inspection, making electrical and pneumatic connections, and conducting an initial calibration check. 3.1. UNPACKING THE GFC7001T/GFC7001TM ANALYZER CAUTION ENERAL AFETY...
Page 32: Ventilation Clearance
Back of the instrument 4 in. Sides of the instrument 1 in. Above and below the instrument 1 in. Various rack mount kits are available for this analyzer. See Table 1-1 of this manual for more information. Teledyne Analytical Instruments...
Page 33: Instrument Layout
• Plug-in mouse (not included) to be used as an alternative to the thouchscreen interface • Thumb drive (not included) to download updates to instruction software (contact TAI Customer Service for information). Figure 3-1: Front Panel Layout Teledyne Analytical Instruments...
Page 34: Figure 3-2: Display Screen And Touch Control
Table 3-2 provides detailed information for each component of the screen. COULD DAMAGE INSTRUMENT AND VOID WARRANTY ATTENTION Do not use hard-surfaced instruments such as pens to touch the control buttons. Teledyne Analytical Instruments...
Page 35: Table 3-2: Display Screen And Touch Control Description
The eight touch control buttons along the bottom of the display screen are represented in the bottom row of each menu chart. Teledyne Analytical Instruments...
Page 36: Figure 3-3: Display/Touch Control Screen Mapped To Menu Charts
Display/Touch Control Screen Mapped to Menu Charts Note The menu charts in this manual contain condensed representations of the analyzer’s display during the various operations being described. These menu charts are not intended to be exact visual representations of the actual display. Teledyne Analytical Instruments...
Page 37: Rear Panel
Getting StartedTeledyne API – Model T300/T300M CO Analyzer 3.2.2. REAR PANEL Figure 3-4: Rear Panel Layout Table 3-3 provides a description of each component on the rear panel. Teledyne Analytical Instruments...
Page 38: Gfc7001T/Gfc7001Tm Analyzer Layout
Option for external voltage signals from other instrumentation and for logging these ANALOG IN signals (Section 3.3.1.2) Connector for direct connection to laptop computer, using USB cable. (Section 3.3.1.9). 3.2.3. GFC7001T/GFC7001TM ANALYZER LAYOUT Figure 3-5 shows the GFC7001T internal layout. Teledyne Analytical Instruments...
Page 39: Figure 3-5: Internal Layout - Gfc7001T
Getting StartedTeledyne API – Model T300/T300M CO Analyzer Figure 3-5: Internal Layout – GFC7001T Teledyne Analytical Instruments...
Page 40: Figure 3-6: Internal Layout - Gfc7001Tm
Getting StartedTeledyne API – Model T300/T300M CO Analyzer Figure 3-6 shows the GFC7001TM internal layout. Figure 3-6: Internal Layout – GFC7001TM Teledyne Analytical Instruments...
Page 41: Connections And Setup
Purge Gas Inlet GFC Heater Figure 3-7: Optical Bench Layout (shorter bench, GFC7001TM, shown) 3.3. CONNECTIONS AND SETUP This section presents the electrical (Section 3.3.1) and pneumatic (Section 3.3.2) connections for setup and preparing for instrument operation Teledyne Analytical Instruments...
Page 42: Electrical Connections
ENERAL AFETY AZARD The GFC7001T/GFC7001TM Analyzer can be configured for both 100-130 V and 210-240 V at either 47 Hz or 63 Hz. To avoid damage to your analyzer, make sure that the AC power voltage matches the voltage indicated on the analyzer’s model/specs label (See Figure 3-4) before plugging the GFC7001T/GFC7001TM into line power.
Page 43: Connecting Analog Outputs
See Section 0 for details on setting up the DAS. 3.3.1.3. CONNECTING ANALOG OUTPUTS The GFC7001T is equipped with several analog output channels accessible through a connector on the back panel of the instrument. The standard configuration for these outputs is mVDC. An optional current loop output is available for each.
Page 44: Current Loop Analog Outputs (Option 41) Setup
Servicing or handling of circuit components requires electrostatic discharge protection, i.e. ESD grounding straps, mats and containers. Failure to use ESD protection when working with electronic assemblies will void the instrument warranty. Refer to Section 14 for more information on preventing ESD damage. Teledyne Analytical Instruments...
Page 45: Figure 3-10: Current Loop Option Installed On Motherboard
(see Figure 3-10). 7. Reattach the top case to the analyzer. • The analyzer is now ready to have a voltage-sensing, recording device attached to that output. 8. Calibrate the analog output as described in Section 5.9.3.2. Teledyne Analytical Instruments...
Page 46: Connecting The Status Outputs
1.2V from its collector to emitter. The status outputs are accessed via a 12-pin connector on the analyzer’s rear panel labeled STATUS (see Figure 3-4). Pin-outs for this connector are: STATUS +5V to external device Figure 3-11: Status Output Connector Teledyne Analytical Instruments...
Page 47: Connecting The Control Inputs
There are two methods for energizing the control inputs. The internal +5V available from the pin labeled “+” is the most convenient method. However, if full isolation is required, an external 5 VDC power supply should be used. Teledyne Analytical Instruments...
Page 48: Concentration Alarm Relay (Option 61) Standard Configuration
This relay option is different from and in addition to the “Contact Closures” that come standard on all TAI instruments. Each relay has 3 pins: Normally Open (NO), Common (C), and Normally Closed (NC). Teledyne Analytical Instruments...
Page 49: Figure 3-13: Concentration Alarm Relay
GFC7001TM instrument can monitor both CO & CO gas. The software is flexible enough to allow you to configure the alarms so that you can have 2 alarm levels for each gas. CO Alarm 1 = 20 PPM Teledyne Analytical Instruments...
Page 50: Concentration Alarm Relay (Option 61) Air Products Configuration
SETUP>COMM menu, Section 6. Although Ethernet is DHCP- enabled by default, it can also be configured manually (Section 6.5.1) to set up a static IP address, which is the recommended setting when operating the instrument via Ethernet. Teledyne Analytical Instruments...
Page 51 TAI for pin assignments (Figure 3-14) before using. RS-232 COM P ONNECTOR OUTS Electronically, the difference between the DCE and DTE is the pin assignment of the Data Receive and Data Transmit functions. Teledyne Analytical Instruments...
Page 52: Figure 3-14: Rear Panel Connector Pin-Outs For Rs-232 Mode
Rear Panel Connector Pin-Outs for RS-232 Mode The signals from these two connectors are routed from the motherboard via a wiring harness to two 10-pin connectors on the CPU card, J11 (COM1) and J12 (COM2) (Figure 3-15). Teledyne Analytical Instruments...
Page 53: Figure 3-15: Default Pin Assignments For Cpu Com Port Connector (Rs-232)
Data Bits: 8 data bits with 1 stop bit • Parity: None • COM2: RS-232 (configurable to RS-485), DB-9 female connector. • Baud rate: 19200 bits per second (baud) • Data Bits: 8 data bits with 1 stop bit • Parity: None Teledyne Analytical Instruments...
Page 54 J3 on the Multidrop/LVDS PCA to the CPU’s COM1 connector • (Note that the CPU’s COM2 connector is not used in Multidrop) J4 on the Multidrop/LVDS PCA to J12 on the motherboard • J1 on the Multidrop/LVDS PCS to the front panel LCD • Teledyne Analytical Instruments...
Page 55: Figure 3-16: Jumper And Cables For Multidrop Mode
LEDs (RX and TX) of the COM1 connector (labeled RS232) are both lit. (Ensure you are using the correct RS-232 cables internally wired specifically for RS-232 communication; see Table 1-1: Analyzer , “Communication Cables” and Section 3.3.1.9: Options Connecting the Communications Inerfaces, “RS-232 Connection”). Teledyne Analytical Instruments...
Page 56: Figure 3-17: Rs-232-Multidrop Pca Host/Analyzer Interconnect Diagram
The (communication) Host instrument can only address one instrument at a time. Note TAI recommends setting up the first link, between the Host and the first analyzer, and testing it before setting up the rest of the chain. Teledyne Analytical Instruments...
Page 57: Pneumatic Connections
CAUTION ENERAL AFETY AZARD Sample and calibration gases should only come into contact with PTFE (Teflon), FEP, glass, stainless steel or brass. It is important to conform to all safety requirements regarding exposure to CO. Teledyne Analytical Instruments...
Page 58 See Figure 3-4 and Table 3-3 for the location and descriptions of the various pneumatic inlets/outlets referenced in this section. Note: Depending on the application, some instruments may include an internal pump. Refer to any addendum that may accompany this manual for information pertaining to custom configurations. Teledyne Analytical Instruments...
Page 59: Pneumatic Connections For Basic Configuration
Pneumatic Connections–Basic Configuration–Using Bottled Span Gas Figure 3-19: Pneumatic Connections–Basic Configuration–Using Gas Dilution Calibrator AMPLE OURCE Attach a sample inlet line to the SAMPLE inlet port. The sample input line should not be more than 2 meters long. Teledyne Analytical Instruments...
Page 60: Pneumatic Layout For Basic Configuration
Attach an exhaust line to the analyzer’s EXHAUST outlet fitting. The exhaust line should be: • PTEF tubing; minimum O.D 1/4”; • A maximum of 10 meters long; • Vented outside the GFC7001T/GFC7001TM Analyzer’s enclosure. 3.3.2.2. PNEUMATIC LAYOUT FOR BASIC CONFIGURATION Figure 3-20: GFC7001T/GFC7001TM Internal Gas Flow Teledyne Analytical Instruments...
Page 61: Pneumatic Connections For Zero/Span Valve Option
/min). ALIBRATION OURCES • Attach a gas line from the source of calibration gas (e.g. a Teledyne’s T700 Dynamic Dilution Calibrator) to the SPAN inlet. • Zero air is supplied via a zero air generator such as a Teledyne’s T701.
Page 62: Pneumatic Layout For Zero/ Span Valve Option
• PTEF tubing; minimum O.D 1/4” • Maximum length of 10 meters • Vented outside the analyzer’s enclosure. 3.3.2.4. PNEUMATIC LAYOUT FOR ZERO/ SPAN VALVE OPTION Figure 3-22 Internal Pneumatic Flow OPT 50A – Zero/Span Valves Teledyne Analytical Instruments...
Page 63: Pneumatic Layout For Internal Zero/ Span Valve Option
Open to PRESSURE SPAN inlet • PTEF tubing; minimum O.D 1/4” • 10 meters long max. • Vented outside the analyzer’s enclosure 3.3.2.5. PNEUMATIC LAYOUT FOR INTERNAL ZERO/ SPAN VALVE OPTION Figure 3-23: Internal Pneumatic Flow – Zero/Span/Shutoff Valves (Opt 50B) Teledyne Analytical Instruments...
Page 64: Pneumatic Connections For Zero Scrubber/Pressurized Span Option
In applications where the sample gas is received from a pressurized manifold, a vent must be placed on the sample gas before it enters the analyzer. ALIBRATION OURCES • Attach a gas line from the pressurized source of calibration gas (e.g. a bottle of NIST-SRM gas) to the span inlet. Teledyne Analytical Instruments...
Page 65 XHAUST UTLET Attach an exhaust line to the analyzer’s EXHAUST outlet fitting. The exhaust line should be: • PTEF tubing; minimum O.D 1/4”; • A maximum of 10 meters long; • Vented outside the analyzer’s enclosure. Teledyne Analytical Instruments...
Page 66: Pneumatic Layout For Zero Scrubber/Pressurized Span Option
Internal zero/span and sample/cal valves control the flow of gas through the instrument, but because the generator and calibrator limit the flow of zero air and span gas no shutoff valves are required. See Figure 3-4 for the location of gas inlets and outlets. Teledyne Analytical Instruments...
Page 67: Figure 3-27: Pneumatic Connections - Option 50H: Zero/Span Calibration Valves
If a pressurized source is used, both the zero air supply and sample gas line MUST be vented in order to ensure that the gases input do not exceed the maximum inlet pressure of the analyzer as well as to prevent back diffusion and pressure effects. These vents should be: Teledyne Analytical Instruments...
Page 68: Pneumatic Layout For Zero Scrubber/ Ambient Span Option
Open to SAMPLE inlet (Normal Zero/Span Open to ZERO AIR scrubber State) Sample/Cal Open to ZERO/SPAN valve ZERO CAL Zero/Span Open to ZERO AIR scrubber Sample/Cal Open to ZERO/SPAN valve SPAN CAL Zero/Span Open to PRESSURE SPAN inlet Teledyne Analytical Instruments...
Page 69: Calibration Gases
In the case of CO measurements made with the GFC7001T or GFC7001TM Analyzer, it is recommended that you use a span gas with a CO concentration equal to 80-90% of the measurement range for your application.
Page 70: Startup, Functional Checks, And Initial Calibration
The analyzer’s cover must be installed to ensure that the temperatures of the GFC Wheel and absorption cell assemblies are properly controlled. If you are unfamiliar with the GFC7001T/GFC7001TM theory of operation, we recommend that you read Section 13. For information on navigating the analyzer’s software menus, see the menu trees described in Appendix A.
Page 71: Table 3-13: Possible Warning Messages At Start-Up
The instrument's A/D circuitry or one of its analog outputs is not calibrated. BENCH TEMP WARNING Optical bench temperature is outside the specified limits. The temperature inside the GFC7001T/GFC7001TM chassis is outside the BOX TEMP WARNING specified limits. Remote span calibration failed while the dynamic span feature was set to CANNOT DYN SPAN turned on.
Page 72: Functional Checks
Clears the next time successful span calibration is performed. Table 3-14 lists brief descriptions of the warning messages that may occur during start up for GFC7001T analyzers with optional second gas options or alarms installed. Table 3-14: Possible Startup Warning Messages – GFC7001T Analyzers with Options...
Page 73: Initial Calibration
Use the LOW button when calibrating for CONC1 (equivalent to RANGE1). • Use the HIGH button when calibrating for CONC2 (equivalent to RANGE2). NOTE The following procedure assumes that the instrument does not have any of the available Valve Options installed. See Section 9.3 for instructions Teledyne Analytical Instruments...
Page 74: Interferents For Co Measurements
Unit of Measure: PPM • Analog Output Reporting Range: 50 ppm • Mode Setting: SNGL While these are the default setting for the GFC7001T/GFC7001TM Analyzer, it is recommended that you verify them before proceeding with the calibration procedure, by pressing: Teledyne Analytical Instruments...
Page 75 If it is not, press ENTR. ILUTION ATIO If the dilution ratio option is enabled on your GFC7001T/GFC7001TM Analyzer and your application involves diluting the sample gas before it enters the analyzer, set the dilution ratio as follows: Teledyne Analytical Instruments...
Page 76 Getting StartedTeledyne API – Model T300/T300M CO Analyzer CO S ONCENTRATION Set the expected CO pan gas concentration. This should be 80-90% of range of concentration range for which the analyzer’s analog output range is set. Teledyne Analytical Instruments...
Page 77 Getting StartedTeledyne API – Model T300/T300M CO Analyzer ALIBRATION To perform the zero/span calibration procedure, press: Teledyne Analytical Instruments...
Page 78: Figure 3-29: Zero/Span Calibration Procedure
Getting StartedTeledyne API – Model T300/T300M CO Analyzer Figure 3-28: Zero/Span Calibration Procedure Teledyne Analytical Instruments...
Page 79: Co Sensor Calibration Procedure
Getting StartedTeledyne API – Model T300/T300M CO Analyzer 3.4.4.3. O SENSOR CALIBRATION PROCEDURE If your GFC7001T/GFC7001TM is equipped with the optional O sensor, this sensor should be calibrated during installation of the instrument. See Section 9.7.1 for instructions. Refer to any addenda that may accompany this instrument for custom configuration such as an optional O sensor.
Page 80 Getting StartedTeledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 81: Part Ii Operating Instructions
Part II Opeerating InstructionsTeledyne API – Model T300/T300M CO Analyzer PART II OPERATING INSTRUCTIONS Teledyne Analytical Instruments...
Page 82 Part II Opeerating InstructionsTeledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 83: Overview Of Operating Modes
24-hour clock to 25:00:00. Once you adjust the setting to an allowable value, the ENTR button will re-appear. The GFC7001T/GFC7001TM software has a variety of operating modes. Most commonly, the analyzer will be operating in Sample Mode. In this mode a continuous...
Page 84: Sample Mode
(refer to Section 12.1.2). They can also be recorded in one of the DAS channels (refer to Section 7.2) for data analysis. To view the test functions, press one of the <TST TST> buttons repeatedly in either direction. Teledyne Analytical Instruments...
Page 85: Figure 4-2: Viewing Gfc7001T/Gfc7001Tm Test Functions
OverviewTeledyne API – Model T300/T300M CO AnalyzerTeledyne API – Model T300/T300M CO Analyzer Figure 4-2: Viewing GFC7001T/GFC7001TM Test Functions MPORTANT MPACT ON EADING OR A value of “XXXX” displayed for any of the TEST functions indicates an out-of-range reading or the analyzer’s inability to calculate it. All pressure measurements are represented in terms of absolute pressure.
Page 86: Warning Messages
Only appears when the optional CO sensor is installed. Only available on the GFC7001T. 4.1.2. WARNING MESSAGES The most common instrument failures will be reported as a warning on the analyzer’s front panel and through the COMM ports. Section 12.1.1 explains how to use these messages to troubleshoot problems.
Page 87 WHEEL TEMP WARNING The Gas Filter Correlation Wheel temperature is outside the specified limits. Alarm warnings only present when optional alarm package is activated. Only enabled when the optional O Sensor is installed. To view and clear warning messages: Teledyne Analytical Instruments...
Page 88: Calibration Mode
Viewing and Clearing GFC7001T/GFC7001TM WARNING Messages 4.2. CALIBRATION MODE Pressing the CAL button switches the GFC7001T/GFC7001TM into calibration mode. In this mode the user can calibrate the instrument with the use of calibrated zero or span gases. This mode is also used to check the current calibration status of the instrument.
Page 89: Setup Mode
Analog outputs. PASS Calibration Password Security Turns the calibration password feature ON/OFF. Internal Clock Configuration Used to Set or adjust the instrument’s internal clock. MORE Advanced SETUP features This button accesses the instruments secondary setup menu. Table 6-5 Teledyne Analytical Instruments...
Page 90: Secondary Setup Menu (Setup>More)
Any changes made to a variable during the SETUP procedures are not acknowledged by the instrument until the ENTR button is pressed. If the EXIT button is pressed before the ENTR button, the analyzer will beep, alerting the user that the newly entered value has not been accepted. Teledyne Analytical Instruments...
Page 91: Setup Menu
Special instrument or software features or installed options may also be listed here. • Use this information to identify the software and hardware installed in your GFC7001T/GFC7001TM Analyzer when contacting customer service. To access the configuration table, press: SAMPLE RANGE=50.00 PPM CO= XX.XX...
Page 92: Setup Acal: Automatic Calibration
A menu tree showing the ACAL menu’s entire structure can be found in Appendix A-1 of this manual. Instructions for using the ACAL feature are located in the Section 9.4 of this manual along with all other information related to calibrating the GFC7001T/GFC7001TM Analyzer. 5.3. SETUP DAS: INTERNAL DATA ACQUISITION SYSTEM Use the SETUP>DAS menu to capture and record data.
Page 93: Physical Range Vs Analog Output Reporting Ranges
5.4.2. PHYSICAL RANGE VS ANALOG OUTPUT REPORTING RANGES Functionally, the GFC7001T Family of CO Analyzers have one hardware PHYSICAL RANGE that is capable of determining CO concentrations between across a very wide array of values. Teledyne Analytical Instruments...
Page 94: Reporting Range Modes: Single, Dual, Auto Ranges
GFC7001T is being used to measure an expected concentration of typically less than 50 ppm CO, the full scale of expected values is only 4% of the instrument’s full 1000 ppm measurement range.
Page 95 Upper span limit setting for the individual range modes are shared. Resetting the span limit in one mode also resets the span limit for the corresponding range in the other modes as follows: SNGL DUAL AUTO Range Range1 Low Range Range2 High Range Teledyne Analytical Instruments...
Page 96: Single Range Mode (Sngl)
(e.g. 0-5 VDC, 0-10 VDC, etc; see Section 5.9.3.1) To select SNGL range mode and to set the upper limit of the range, press: Teledyne Analytical Instruments...
Page 97: Dual Range Mode (Dual)
The concentration currently being displayed is identified as follows: C1= LOW (or A1) and C2 = HIGH (or A2). Teledyne Analytical Instruments...
Page 98 In DUAL range mode the LOW and HIGH ranges have separate slopes and offsets for computing CO concentrations. The two ranges must be independently calibrated. To set the upper range limit for each independent reporting range, press: Teledyne Analytical Instruments...
Page 99: Auto Range Mode (Auto)
RANGE1: The LOW range setting for all analog outputs. • RANGE2: The HIGH range setting for all analog outputs. The high/low range status is also reported through the external, digital status bits (See Section 3.3.1.4). To set individual ranges press the following control button sequence. Teledyne Analytical Instruments...
Page 100 SetupTeledyne API – Model T300/T300M CO Analyzer Teledyne Analytical Instruments...
Page 101: Range Units
SetupTeledyne API – Model T300/T300M CO Analyzer 5.4.4. RANGE UNITS The GFC7001T/GFC7001TM can display concentrations in parts per million (10 mols per mol, PPM) or milligrams per cubic meter (mg/m , MG). Changing units affects all of the display, COMM port and DAS values for all reporting ranges regardless of the analyzer’s range mode.
Page 102: Dilution Ratio (Option)
3. Set the dilution factor as a gain (e.g., a value of 20 means 20 parts diluent and 1 part of sample gas): 4. Calibrate the analyzer. • Make sure that the calibration span gas is either supplied through the same dilution system as the sample gas or has an appropriately lower actual concentration. Teledyne Analytical Instruments...
Page 103: Setup Pass: Password Protection
All functions of the main menu (top level, or Primary, menu) Access to Primary and Secondary SETUP Menus when PASSWORD is Configuration/Maintenance enabled Configuration/Maintenance Access to Secondary SETUP Submenus VARS and DIAG whether PASSWORD is enabled or disabled. To enable or disable passwords, press: Teledyne Analytical Instruments...
Page 104 If the password feature is enabled, then when entering either Calibration or Setup Mode, the default password displayed will be 000, and the new password must be input. Example: If all passwords are enabled, the following control button sequence would be required to enter the SETUP menu: Teledyne Analytical Instruments...
Page 105 DIAG menus, even if passwords are disabled. It will display the default password (818) upon entering these menus. The user only has to press ENTR to access the password-protected menus but does not have to enter the required number code. Teledyne Analytical Instruments...
Page 106: Setup
CLOCK AND ADJUSTING SPEED 5.6.1.1. SETTING THE INTERNAL CLOCK’S TIME AND DAY The GFC7001T/GFC7001TM has a time of day clock that supports the DURATION step of the automatic calibration (ACAL) sequence feature, time of day TEST function, and time stamps on for the DAS feature and most COMM port messages.
Page 107 SetupTeledyne API – Model T300/T300M CO Analyzer Teledyne Analytical Instruments...
Page 108: Setup Comm: Communications Ports
• view/set the baud rate (Section 6.2.2) • test the connections of the com ports (Section 6.2.3). Configuring COM1 or COM2 requires setting the DCE DTE switch on the rear panel. Section 6.1 provides DCE DTE information. Teledyne Analytical Instruments...
Page 109: Setup Vars: Variables Setup And Definition
VARS menu. The following table lists all variables that are available within the 818 password protected level. See Appendix A-2 for a detailed listing of all of the GFC7001T/ GFC7001TM variables that are accessible through the remote interface.
Page 110: Setup Diag: Diagnostics Functions
A series of diagnostic tools is grouped together under the SETUP MORE DIAG menu, as these parameters are dependent on firmware revision (see Appendix A). These tools can be used in a variety of troubleshooting and diagnostic procedures and are Teledyne Analytical Instruments...
Page 111: Table 5-4: Diagnostic Mode (Diag) Functions
9.6.3 CALIBRATION CALIBRATION TEST CHAN Selects one of the available test channel signals to DIAG TEST 5.9.8 and OUTPUT output over the A4 analog output channel. CHAN OUTPUT 12.5.8.2 These settings are retained after exiting DIAG mode. Teledyne Analytical Instruments...
Page 112 SetupTeledyne API – Model T300/T300M CO Analyzer To access the DIAG functions press the following buttons: Teledyne Analytical Instruments...
Page 113: Signal I/O
Any changes of signal I/O settings will remain in effect only until the signal I/O menu is exited. Exceptions are the ozone generator override and the flow sensor calibration, which remain as entered when exiting. Access the SIGNAL I/O test mode from the DIAG Menu: Teledyne Analytical Instruments...
Page 114: Analog Output
12.5.8.2). Access the Analog Output Step Test from the DIAG Menu as follows: 5.9.3. ANALOG I/O CONFIGURATION The GFC7001T/GFC7001TM Analyzer comes equipped with four analog outputs. • The first two outputs (A1 & A2) carry analog signals that represent the currently measured concentration of CO (see Section 5.4.1).
Page 115: Table 5-5: Diag - Analog I/O Functions
For each of 8 external analog input channels, shows the gain, offset, engineering units, and whether the channel is to show up as a Test function. XIN8 Any changes made to RANGE or REC_OFS require recalibration of this output. Teledyne Analytical Instruments...
Page 116: Figure 5-3: Accessing The Analog I/O Configuration Submenus
SetupTeledyne API – Model T300/T300M CO Analyzer To access the ANALOG I/O CONFIGURATION submenu, press: Figure 5-3: Accessing the Analog I/O Configuration Submenus Teledyne Analytical Instruments...
Page 117: Analog Output Voltage / Current Range Selection
The default offset for all current ranges is 0 mA. • Current outputs are available only on A1-A3. To change the output type and range, select the ANALOG I/O CONFIGURATION submenu from the DIAG Menu (see Figure 5-3) then press: Teledyne Analytical Instruments...
Page 118 SetupTeledyne API – Model T300/T300M CO Analyzer Teledyne Analytical Instruments...
Page 119: Analog Output Calibration
The outputs can also be calibrated individually, but this requires the AUTOCAL feature be disabled. 5.9.3.3. ENABLING OR DISABLING THE AUTOCAL FOR AN INDIVIDUAL ANALOG OUTPUT To enable or disable the AutoCal feature for an individual analog output, elect the ANALOG I/O CONFIGURATION submenu (see Figure 5-3) then press: Teledyne Analytical Instruments...
Page 120: Automatic Calibration Of The Analog Outputs
SetupTeledyne API – Model T300/T300M CO Analyzer 5.9.3.4. AUTOMATIC CALIBRATION OF THE ANALOG OUTPUTS To calibrate the outputs as a group with the AOUTS CALIBRATION command, select the ANALOG I/O CONFIGURATION submenu (see Figure 5-3) then press: Teledyne Analytical Instruments...
Page 121 MPORTANT MPACT ON EADINGS OR Manual calibration should be used for any analog output set for a 0.1V output range or in cases where the outputs must be closely matched to the characteristics of the recording device. Teledyne Analytical Instruments...
Page 122: Individual Calibration Of The Analog Outputs
SetupTeledyne API – Model T300/T300M CO Analyzer 5.9.3.5. INDIVIDUAL CALIBRATION OF THE ANALOG OUTPUTS To use the AUTO CAL feature to initiate an automatic calibration for an individual analog output, select the ANALOG I/O CONFIGURATION submenu (see Figure 5-3) then press: Teledyne Analytical Instruments...
Page 123: Manual Calibration Of The Analog Outputs Configured For Voltage Ranges
SPAN VOLTAGE TOLERANCE (1 count) 0.1 VDC ±0.0005V 90 mV ±0.001V 0.02 mV 1 VDC ±0.001V 900 mV ±0.001V 0.24 mV 5 VDC ±0.002V 4500 mV ±0.003V 1.22 mV 10 VDC ±0.004V 4500 mV ±0.006V 2.44 mV Teledyne Analytical Instruments...
Page 124 SetupTeledyne API – Model T300/T300M CO Analyzer To adjust the signal levels of an analog output channel manually, select the ANALOG I/O CONFIGURATION submenu (see Figure 5-3) then press: Teledyne Analytical Instruments...
Page 125: Manual Adjustment Of Current Loop Output Span And Offset
See Figure 3-9 for pin assignments and diagram of the analog output connector. Figure 5-5: Setup for Checking / Calibration Current Output Signal Levels Using an Ammeter CAUTION ENERAL AFETY AZARD Do not exceed 60 V peak voltage between current loop outputs and instrument ground. Teledyne Analytical Instruments...
Page 126 SetupTeledyne API – Model T300/T300M CO Analyzer To adjust the zero and span signal levels of the current outputs, select the ANALOG I/O CONFIGURATION submenu (see Figure 5-3) then press: Teledyne Analytical Instruments...
Page 127: Figure 5-6: Alternative Setup Using 250Ω Resistor For Checking Current Output Signal Levels
In this case, follow the procedure above but adjust the output for the following values: Table 5-8: Current Loop Output Check Voltage across Resistor for Voltage across % FS 2-20 mA Resistor for 4-20 mA 500 mVDC 1000 mVDC 5000 mVDC 5000 mVDC Teledyne Analytical Instruments...
Page 128: Turning An Analog Output Over-Range Feature On/Off
5.9.3.8. TURNING AN ANALOG OUTPUT OVER-RANGE FEATURE ON/OFF In its default configuration, a ± 5% over-range is available on each of the GFC7001T/GFC7001TM Analyzer’s analog outputs. This over-range can be disabled if your recording device is sensitive to excess voltage or current.
Page 129: Adding A Recorder Offset To An Analog Output
Some analog signal recorders require that the zero signal is significantly different from the baseline of the recorder in order to record slightly negative readings from noise around the zero point. This can be achieved in the GFC7001T/GFC7001TM by defining a zero offset, a small voltage (e.g., 10% of span).
Page 130: Ain Calibration
SetupTeledyne API – Model T300/T300M CO Analyzer 5.9.3.10. AIN CALIBRATION This is the submenu to conduct a calibration of the GFC7001T/GFC7001TM Analyzer’s analog inputs. This calibration should only be necessary after major repair such as a replacement of CPU, motherboard or power supplies.
Page 131: Analog Inputs (Xin1
This signal is generated by circuitry on the pre- amplifier board itself and tests the filtering and amplification functions of that assembly along with the A/D converter on the motherboard. It does not test the PMT itself. (See also Section 12.5.7.2). Teledyne Analytical Instruments...
Page 132: Dark Calibration
For details see Section 9.6.3. 5.9.8. TEST CHAN OUTPUT When activated, output channel A4 can be used in the standard configuration to report one of the test functions viewable from the SAMPLE mode display. (See also Section 12.5.8.2). Teledyne Analytical Instruments...
Page 133: Selecting A Test Channel Function For Output A4
SetupTeledyne API – Model T300/T300M CO Analyzer 5.9.8.1. SELECTING A TEST CHANNEL FUNCTION FOR OUTPUT A4 The test functions available to be reported are listed in Table 5-9: Table 5-9: Test Channels Functions available on the GFC7001T/GFC7001TM’s Analog Output TEST CHANNEL DESCRIPTION...
Page 134: Setup More
5.10. SETUP MORE ALRM (OPTION): USING THE GAS CONCENTRATION ALARMS The GFC7001T/GFC7001TM includes two CO concentration alarms if OPT 61 is installed on your instrument. Each alarm has a user settable limit, and is associated with Teledyne Analytical Instruments...
Page 135: Setting The Gfc7001T Concentration Alarm Limits
CAL or CALS button is pressed prior to introducing span gas into the analyzer. 5.10.1. SETTING THE GFC7001T CONCENTRATION ALARM LIMITS To enable either of the CO concentration alarms and set the limit points, press: SAMPLE RANGE=50.0 PPM...
Page 136 SetupTeledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 137: Communications Setup And Operation
Either of the analyzer’s serial ports (RS232 or COM2 on rear panel) can be configured to operate in a number of different modes, which are described in Table 6-1. As modes are selected, the analyzer sums the mode ID numbers and displays this combined Teledyne Analytical Instruments...
Page 138: Table 6-1: Comm Port Communication Modes
Enables CTS/RTS style hardwired transmission handshaking. This style of data HARDWARE transmission handshaking is commonly used with modems or terminal emulation HANDSHAKE protocols as well as by Teledyne Instrument’s APICOM software. HARDWARE Disables the HARDWARE FIFO (First In – First Out). When FIFO is enabled it improves FIFO data transfer rate for that COM port.
Page 139: Com Port Baud Rate
6.2.2. COM PORT BAUD RATE To select the baud rate of either COM Port, go to SETUP>MORE>COMM and select either COM1 or COM2 as follows (use COM2 to view/match your personal computer baud rate when using the USB port, Section 6.6): Teledyne Analytical Instruments...
Page 140: Com Port Testing
This test sends a string of 256 ‘w’ characters to the selected COM port. While the test is running, the red LED labeled TX for that COM port on the instrument’s rear panel analyzer should flicker. To initiate the test, access the COMMUNICATIONS Menu (SETUP>MORE>COMM), then press: Teledyne Analytical Instruments...
Page 141: 141
LEDs should be on. • If the lights are not lit, use small switch on the rear panel to switch it between DTE and DCE modes. Teledyne Analytical Instruments...
Page 142: Ethernet
Instrument and Gateway IP addresses and Subnet Mask to the desired settings. Alternatively, from the computer, enter the same information through an application such as HyperTerminal. Table 6-3 shows the default Ethernet configuration settings. Teledyne Analytical Instruments...
Page 143: Table 6-3: Lan/Internet Default Configuration Properties
The name by which your analyzer will appear when [initially blank] HOST NAME addressed from other computers on the LAN or via the Internet. To change, see Section 6.5.3. Do not change the setting for this property unless instructed to by Teledyne Customer Service personnel. Teledyne Analytical Instruments...
Page 144: Configuring Ethernet Communication Using Dynamic Host Configuration Protocol (Dhcp)
EDIT EXIT The PORT number must remain at 3000. Do not change this setting unless instructed to by Pressing EXIT from Teledyne Instruments Customer Service personnel. any of the above display menus causes the Ethernet option to reinitialize SETUP X.X...
Page 145: Changing The Analyzer's Hostname
COMM – LAN / Internet Automatic Configuration (DHCP) 6.5.3. CHANGING THE ANALYZER’S HOSTNAME The HOSTNAME is the name by which the analyzer appears on your network. The default name for all Teledyne’s GFC7001T analyzers is GFC7001T. To change this Teledyne Analytical Instruments...
Page 146 Communications Setup and OperationTeledyne API – Model T300/T300M CO Analyzer name (particularly if you have more than one GFC7001T/GFC7001TM Analyzer on your network), press: BUTTON FUNCTION <CH Moves the cursor one character to the left. CH> Moves the cursor one character to the right.
Page 147: Usb Port (Option) For Remote Access
Communications Setup and OperationTeledyne API – Model T300/T300M CO Analyzer 6.6. USB PORT (OPTION) FOR REMOTE ACCESS The analyzer can be operated through a personal computer by downloading the Teledyne USB driver and directly connecting their respective USB ports. 1. Install the Teledyne T-Series USB driver on your computer, downloadable from the...
Page 148 APIcom when configuring a new instrument. See the APIcom manual (PN 07463) for more details. USB configuration requires that the baud rates of the instrument and • Note the PC match; check the PC baud rate and change if needed. Teledyne Analytical Instruments...
Page 149 Communications Setup and OperationTeledyne API – Model T300/T300M CO Analyzer Using the USB port disallows use of the rear panel COM2 port except • for multidrop communication. Teledyne Analytical Instruments...
Page 150 Communications Setup and OperationTeledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 151: Data Acquisition System (Das) And Apicom
The DAS of the GFC7001T/GFC7001TM can store up to about one million data points, which can, depending on individual configurations, cover days, weeks or months of valuable measurements. The data is stored in non-volatile memory and is retained even when the instrument is powered off.
Page 152: Das Structure
One triggering event is selected. • Up to 50 data parameters, which can be the shared between channels. • Several other properties that define the structure of the channel and allow the user to make operational decisions regarding the channel. Teledyne Analytical Instruments...
Page 153: Default Das Channels
The CALDAT channel collects data based on events (e.g. a calibration operation) rather than a timed interval and therefore does not represent any specific length of time. As with all data channels, a date and time stamp is recorded for every logged data point. Teledyne Analytical Instruments...
Page 154 EADINGS OR Sending a DAS configuration to the analyzer through its COM ports will replace the existing configuration and will delete all stored data. Back up any existing data and the DAS configuration before uploading new settings. Teledyne Analytical Instruments...
Page 155: Figure 7-1: Default Das Channel Setup
Channel Enabled: ON Cal Hold OFF: OFF Name: TEMP Event: EXITSP BNTEMP Parameters: 3 BOXTEMP PHTDRV Report Period: 000:06:00 No. of Records: 400 RS-232 Report: OFF Channel Enabled: ON Cal Hold OFF: OFF Figure 7-1: Default DAS Channel Setup Teledyne Analytical Instruments...
Page 156: Viewing Das Channels And Individual Records
SETUP X.X 101:19:45 SLOPE1=0.997 PV10 PREV NEXT PRM> EXIT SETUP X.X 102:04:55 SLOPE1=1.002 SETUP X.X 101:19:45 OFFSET=1.3 PV10 PREV NX10 NEXT <PRM PRM> EXIT PV10 PREV <PRM PRM> EXIT Continue pressing NEXT to view remaining DAS channels Teledyne Analytical Instruments...
Page 157: Editing Das Channels
For example, the display line: 0) CONC: ATIMER, 1, 800 Translates to the following configuration: Channel No.: 0 NAME: CONC TRIGGER EVENT: ATIMER PARAMETERS: One parameter is included in this channel EVENT: This channel is set up to store 800 records. Teledyne Analytical Instruments...
Page 158: Editing Das Data Channel Names
DAS and APICOMTeledyne API – Model T300/T300M CO Analyzer 7.1.4.1. EDITING DAS DATA CHANNEL NAMES To edit the name of a DAS data channel, follow the instruction shown in Section 7.1.4.1, then press: Teledyne Analytical Instruments...
Page 159: Editing Das Triggering Events
WTEMPW (GFC Wheel temperature warning). This is helpful for troubleshooting by monitoring when a particular warning occurrs. To edit the list of data parameters associated with a specific data channel, follow the instruction shown in Section 7.1.4 then press: Teledyne Analytical Instruments...
Page 160: Editing Das Parameters
DAS does not keep track of the unit (e.g., PPM, PPB, etc.) of each concentration value and DAS data files may contain concentrations in more than one type of unit if the unit was changed during data acquisition. Teledyne Analytical Instruments...
Page 161: Table 7-3: Das Data Parameter Functions
Users can specify up to 50 parameters per data channel (the GFC7001T/GFC7001TM provides about 40 parameters). However, the number of parameters and channels is ultimately limited by available memory.
Page 162 To modify, add or delete a parameter, follow the instruction shown in Section 7.1.4 then press: Note When the STORE NUM SAMPLES feature is turned on, the instrument will store how many measurements were used to compute the AVG, SDEV, MIN or MAX value but not the actual measurements themselves. Teledyne Analytical Instruments...
Page 163: Sample Period And Report Period
Report Period may be set from the front panel. If the INST sample mode is selected the instrument stores and reports an instantaneous reading of the selected parameter at the end of the chosen report period. To define the REPORT PERIOD, follow the instruction shown in Section 7.1.4 then press: Teledyne Analytical Instruments...
Page 164 REPORT PERIOD PERIOD, only the sample readings taken since the instrument was turned back on will be included in any AVG, SDEV, MIN or MAX calculation. Also, the STORE NUM SAMPLES feature will report the number of sample readings taken since the instrument was restarted. Teledyne Analytical Instruments...
Page 165: Number Of Records
DAS script or calculate the number of records using the DAS or APICOM manuals. To set the NUMBER OF RECORDS, follow the instruction shown in Section 7.1.4 then press: Teledyne Analytical Instruments...
Page 166: Report Function
The COMPACT DATA REPORT generally cannot be accessed from the standard DAS front panel menu, but is available via the instrument’s communication ports by using APICOM or the analyzer’s standard serial data protocol. Teledyne Analytical Instruments...
Page 167: The Starting Date Feature
APICOM or the analyzer’s standard serial data protocol. 7.1.10. DISABLING/ENABLING DATA CHANNELS Data channels can be temporarily disabled, which can reduce the read/write wear on the Disk-on-Module. To disable a data channel, follow the instruction shown in Section 7.1.4 then press: Teledyne Analytical Instruments...
Page 168: Holdoff Feature
To set the length of the DAS_HOLDOFF period, go to the SETUP>MORE>VARS menu (Section 5.8) and EDIT the “0) DAS_HOLD_OFF…” parameter. To enable or disable the HOLDOFF feature for an individual channel, follow the instruction shown in Section 7.1.4 then press: Teledyne Analytical Instruments...
Page 169: Remote Das Configuration
Figure 7-2 shows examples of APICOM’s main interface, which emulates the look and functionality of the instrument’s actual front panel. Figure 7-3 shows an example of APICOM being used to remotely configure the DAS feature. The APICOM user manual (Teledyne P/N 039450000) is included in the APICOM installation file,...
Page 170: Figure 7-3: Apicom User Interface For Configuring The Das
DAS data collection), it is conveniently uploaded to the instrument and can be stored on a computer for later review, alteration or documentation and archival. Refer to the APICOM manual for details on these procedures. The APICOM user manual (Teledyne P/N 039450000) is included in the APICOM installation file, which can be downloaded at http://www.teledyne-api.com/manuals/.
Page 171: Das Configuration Using Terminal Emulation Programs
DAS configuration. Backup of data and the original DAS configuration is advised before attempting any DAS changes. Refer to Section 8.2.1 for details on remote access to and from the GFC7001T/GFC7001TM Analyzer via the instrument’s COMM ports. Teledyne Analytical Instruments...
Page 172 DAS and APICOMTeledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 173: Remote Operation
Ethernet. Running APICOM, a user can: • Establish a link from a remote location to the GFC7001T through direct cable connection via RS-232 modem or Ethernet. • View the instrument’s front panel and remotely access all functions that could be accessed manually on the instrument.
Page 174: Remote Control Via A Terminal Emulation Program
Press ? <CR> or refer to Appendix A-6 for a list of available command designators. is a carriage return. All commands must be terminated by a carriage return <CR> (usually achieved by pressing the ENTER button on a computer). Teledyne Analytical Instruments...
Page 175: Data Types
Remote OperationTeledyne API – Model T300/T300M CO Analyzer Table 8-2: Teledyne’s Serial I/O Command Types COMMAND COMMAND TYPE Calibration Diagnostic Logon Test measurement Variable Warning 8.2.1.3. DATA TYPES Data types consist of integers, hexadecimal integers, floating-point numbers, Boolean expressions and text strings.
Page 176: Status Reporting
• The DTE-DCE is in the DCE position. • The GFC7001T/GFC7001TM COMM port is set for a baud rate that is compatible with the modem, • The modem is designed to operate with an 8-bit word length with one stop bit.
Page 177 The default setting for this feature is: AT Y0 &D0 &H0 &I0 S0=2 &B0 &N6 &M0 E0 Q1 &W0 This string can be altered to match your modem’s initialization and can be up to 100 characters long. To change this setting press: Teledyne Analytical Instruments...
Page 178 Remote OperationTeledyne API – Model T300/T300M CO Analyzer To initialize the modem press: Teledyne Analytical Instruments...
Page 179: Password Security For Serial Remote Communications
8.4. PASSWORD SECURITY FOR SERIAL REMOTE COMMUNICATIONS In order to provide security for remote access of the GFC7001T/GFC7001TM, a LOGON feature can be enabled to require a password before the instrument will accept commands. This is done by turning on the SECURITY MODE (Mode 4, Table 6-1).
Page 180 Remote OperationTeledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 181: Calibration Procedures
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer CALIBRATION PROCEDURES This section describes the calibration procedures for the GFC7001T/GFC7001TM. All of the methods described in this section can be initiated and controlled through the COM ports. MPORTANT MPACT ON...
Page 182: Zero Air
For the GFC7001T/GFC7001TM zero air should contain less than 25 ppb of CO and other major interfering gases such as CO and Water Vapor. It should have a dew point of -5°C or less.
Page 183: Data Recording Devices
9.1.2. DATA RECORDING DEVICES A strip chart recorder, data acquisition system or digital data acquisition system should be used to record data from the serial or analog outputs of the GFC7001T/GFC7001TM. • If analog readings are used, the response of the recording system should be checked against a NIST traceable voltage source or meter.
Page 184: Figure 9-1: Pneumatic Connections - Basic Configuration - Using Bottled Span Gas
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer Figure 9-1: Pneumatic Connections – Basic Configuration – Using Bottled Span Gas Figure 9-2: Pneumatic Connections – Basic Configuration – Using Gas Dilution Calibrator Teledyne Analytical Instruments...
Page 185: Performing A Basic Manual Calibration Check
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.2.2. PERFORMING A BASIC MANUAL CALIBRATION CHECK Teledyne Analytical Instruments...
Page 186: Performing A Basic Manual Calibration
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.2.3. PERFORMING A BASIC MANUAL CALIBRATION The following section describes the basic method for manually calibrating the GFC7001T/GFC7001TM. If the analyzer’s reporting range is set for the AUTO range mode, a step will appear for selecting which range is to be calibrated (LOW or HIGH).
Page 187 Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer MPORTANT MPACT ON EADINGS OR For this Initial Calibration it is important to independently verify the PRECISE CO Concentration Value of the SPAN gas. If the source of the Span Gas is from a Calibrated Bottle, use the exact concentration value printed on the bottle.
Page 188: Zero/Span Point Calibration Procedure
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.2.3.2. ZERO/SPAN POINT CALIBRATION PROCEDURE Teledyne Analytical Instruments...
Page 189: Manual Calibration With Zero/Span Valves
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.3. MANUAL CALIBRATION WITH ZERO/SPAN VALVES There are a variety of valve options available on the GFC7001T/GFC7001TM for handling calibration gases (see Table 1-1 for descriptions of each). Generally performing calibration checks and zero/span point calibrations on analyzers with these options installed is similar to the methods discussed in the previous sections of this section.
Page 190: Figure 9-4: Pneumatic Connections - Option 50B: Ambient Zero/Pressurized Span Calibration Valves
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer Figure 9-4: Pneumatic Connections – Option 50B: Ambient Zero/Pressurized Span Calibration Valves Figure 9-5: Pneumatic Connections – Option 50H: Zero/Span Calibration Valves Teledyne Analytical Instruments...
Page 191: Figure 9-6: Pneumatic Connections - Option 50E: Zero/Span Calibration Valves
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer Figure 9-6: Pneumatic Connections – Option 50E: Zero/Span Calibration Valves Teledyne Analytical Instruments...
Page 192: Manual Calibration Checks With Valve Options Installed
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.3.2. MANUAL CALIBRATION CHECKS WITH VALVE OPTIONS INSTALLED Teledyne Analytical Instruments...
Page 193: Manual Calibration Using Valve Options
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.3.3. MANUAL CALIBRATION USING VALVE OPTIONS The following section describes the basic method for manually calibrating the GFC7001T/GFC7001TM Analyzer. If the analyzer’s reporting range is set for the DUAL or AUTO range modes, a step will appear for selecting which range is to be calibrated (LOW or HIGH).
Page 194: Zero/Span Point Calibration Procedure
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer MPORTANT MPACT ON EADINGS OR For this Initial Calibration it is important to independently verify the PRECISE CO Concentration Value of the SPAN gas. If the source of the Span Gas is from a Calibrated Bottle, use the exact concentration value printed on the bottle.
Page 195 Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer Teledyne Analytical Instruments...
Page 196: Use Of Zero/Span Valve With Remote Contact Closure
If contact closures are being used in conjunction with the analyzer’s AutoCal (see Section 9.4) feature and the AutoCal attribute “CALIBRATE” is enabled, the GFC7001T/GFC7001TM will not recalibrate the analyzer until the contact is opened. At this point, the new calibration values will be recorded before the instrument returns to Sample Mode.
Page 197: Table 9-3: Autocal Attribute Setup Parameters
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer For each mode, there are seven parameters that control operational details of the SEQUENCE (see Table 9-3). Table 9-3: AutoCal Attribute Setup Parameters ATTRIBUTE ACTION TIMER ENABLED Turns on the Sequence timer.
Page 198: Table 9-4: Example Autocal Sequence
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer The following example sets sequence #2 to do a zero-span calibration every other day starting at 2:15 PM on September 4, 2008, lasting 15 minutes, without calibration. This will start 1/2 hour later each iteration.
Page 199: Setup
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.4.1. SETUP ACAL: PROGRAMMING AND AUTO CAL SEQUENCE Note If at any time an illegal entry is selected, (for example: Delta Days > 366) the ENTR label will disappear from the control button.
Page 200 Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer CONTINUED FROM PREVIOUS PAGE - STARTING DATE SETUP X.X STARTING DATE: 04–SEP–08 <SET SET> EDIT EXIT SETUP X.X STARTING TIME:00:00 <SET SET> EDIT EXIT Toggle buttons to set time: SETUP X.X...
Page 201: Autocal With Auto Or Dual Reporting Ranges Modes Selected
Menu. 9.4.1.1. AUTOCAL WITH AUTO OR DUAL REPORTING RANGES MODES SELECTED If the GFC7001T/GFC7001TM Analyzer is set for either the Dual or Auto reporting range modes, the following three steps will appear at the beginning of the AutoCal setup routine: SETUP X.X...
Page 202: Co Calibration Quality
OFFS -0.500 0.000 0.500 These values should not be significantly different from the values recorded on the Teledyne Final Test and Validation Data Sheet that was shipped with your instrument. Section 11 If they are, refer to the troubleshooting The default DAS configuration records all calibration values in channel CALDAT as well as all calibration check (zero and span) values in its internal memory.
Page 203: Calibration Of The Gfc7001T/Gfc7001Tm Electronic Subsystems
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.6. CALIBRATION OF THE GFC7001T/GFC7001TM ELECTRONIC SUBSYSTEMS 9.6.1. DARK CALIBRATION TEST The dark calibration test interrupts the signal path between the IR photo-detector and the remainder of the sync/demod board circuitry. This allows the instrument to compensate for any voltage levels inherent in the sync/demod circuitry that might effect the calculation of CO concentration.
Page 204: Pressure Calibration
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.6.2. PRESSURE CALIBRATION A sensor at the sample chamber outlet continuously measures the pressure of the sample gas. These data are used to compensate the final CO concentration calculation for changes in atmospheric pressure and is stored in the CPU’s memory as the test function PRES (also viewable via the front panel).
Page 205: Flow Calibration
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.6.3. FLOW CALIBRATION The flow calibration allows the user to adjust the values of the sample flow rates as they are displayed on the front panel and reported through COMM ports to match the actual flow rate measured at the sample inlet.
Page 206: Calibration Of Optional Sensors
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.7. CALIBRATION OF OPTIONAL SENSORS This section provides the calibration setup and procedures for the O Sensor and the CO Sensor options. Refer to any addenda accompanying this manual for custom configuration information.
Page 207 Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer Teledyne Analytical Instruments...
Page 208: Activate O2 Sensor Stability Function
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.7.1.3. ACTIVATE O2 SENSOR STABILITY FUNCTION To change the stability test function from CO concentration to the O sensor output, press: Note Use the same procedure to reset the STB test function to CO when the O2 calibration procedure is complete.
Page 209: O2 Zero/Span Calibration
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.7.1.4. O2 ZERO/SPAN CALIBRATION To perform the zero/span calibration procedure: Teledyne Analytical Instruments...
Page 210: Co Sensor Calibration Procedure
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.7.2. CO SENSOR CALIBRATION PROCEDURE Presented here are first the setup and then the calibration steps for the CO Sensor. 9.7.2.1. CO2 PNEUMATICS CONNECTIONS The pneumatic connections for calibrating are as follows...
Page 211 Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer Teledyne Analytical Instruments...
Page 212: Activate Co2 Sensor Stability Function
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.7.2.3. ACTIVATE CO2 SENSOR STABILITY FUNCTION To change the stability test function from CO concentration to the CO sensor output, press: Note Use the same procedure to reset the STB test function to CO when the CO2 calibration procedure is complete.
Page 213: Co2 Zero/Span Calibration
Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer 9.7.2.4. CO2 ZERO/SPAN CALIBRATION To perform the zero/span calibration procedure: Teledyne Analytical Instruments...
Page 214 Calibration Procedures Teledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 215: Epa Calibration Protocol
EPA CALIBRATION PROTOCOL 10.1. CALIBRATION REQUIREMENTS If the GFC7001T is to be used for EPA SLAMS monitoring, it must be calibrated in accordance with the instructions in this section. The USEPA strongly recommends that you obtain a copy of the publication Quality Assurance Handbook for Air Pollution Measurement Systems Volume 2: Part 1, Ambient (abbreviated, Q.A.
Page 216: Calibration Equipment, Supplies, And Expendables
Either a strip chart recorder, data acquisition system, digital data acquisition system should be used to record the data from the Mode; GFC7001T RS-232 port or analog outputs. If analog readings are being used, the response of that system should be checked against a NIST referenced voltage source or meter.
Page 217: Recommended Standards For Establishing Traceability
EPA Calibration Protocol Teledyne API – Model T300/T300M CO Analyzer Table 10-1: Matrix for Calibration Equipment & Supplies ACTION IF EQUIPMENT & SPECIFICATION REFERENCE REQUIREMENTS ARE NOT SUPPLIES Compatible with output signal of analyzer; min. Recorder Return equipment to supplier...
Page 218: Calibration Frequency
EPA Calibration Protocol Teledyne API – Model T300/T300M CO Analyzer Cylinders of working gas traceable to NIST-SRMs (called EPA Protocol Calibration Gas) are also commercially available (from sources such as Scott Specialty Gases, etc.). See Table 3-12 for a list of appropriate SRMs.
Page 219: Zero And Span Checks
EPA Calibration Protocol Teledyne API – Model T300/T300M CO Analyzer weeks. Level 2 zero and span checks should be conducted at a frequency desired by the user. Definitions of these terms are given in Table 10-3. To provide for documentation and accountability of activities, a checklist should be compiled and then filled out by the field operator as each activity is completed.
Page 220: Zero/Span Check Procedures
EPA Calibration Protocol Teledyne API – Model T300/T300M CO Analyzer • Provide a decision point on invalidation of monitoring data. Items 1 and 2 are described in detail in Subsection 9.1.3 of Section 2.0.9 (Q.A. Handbook Vol II ). Item 3 is described in Subsection 9.1.4 of the same section.
Page 221: Precision Calibration
All operational adjustments to the GFC7001T should be completed prior to the calibration. The following software features must be set into the desired state before calibration.
Page 222: Data Reduction Audit
EPA Calibration Protocol Teledyne API – Model T300/T300M CO Analyzer year. Each agency must audit 25% of the reference or equivalent analyzers each quarter. If an agency operates less than four reference or equivalent analyzers, it must randomly select analyzers for reauditing so that one analyzer will be audited each calendar quarter and each analyzer will be audited at least once a year.
Page 223 ±2% of full scale. If carried out carefully, the checks described in this section will provide reasonable confidence that the GFC7001T is operating properly. Checks should be carried out at least every 3 months as the possibility of malfunction is always present.
Page 224: References
EPA Calibration Protocol Teledyne API – Model T300/T300M CO Analyzer • Failed IR detector, GFC Wheel or Sync/Demod Board • Contaminated optical bench or sample lines 10.6. REFERENCES Quality Assurance Handbook for Air Pollution Measurement Systems Volume II: Part 1 - Ambient Air Quality Monitoring Program Quality System Development - EPA- 454/R-98-004 - August 1998.
Page 225: Part Iii Technical Information
EPA Calibration Protocol Teledyne API – Model T300/T300M CO Analyzer PART III TECHNICAL INFORMATION Teledyne Analytical Instruments...
Page 226 EPA Calibration Protocol Teledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 227: Maintenance Schedule & Procedures
Risk of electrical shock. Disconnect power before performing any of the following operations that require entry into the interior of the analyzer. CAUTION UALIFIED ERSONNEL The operations outlined in this section are to be performed by qualified maintenance personnel only. Teledyne Analytical Instruments...
Page 228 MaintenanceTeledyne API – Model T300/T300M CO Analyzer This page intentionally left blank. Teledyne Analytical Instruments...
Page 229: Table 11-1: Gfc7001T/Gfc7001Tm Maintenance Schedule
MaintenanceTeledyne API – Model T300/T300M CO Analyzer Table 11-1: GFC7001T/GFC7001TM Maintenance Schedule DATE PERFORMED ITEM ACTION FREQ CHECK MANUAL REQ’D Particulate Weekly or As Replace Filter Needed Weekly or after Verify Test Record and Functions Analyze Maintenance or Repair Perform Flow...
Page 230: Table 11-2: Gfc7001T/Gfc7001Tm Test Function Record
MaintenanceTeledyne API – Model T300/T300M CO Analyzer Table 11-2: GFC7001T/GFC7001TM Test Function Record DATE RECORDED OPERATING FUNCTION MODE* STABILITY ZERO CAL CO MEAS ZERO CAL ZERO CAL MR RATIO SPAN CAL PRES SAMPLE SAMPLE PHT DRIVE AFTER WARM- SLOPE SPAN CAL...
Page 231: Predicting Failures Using The Test Functions
Increasing OFFSET Zero Cal • See MR Ratio - Zero Cal Increasing above Decreasing • See MR Ratio - Span Cal Decreasing above Increasing SLOPE Span Cal • See MR Ratio – Span Cal Increasing above Decreasing Teledyne Analytical Instruments...
Page 232: Maintenance Procedures
PTFE retaining ring, glass cover and the o-ring. To change the filter: 1. Turn OFF the analyzer to prevent drawing debris into the instrument. 2. Open the GFC7001T Analyzer’s hinged front panel and unscrew the knurled retaining ring on the filter assembly. Figure 11-1: Sample Particulate Filter Assembly 3.
Page 233: Performing Leak Checks
See Figure 3-4 for SAMPLE port location. 1. Attach the Flow Meter to the sample inlet port on the rear panel. Ensure that the inlet to the Flow Meter is at atmospheric pressure. /min ± 10%. 2. Sample flow should be 800 cm Teledyne Analytical Instruments...
Page 234: Cleaning The Optical Bench
11.3.5. CLEANING EXTERIOR SURFACES OF THE GFC7001T/GFC7001TM If necessary, the exterior surfaces of the GFC7001T/GFC7001TM can be cleaned with a clean damp cloth. Do NOT submerge any part of the instrument and do NOT use any cleaning solution.
Page 235: Troubleshooting And Service
•Use common sense when operating inside a running analyzer. 12.1. GENERAL TROUBLESHOOTING The GFC7001T/GFC7001TM Carbon Monoxide Analyzer has been designed so that problems can be rapidly detected, evaluated and repaired. During operation, it continuously performs diagnostic tests and provides the ability to evaluate its key operating parameters without disturbing monitoring operations.
Page 236: Fault Diagnosis With Warning Messages
(press to clear Warning message). The MSG button displays if there is more than one warning in queue or if you are in the TEST menu and have not yet cleared the message. The following display/touchscreen examples provide an illustration of each: Teledyne Analytical Instruments...
Page 237 Troubleshooting and ServiceTeledyne API – Model T300/T300M CO Analyzer The analyzer will also alert the user via the Serial I/O COM port(s). To view or clear the various warning messages press: Teledyne Analytical Instruments...
Page 238: Figure 12-1: Viewing And Clearing Warning Messages
Relay Board. Loose connectors/wiring Blocked sample inlet/gas line SAMPLE FLOW Sample flow rate is < 500 cm /min Dirty particulate filter WARN or > 1000 cm /min. Leak downstream of critical flow orifice Failed flow sensor/circuitry Teledyne Analytical Instruments...
Page 239: Fault Diagnosis With Test Functions
Section 13). The acceptable ranges for these test functions are listed in the “Nominal Range” column of the analyzer Final Test and Validation Data Sheet (GFC7001T, P/N 04307 and GFC7001TM, P/N 04311) shipped with the instrument. Values outside these acceptable ranges indicate a failure of one or more of the analyzer’s subsystems.
Page 240: Table 12-2: Test Functions - Indicated Failures
Table 12-1 for BENCH TEMP WARNING. WHEEL Wheel temp control improves instrument noise, stability and drift. Outside of set point or oscillating TEMP temperatures are causes for concern. See Table 12-1 for WHEEL TEMP WARNING. Teledyne Analytical Instruments...
Page 241: The Diagnostic Signal I/O Function
The following flowchart shows an example of how to use the Signal I/O menu to view the raw voltage of an input signal or to control the state of an output voltage or control signal. (See also Sections 5.9.1 and 12.5.8.1). Teledyne Analytical Instruments...
Page 242: Status Leds
12.1.4. STATUS LEDS Several color-coded light-emitting diodes (LEDs) are located inside the instrument to assist in determining if the analyzer’s CPU, I C bus and relay board, GFC Wheel and the sync/demodulator board are functioning properly. Teledyne Analytical Instruments...
Page 243: Motherboard Status Indicator (Watchdog)
If after 30 – 60 seconds neither the DS5 is flashing or no characters have been written to the front panel display then the CPU is bad and must be replaced. Motherboard CPU Status LED Figure 12-3: CPU Status Indicator Teledyne Analytical Instruments...
Page 244: Sync Demodulator Status Leds
ON or OFF JP 4 Connector/Wiring faulty (Flashes quickly) Failed/Faulty +5 VDC Power Supply (PS1) D1 – M/R Sensor Status JP4 Connector to Opto-Pickup Board D2 – Segment Sensor Status Figure 12-4: Sync/Demod Board Status LED Locations Teledyne Analytical Instruments...
Page 245: Relay Board Status Leds
Continuously ON (Watch Dog Faulty Connectors/Wiring between Motherboard, (Red) Circuit) Continuously OFF Touchscreen or Relay Board Failed/Faulty +5 VDC Power Supply (PS1) DC VOLTAGE TEST STATUS LED’s POINTS RELAY PCA PN 04135 Figure 12-5: Relay Board Status LEDs Teledyne Analytical Instruments...
Page 246: Table 12-5: Relay Board Status Led Failure Indications
Faulty +12 VDC Supply (PS2) Faulty Connectors/Wiring Voltage displayed should change. If not: Failed IR Source Faulty +12 VDC Supply (PS2) IR SOURCE IR_SOURCE CO_MEASURE Failed Relay Board Green Failed IR Photo-Detector Failed Sync/Demod Board Faulty Connectors/Wiring Teledyne Analytical Instruments...
Page 247: Gas Flow Problems
11.3.3. If this test shows the flow to be correct, check the pressure sensors as described in Section 12.5.7.6. The GFC7001T/GFC7001TM has one main gas flow path. With the IZS or zero/span valve option installed, there are several subsidiary paths but none of those are displayed on the front panel or stored by the DAS.
Page 248: Gfc7001T/Gfc7001Tm Internal Gas Flow Diagrams
Troubleshooting and ServiceTeledyne API – Model T300/T300M CO Analyzer 12.2.1. GFC7001T/GFC7001TM INTERNAL GAS FLOW DIAGRAMS Figure 12-6: GFC7001T/GFC7001TM – Basic Internal Gas Flow Figure 12-7: Internal Pneumatic Flow OPT 50A – Zero/Span Valves (OPT 50A & 50B) Teledyne Analytical Instruments...
Page 249: Figure 12-8: Internal Pneumatic Flow Opt 50B - Zero/Span/Shutoff Valves
Troubleshooting and ServiceTeledyne API – Model T300/T300M CO Analyzer Figure 12-8: Internal Pneumatic Flow OPT 50B – Zero/Span/Shutoff Valves Figure 12-9: Internal Pneumatic Flow OPT 50H – Zero/Span Valves with Internal Zero Air Scrubber Teledyne Analytical Instruments...
Page 250: Figure 12-10: Internal Pneumatic Flow Opt 50E - Zero/Span/Shutoff W/ Internal Zero Air Scrubber
Troubleshooting and ServiceTeledyne API – Model T300/T300M CO Analyzer Figure 12-10: Internal Pneumatic Flow OPT 50E – Zero/Span/Shutoff w/ Internal Zero Air Scrubber Figure 12-11: GFC7001T/GFC7001TM – Internal Pneumatics with O Sensor Option 65A Teledyne Analytical Instruments...
Page 251: Typical Sample Gas Flow Problems
Troubleshooting and ServiceTeledyne API – Model T300/T300M CO Analyzer Figure 12-12: GFC7001T/GFC7001TM – Internal Pneumatics with CO Sensor Option 67A 12.2.2. TYPICAL SAMPLE GAS FLOW PROBLEMS 12.2.2.1. FLOW IS ZERO The unit displays a SAMPLE FLOW warning message on the front panel display or the SAMPLE FLOW test function reports a zero or very low flow rate.
Page 252: High Flow
1. Bad span gas. This can cause a large error in the slope and a small error in the offset. Delivered from the factory, the GFC7001T Analyzer’s slope is within ±15% of nominal. Bad span gas will cause the analyzer to be calibrated to the wrong value.
Page 253: Non-Repeatable Zero And Span
Troubleshooting and ServiceTeledyne API – Model T300/T300M CO Analyzer 12.3.2. NON-REPEATABLE ZERO AND SPAN As stated earlier, leaks both in the GFC7001T/GFC7001TM and in the external system are a common source of unstable and non-repeatable readings. 1. Check for leaks in the pneumatic systems as described in Section 11.3.2. Don’t...
Page 254: Other Performance Problems
Individual control loops are used to maintain the set point of the absorption bench, filter wheel and IR photo-detector temperatures. If any of these temperatures are out of range or are poorly controlled, the GFC7001T/GFC7001TM will perform poorly. 12.4.1.1. BOX OR SAMPLE TEMPERATURE...
Page 255: Gfc Wheel Temperature
5. Unplug the connector labeled “Wheel”, and measure the resistance of the thermistor. The resistance near the 68°C set point is ~5.7k ohms. 12.4.1.4. IR PHOTO-DETECTOR TEC TEMPERATURE If the PHT DRIVE test parameter described in Table 11-3 is out of range there are four possible causes of failure. Teledyne Analytical Instruments...
Page 256: Excessive Noise
• If PHT DRIVE is > 4800 mV there is a malfunction. • The +5 and ±15 VDC voltages in the GFC7001T/GFC7001TM are provided by switching power supplies. • Switch mode supplies create DC outputs by switching the input AC waveform at high frequencies.
Page 257: Subsystem Checkout
Table 12-6: DC Power Test Point and Wiring Color Codes NAME TEST POINT# TP AND WIRE COLOR Dgnd Black Agnd Green +15V Blue -15V Yellow +12R Purple +12V Orange Teledyne Analytical Instruments...
Page 258: I 2 C Bus
CPU goes through its initialization process. 12.5.6. RELAY BOARD The relay board PCA (P/N 04135) can be most easily checked by observing the condition of the its status LEDs on the relay board, as described in Section 12.1.4.3, and Teledyne Analytical Instruments...
Page 259: Sensor Assembly
A/D converter. • If they are not then either the sync demodulator board or the IR- photodetector are bad. See Section 12.4.1.4 for problems with the IR- photodetector TEC drive. Teledyne Analytical Instruments...
Page 260: Electrical Test
Table 12-9. Table 12-9: Opto Pickup Board Nominal Output Frequencies Nominal Measured Frequency AC Mains Freq. 50 Hz 60 Hz 12.5.7.4. GFC WHEEL DRIVE If the D1 and D2 on the sync demodulator board are not flashing then: Teledyne Analytical Instruments...
Page 261: Ir Source
• Measure the voltage across C1 - it should be 5 ± 0.25 VDC. If not, then the board is bad. • Measure the voltage across TP4 and TP1. • It should be 4500 mV ±250 mV. Teledyne Analytical Instruments...
Page 262: Motherboard
The ANALOG OUTPUT submenu, located under the SETUP MORE DIAG menu is used to verify that the GFC7001T/GFC7001TM Analyzer’s analog outputs are working properly. The test generates a signal on functioning outputs simultaneously as shown in the following table. (See also Section 5.9.2).
Page 263: Table 12-10: Analog Output Test Function - Nominal Values Voltage Outputs
DACs and their associated circuitry on the motherboard. To perform the test connect a voltmeter to the output in question and perform an analog output step test as follows: Teledyne Analytical Instruments...
Page 264: Analog Outputs: Current Loop
0 volts for ON and 5 volts for OFF. Table 12-12: Status Outputs Check PIN (LEFT TO RIGHT) STATUS SYSTEM OK CONC VALID HIGH RANGE ZERO CAL SPAN CAL DIAG MODE SPARE SPARE Teledyne Analytical Instruments...
Page 265: Control Inputs - Remote Zero, Span
Status connector to the B pin on the Control In connector. The instrument should switch from Sample Mode to SPAN CAL R mode. 4. In each case, the GFC7001T/GFC7001TM should return to Sample Mode when the jumper is removed. 12.5.9. CPU There are two major types of CPU board failures, a complete failure and a failure associated with the Disk On Module (DOM).
Page 266: Troubleshooting Analyzer/Modem Or Terminal Operation
3. Check to make sure the set up command is correct. See Section 8.3. 4. Verify that the Ready to Send (RTS) signal is at logic high. The GFC7001T/GFC7001TM sets pin 7 (RTS) to greater than 3 volts to enable modem transmission.
Page 267: Repair Procedures
Pneumatic Connector, Male 1/8” (P/N FT_70 Spring (P/N HW_20) Sintered Filter (P/N FL_01) Critical Flow Orifice (P/N 00094100) Make sure it is placed with the jewel down) O-Ring (P/N OR_01) Purge Housing (P/N 000850000) Figure 12-14: Critical Flow Restrictor Assembly/Disassembly Teledyne Analytical Instruments...
Page 268: Removing/Replacing The Gfc Wheel
GFC Wheel motor power supply SOURCE ASSEMBLY SYNCHRONOUS MOTOR THERMISTOR HEATER SAFETY SHIELD Figure 12-15: Opening the GFC Wheel Housing 6. Remove the two (2) screws holding the opto-pickup printed circuit assembly to the GFC Wheel housing. Teledyne Analytical Instruments...
Page 269: Figure 12-16: Removing The Opto-Pickup Assembly
8. Remove the three (3) screws holding the GFC Wheel motor/heat sink assembly to the GFC Wheel housing. 9. Carefully remove the GFC Wheel motor/heat sink assembly from the GFC Wheel housing. GFC WHEEL HOUSING Figure 12-17: Removing the GFC Wheel Housing Teledyne Analytical Instruments...
Page 270: Checking And Adjusting The Sync/Demodulator, Circuit Gain (Co Meas)
12.6.3. CHECKING AND ADJUSTING THE SYNC/DEMODULATOR, CIRCUIT GAIN (CO MEAS) 12.6.3.1. CHECKING THE SYNC/DEMODULATOR CIRCUIT GAIN The GFC7001T/GFC7001TM Analyzers will operate accurately as long as the sync/demodulator circuit gain is properly adjusted. To determine if this gain factor is correct: 1.
Page 271: Adjusting The Sync/Demodulator, Circuit Gain
Screws Sync/Demod PCA Housing Optical Bench Figure 12-19: Location of Sync/Demod Housing Mounting Screws 7. Adjust potentiometer VR1 until CO MEAS reads 4500 mV ± 300 mV Adjustment Made Here Figure 12-20: Location of Sync/Demod Gain Potentiometer Teledyne Analytical Instruments...
Page 272: Disk-On-Module Replacement
7. It may be necessary to straighten the pins somewhat to fit them into the socket. Press the chip all the way in. 8. Close the rear panel and turn on power to the machine. 9. If the replacement DOM carries a firmware revision, re-enter all of the setup information. Teledyne Analytical Instruments...
Page 273: Frequently Asked Questions
Troubleshooting and ServiceTeledyne API – Model T300/T300M CO Analyzer 12.7. FREQUENTLY ASKED QUESTIONS The following is a list from Teledyne’s Customer Service Department of the most commonly asked questions relating to the GFC7001T/GFC7001TM CO Analyzer. QUESTION ANSWER Why does the ENTR button...
Page 274: Technical Assistance
Q: What is the averaging time for A: The default averaging time, optimized for ambient pollution an GFC7001T/GFC7001TM? monitoring, is 150 seconds for stable concentrations and 10 seconds for rapidly changing concentrations (see Section 13.5.1 for more information).
Page 275: Theory Of Operation
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer THEORY OF OPERATION The GFC7001T/GFC7001TM Gas Filter Correlation Carbon monoxide Analyzer is a microprocessor-controlled analyzer that determines the concentration of carbon monoxide (CO) in a sample gas drawn through the instrument. It requires that the...
Page 276: Measurement Fundamentals
13.2. MEASUREMENT FUNDAMENTALS In the most basic terms, the GFC7001T/GFC7001TM uses a high-energy heated element to generate a beam of broad-band IR light with a known intensity (measured during instrument calibration). This beam is directed through multi-pass cell filled with sample gas.
Page 277: Gas Filter Correlation
13.2.1. GAS FILTER CORRELATION Unfortunately, water vapor absorbs light at 4.7 µm too. To overcome the interfering effects of water vapor the GFC7001T/GFC7001TM adds another component to the IR light path called a Gas Filter Correlation (GFC) Wheel. Measurement Cell...
Page 278: The Measure Reference Ratio
13.2.1.2. THE MEASURE REFERENCE RATIO The GFC7001T/GFC7001TM determines the amount of CO in the sample chamber by computing the ratio between the peak of the measurement pulse (CO MEAS) and the peak of the reference pulse (CO REF).
Page 279: Figure 13-4: Affect Of Co In The Sample On Co Meas & Co Ref
Figure 13-4: Affect of CO in the Sample on CO MEAS & CO REF Once the GFC7001T/GFC7001TM has computed this ratio, a look-up table is used, with interpolation, to linearize the response of the instrument. This linearized concentration value is combined with calibration SLOPE and OFFSET values to produce the CO concentration which is then normalized for changes in sample pressure.
Page 280: Summary Interference Rejection
Figure 13-6: Chopped IR Signal 13.2.1.3. SUMMARY INTERFERENCE REJECTION The basic design of the GFC7001T/GFC7001TM rejects most of this interference at a 300:1 ratio. The two primary methods used to accomplish this are: • The 4.7μm band pass filter just before the IR sensor which allows the instrument to only react to IR absorption in the wavelength affected by CO.
Page 281: Flow Rate Control
13.3. FLOW RATE CONTROL To maintain a constant flow rate of the sample gas through the instrument, the GFC7001T/GFC7001TM uses a special flow control assembly located in the exhaust gas line. In instruments with the O sensor installed, a second flow control assembly is located between the O sensor assembly and the exhaust port.
Page 282: Particulate Filter
2:1 pressure differential and not absolute pressure, the flow rate of the gas is also unaffected by ambient pressure fluctuations downstream. The critical flow orifice used in the GFC7001T/GFC7001TM is designed to provide a flow rate of 800 cc/min. 13.3.2. PARTICULATE FILTER The GFC7001T/GFC7001TM Analyzer comes equipped with a 47 mm diameter, Teflon, particulate filter with a 5 micron pore size.
Page 283: Pneumatic Sensors
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer 13.3.3. PNEUMATIC SENSORS There are two pneumatic sensors: one each to measure sample pressure and flow. 13.3.3.1. SAMPLE PRESSURE SENSOR An absolute value pressure transducer plumbed to the outlet of the sample chamber is used to measure sample pressure.
Page 284: Figure 13-9: Electronic Block Diagram
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer • Various analog voltage and current outputs • Several digital I/O channels • Ethernet Figure 13-9: Electronic Block Diagram Teledyne Analytical Instruments...
Page 285: Cpu
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer 13.4.1. CPU The unit’s CPU card is installed on the motherboard located inside the rear panel. It is a low power (5 VDC, 720mA max), high performance, Vortex 86SX-based microcomputer running Windows CE. Its operation and assembly conform to the PC/104 specification.
Page 286: Optical Bench & Gfc Wheel
13.4.2. OPTICAL BENCH & GFC WHEEL Electronically, in the case of the optical bench for the GFC7001T Analyzer, GFC Wheel and associated components do more than simply measure the amount of CO present in the sample chamber. A variety of other critical functions are performed here as well.
Page 287: Figure 13-11: Gfc Light Mask
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer other photo emitters/detectors. These devices consist of a combination LED and detector mounted so that the light emitted by the LED shines through the same mask on the GFC Wheel that chops the IR beam.
Page 288: Ir Photo-Detector
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer Measurement Pulses Reference Pulses IR Beam Pulses Segment Sensor Pulses MR Sensor Pulses Figure 13-12: Segment Sensor and M/R Sensor Output CHMIDT RIGGERS To ensure that the waveforms produced by the Segment Sensor and the M/R Sensor are properly shaped and clean, these signals are passed through a set of Schmidt Triggers circuits.
Page 289: Signal Synchronization And Demodulation
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer Bias CO MEAS Variable Sample & Dark Pre Amp Photo- Signal Gain Amp Switch Hold detector Conditioner Circuits TEC Control PHT DRIVE E-Test Generator CO Reference Signal (x4) Amplifiers Conditioner...
Page 290: Sync/Demod Status Leds
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer The four sample and hold circuits are designated as follows: Table 13-2: Sync DEMOD Sample and Hold Circuits Active When: Designation IR BEAM PASSING THROUGH Segment Sensor Pulse is: Measure Gate...
Page 291: Dark Calibration Switch
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer coolers by the sync/demod board which is adjusted by the sync/demod board based on a return signal called TEC control which alerts the sync/demod board of the detector’s temperature. The warmer the detector, the harder the coolers are driven.
Page 292: Zero/Span Valve Options
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer 13.4.4.3. ZERO/SPAN VALVE OPTIONS Any zero/span/shutoff valve options installed in the analyzer are controlled by a set of electronic switches located on the relay board. These switches, under CPU control, supply the +12VDC needed to activate each valve’s solenoid.
Page 293: I2C Watch Dog Circuitry
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer DC VOLTAGE TEST STATUS LED’s POINTS RELAY PCA PN 04135 Figure 13-15: Location of relay board Status LEDs 13.4.4.6. I2C WATCH DOG CIRCUITRY Special circuitry on the relay board monitors the activity on the I C bus and drives LED D1.
Page 294: Sensor Inputs
The A/D can be configured for several different input modes and ranges but in the GFC7001T/GFC7001TM is used in uni-polar mode with a +5 V full scale. converter includes a 1% over and under-range. This allows signals from –0.05 V to +5.05 V to be fully converted.
Page 295: Analog Outputs
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer EMPERATURE ENSOR A thermistor is attached to the motherboard. It measures the analyzer’s internal temperature. This information is stored by the CPU and can be viewed by the user for troubleshooting purposes via the front panel display (see Section 12.1.2).
Page 296: Power Supply/ Circuit Breaker
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer 13.4.7. POWER SUPPLY/ CIRCUIT BREAKER The analyzer operates on 100 VAC, 115 VAC or 230 VAC power at either 50Hz or 60Hz. Individual units are set up at the factory to accept any combination of these five attributes.
Page 297: Figure 13-16: Power Distribution Block Diagram
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer Figure 13-16: Power Distribution Block Diagram Teledyne Analytical Instruments...
Page 298: Front Panel Touchscreen/Display Interface
Theory of Operation Teledyne API – Model T300/T300M CO Analyzer 13.4.8. FRONT PANEL TOUCHSCREEN/DISPLAY INTERFACE Users can input data and receive information directly through the front panel touchscreen display. The LCD display is controlled directly by the CPU board. The touchscreen is interfaced to the CPU by means of a touchscreen controller that connects to the CPU via the internal USB bus and emulates a computer mouse.
Page 299: Software Operation
Unlike other analyzers that average the output signal over a fixed time period, the GFC7001T/GFC7001TM averages over a set number of samples, where each sample is 0.2 seconds. This technique is known as boxcar averaging. During operation, the software automatically switches between two different length filters based on the conditions at hand.
Page 300: Calibration - Slope And Offset
13.5.4. TEMPERATURE AND PRESSURE COMPENSATION Changes in pressure can have a noticeable, effect on the CO concentration calculation. To account for this, the GFC7001T/GFC7001TM software includes a feature which allows the instrument to compensate for the CO calculations based on changes in ambient pressure.
Page 301: A Primer On Electro-Static Discharge
If one of the surfaces is a poor conductor or even a good conductor that is not grounded, the resulting positive or negative charge cannot bleed off and becomes trapped in place, or static. The most common example of triboelectric charging happens when someone Teledyne Analytical Instruments...
Page 302: How Electro-Static Charges Cause Damage
OCCURRING AT DAMAGE AT MOSFET VMOS 1800 NMOS GaAsFET 2000 EPROM JFET 7000 Op-AMP 2500 CMOS 3000 Schottky Diodes 2500 Film Resistors 3000 This Film Resistors 7000 1000 Schottky TTL 2500 Potentially damaging electro-static discharges can occur: Teledyne Analytical Instruments...
Page 303: Common Myths About Esd Damage
• A charge can be induced onto the conductive surface and/or discharge triggered in the presence of a charged field such as a large static charge Teledyne Analytical Instruments...
Page 304: Basic Principles Of Static Control
Basic anti-ESD Workbench For technicians that work in the field, special lightweight and portable anti-ESD kits are available from most suppliers of ESD protection gear. These include everything needed to create a temporary anti-ESD work area anywhere. Teledyne Analytical Instruments...
Page 305: Basic Anti-Esd Procedures For Analyzer Repair And Maintenance
14.4.2. BASIC ANTI-ESD PROCEDURES FOR ANALYZER REPAIR AND MAINTENANCE Teledyne Analytical Instruments...
Page 306: Working At The Instrument Rack
6. Disconnecting your wrist strap is always the last action taken before leaving the workbench. 14.4.2.3. TRANSFERRING COMPONENTS FROM RACK TO BENCH AND BACK When transferring a sensitive device from an installed TAI analyzer to an anti-ESD workbench or back: Teledyne Analytical Instruments...
Page 307: Opening Shipments From Teledyne Customer Service
14.4.2.4. OPENING SHIPMENTS FROM TELEDYNE CUSTOMER SERVICE Packing materials such as bubble pack and Styrofoam pellets are extremely efficient generators of static electric charges. To prevent damage from ESD, Teledyne ships all electronic components and assemblies in properly sealed anti-ESD containers.
Page 308: Packing Components For Return To Teledyne Customer Service
ESDTeledyne API – Model T300/T300M CO Analyzer 14.4.2.5. PACKING COMPONENTS FOR RETURN TO TELEDYNE CUSTOMER SERVICE Always pack electronic components and assemblies to be sent to Teledyne Customer Service in anti-ESD bins, tubes or bags. CAUTION ESD Hazard • DO NOT use pink-poly bags.
Page 309: Glossary
10 megabits per second (Mbps) 100Base-T same as 10BaseT except ten times faster (100 Mbps) APICOM name of a remote control program offered by Teledyne-API to its customers ASSY Assembly Code-Activated Switch Corona Discharge, a frequently luminous discharge, at the surface of a conductor...
Page 310 Integrated Circuit, a modern, semi-conductor circuit that can contain many basic components such as resistors, transistors, capacitors etc in a miniaturized package used in electronic assemblies Teledyne Analytical Instruments...
Page 311 PTFE Polytetrafluoroethylene, a very inert polymer material used to handle gases that may react on other surfaces; one of the polymers that Du Pont markets as ® Teflon Poly Vinyl Chloride, a polymer used for downstream tubing Teledyne Analytical Instruments...
Page 312 Universal Serial Bus: a standard connection method to establish communication between peripheral devices and a host controller, such as a mouse and/or keyboard and a personal computer or laptop VARS Variables, the variable settings of the instrument Voltage-to-Frequency Zero / Span Teledyne Analytical Instruments...

Teledyne GFC7001T Operation Manual

About this Manual

Important Safety Information

Table of Contents

Part I General Information

1 Introduction, Features and Options

2 Specifications and Approvals

3 Getting Started

Appendix A - Version Specific Software Documentation

Appendix B - Gfc7001T/Gfc7001Tm Spare Parts List

Appendix C - Repair Questionnaire - Gfc7001T

Appendix D - Schematics

Part II Operating Instructions

4 Overview of Operating Modes

5 Setup Menu

6 Communications Setup and Operation

7 Data Acquisition System (Das) and Apicom

8 Remote Operation

9 Calibration Procedures

10 Epa Calibration Protocol

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for Teledyne GFC7001T

Summary of Contents for Teledyne GFC7001T
