Page 2
1. 1. 1. SAFETY PRECAUTIONS SAFETY PRECAUTIONS SAFETY PRECAUTIONS SAFETY PRECAUTIONS Before using this game,read the following safety precautions thoroughly and use the game correctly. Be sure to observe the safety instructions as they are important for ensuring safe operation of the game.
Page 3
people from getting injured by touching the inside of the machine. ● Never touch the slide unit or other drive system during operation. Moving parts can pinch or injure your fingers. ● When removing the rear compartment door, hold it carefully with both hands as it is large and heavy.
Page 4
3. 3. 3. TEARDOWN FOR TRANSPORTATION TEARDOWN FOR TRANSPORTATION TEARDOWN FOR TRANSPORTATION TEARDOWN FOR TRANSPORTATION ・・・ ・・・Jackpot Cascading Unit Jackpot Cascading Unit ・・・ ・・・ Jackpot Cascading Unit Jackpot Cascading Unit Teardown this foam ・・・ ・・・ ・・・ ・・・Starting Gate Starting Gate Unit Unit Starting Gate Starting Gate...
4. 4. 4. Installation Installation Installation Installation of of of of LCD Box Unit LCD Box Unit LCD Box Unit LCD Box Unit Top Tray 1pcs Top Tray 1pcs Screw M4X12 8pcs Screw M4X12 8pcs OK OK Pipe .4....
5. INSTALLATION INSTALLATION 5. 5. INSTALLATION INSTALLATION Install the machine according to the instructions and procedures specified in this operation manual. Failure to follow the specified procedures may result in a fire, electric shock, injury, or machine malfunction. Insert the power cord plug firmly into the power outlet. Poor contact may cause overheating that can lead to fire or burns.
Page 7
6. 6. 6. Play Zone of Installed Machine Play Zone of Installed Machine Play Zone of Installed Machine Play Zone of Installed Machine ● Set a play zone as shown below so that players can move away from the machine without bumping into observers or passersby.
Page 8
7. 7. 7. ACCESSORIES ACCESSORIES ACCESSORIES ACCESSORIES LIST LIST LIST LIST ITEM DESCRIPTION QY. PART No. 1 Key(9895) 310-680 2 Key (9888) 310-681 3 White Ball (25 pieces) 310-564 4 Pink Ball (25 pieces) 310-565 5 Yellow Ball (25 pieces) 310-566 6...
Page 9
9. 9. 9. Power switch and Ball Power switch and Ball Power switch and Ball Power switch and Ball ・ ・ ・ ・ Power switch switch switch switch There are two power switches, one is on the back and the other is inside of the service door.
Page 10
10. How to Play How to Play How to Play How to Play When a ball through number “ CHANNEL JAM”or 7SEG“ CHANNEL JAM”,the ticket is dispensed directly to the player. After inserting the coin, a set of "Starting Gate Unit" will move from left to right back &...
Page 11
11. CHANGE OF SETTINGS & CONFIRMATION OF DATA CHANGE OF SETTINGS & CONFIRMATION OF DATA CHANGE OF SETTINGS & CONFIRMATION OF DATA CHANGE OF SETTINGS & CONFIRMATION OF DATA FUNCTION KEYS ILLUSTRATION: FUNCTION KEYS ILLUSTRATION: FUNCTION KEYS ILLUSTRATION: FUNCTION KEYS ILLUSTRATION: ①...
Page 12
BOOKKEEPING BOOKKEEPING BOOKKEEPING BOOKKEEPING MENU MENU MENU MENU GAME COUNT …Number of games played. It will be updated when it is game over. COIN COUNT …Number of coins inserted. It will be updated when a coin is inserted. (Key in is not counted) TICKETS PAYOUT …Number of tickets paid out.
SETTING MENU SETTING MENU SETTING MENU SETTING MENU Jackpot Jackpot Jackpot Jackpot…Number of JPs Mercy Tickets Mercy Tickets Mercy Tickets Mercy Tickets…Number of mercy tickets Mode Switching Mode Switching Mode Switching Mode Switching…Change of mode(Normal or Debug) Coin Set Mode Coin Set Mode…Setup of coin in.
Page 14
TICKET PAY OUT SETTING TICKET PAY OUT SETTING TICKET PAY OUT SETTING TICKET PAY OUT SETTING ●Jackpot/7-segment display ●№Gate PAY OUT Mode 90 SETTING A SETTING Max(Jackpot) normal(Jackpot):Totai 90 70 SETTING Max(Jackpot) normal(Jackpot):Totai 70 B SETTING 50 SETTING【Default】 Max(Jackpot)【Default】 normal(Jackpot):Totai 50 30 SETTING C SETTING 【Default】...
Page 16
Display of error log Display of error log Display of error log Display of error log 显示最新10笔故障记録 按键①回到主画面 按键④进入清除画面 按键④清除 选择YES再按下 记録 TICKET PAYOUT LOG TICKET PAYOUT LOG TICKET PAYOUT LOG TICKET PAYOUT LOG Display the latest 30 records of ticket out. Press button ①...
Page 17
INPUT/OUTPUT TESTING INPUT/OUTPUT TESTING INPUT/OUTPUT TESTING INPUT/OUTPUT TESTING TESTING DISPLAY: IN RED… Starting up (ON) IN YELLOW…No startup (OFF) Sensor signal MIDDLE On/off of allmotors and solenoid valve. DOWN On/off of all LED lamps. Press button ② & button ③ to move cursor. Press button ①...
Page 18
12. Error Messages Error Messages Error Messages Error Messages ERR CODE ERR UNIT HOW TO RELEASE 01. TUBE BOTTOM JAM Long pipe bottom Bottom of ball-dispatching tube got jammed 02. TUBE COUNT JAM Long pipe MID Middle of ball-dispatching tube got jammed Launcher 5Ball...
Page 19
occurred at dropping balls when hitting JP. Launcher 5Ball Unit 37. 5BALL FALL MOTOR ERR. Motor not working Hopper Unit 38. HOPPER ERROR Motor for dispatching balls not working or sensor error occurred 39.Play CHANNEL sensor ERR Play CHANNEL Play CHANNEL JAM 13.
Page 21
14.2 14.2 14.2 14.2 ・・ ・・ ・・ ・・Cabinet Cabinet Cabinet Cabinet 17 17 17 17 10/12 ITEM DESCRIPTION QY. PART No. 1 LED RGB LAMP(LED-FPC-600L-18P-RGB) 310-545 2 LED RGB LAMP(LED-FPC-1200L-36P-RGB) 310-546 3 LED LAMP(LED-FPC-600L-36P -SW) 310-547 4 LED LAMP(LED-FPC-500L-30P -SW) 310-548 5...
Page 22
14.3 14.3 14.3 14.3 ・・・ ・・・ ・・・ ・・・LCD Box Unit LCD Box Unit LCD Box Unit LCD Box Unit 3 3 3 3 ITEM DESCRIPTION QY. PART No. 1 Lcd( AU 16:9 M215HW02 V0;21.5" LCD PANEL ) 310-570 2 A/D Board (ALLYSTAR M03-MB) 310-571 3...
Page 23
14.4 14.4 14.4 14.4 ・・・ ・・・ ・・・ ・・・Divide Unit Divide Unit Divide Unit Divide Unit ITEM DESCRIPTION QY. PART No. 1 SOLENOID(DC 12V 1253L) 310-576 2 Sensor (KR 1207) 310-577 3 Sensor (INT-2-DN ) 310-578 4 Driver Board ( FETDR-001 V2 ) 310-561 .22....
Page 24
14.5 14.5 14.5 14.5 ・・・ ・・・ ・・・ ・・・Jackpot Cascading Unit Jackpot Cascading Unit Jackpot Cascading Unit Jackpot Cascading Unit ITEM DESCRIPTION QY. PART No. 1 DC MOTOR(DC 24V 35R.P.M.) 310-585 2 Sensor (INT-2-DN ) 310-578 3 JP Sensor Buffer( J2207A ) 310-586 DC MOTOR Driver Board 4...
Page 25
14.6 14.6 14.6 14.6 ・・・ ・・・ ・・・ ・・・Starting Gate Unit Starting Gate Unit Starting Gate Unit Starting Gate Unit ITEM DESCRIPTION QY. PART No. 1 Step Motor( SS1704A20A ) 310-595 2 Timing Belt(630XL-031) 310-596 3 Synchronizing Wheel(11XL -031-P5) 310-597 4 Solenoid(DC 12V 1253L)...
Page 26
14.7 14.7 14.7 14.7 ・・・ ・・・ ・・・ ・・・5Ball Gate Unit 5Ball Gate Unit 5Ball Gate Unit 5Ball Gate Unit ITEM DESCRIPTION QY. PART No. 1 Step Motor( SS1704A20A ) 310-595 2 Timing Belt(630XL-031) 310-596 3 Synchronizing Wheel(11XL -031-P5) 310-597 4 Sensor (KI-662) 310-598 5...
Page 27
14.8 14.8 14.8 14.8 ・・・ ・・・ ・・・ ・・・5Ball 5Ball 5Ball Launcher 5Ball Launcher Launcher Unit Launcher Unit Unit Unit ITEM DESCRIPTION QY. PART No. DC MOTOR(DC 24V 35R.P.M.) 1 310-585 2 Sensor (INT-2-DN ) 310-578 3 5Ball Launcher Buffer( B2164 ) 310-610 4...
Page 28
14.9 14.9 14.9 14.9 ・・・ ・・・ ・・・ ・・・Number Gate Unit Number Gate Unit Number Gate Unit Number Gate Unit ITEM DESCRIPTION QY. PART No. 1 Led Lamp Pcb Unit (JMGB-G083-001) 310-615 2 Receiver Pcb Unit(JMGB-G083-006) 310-616 3 Number Acrylic (J2034) ※1 -(※1)...
Page 29
14.10 14.10 14.10 14.10 ・・・ ・・・ ・・・ ・・・7seg Gate Unit 7seg Gate Unit 7seg Gate Unit 7seg Gate Unit ITEM DESCRIPTION QY. PART No. 1 Seg Pcb(JMGB-G083-004) 310-625 (JMGB-G083-006) 2 Receiver Pcb Unit 310-616 3 Led Lamp Pcb Unit (JMGB-G083-001) 310-615 .28....
Page 30
14.11 14.11 14.11 14.11 ・・・ ・・・ ・・・ ・・・Jackpot Gate Unit Jackpot Gate Unit Jackpot Gate Unit Jackpot Gate Unit ITEM DESCRIPTION QY. PART No. DC MOTOR(DC 12V 43R.P.M.) 1 310-690 2 Sensor (INT-2-DN ) 310-578 3 JP Get Sensor Buffer(B2149) 310-631 4...
Page 31
14.12 14.12 14.12 14.12 ・・・ ・・・ ・・・ ・・・Hopper Unit Hopper Unit Hopper Unit Hopper Unit ITEM DESCRIPTION QY. PART No. DC MOTOR(DC 24V 12R.P.M.) 1 310-640 2 Sensor (INT-2-DN ) 310-578 DC MOTOR Driver Board 3 310-641 (JMGB-G083-005 1.5A) 4 Hopper Sensor Buffer ( B2175 ) 310-642 Hopper Disk(K2002-22)...
Page 32
14.13 14.13 14.13 14.13 ・・・ ・・・ ・・・ ・・・Coin Coin Coin / / / / Redemption Door Unit Coin Redemption Door Unit Redemption Door Unit Redemption Door Unit (3 IN 1 DOOR Unit) for (3 IN 1 DOOR Unit) for (3 IN 1 DOOR Unit) for (3 IN 1 DOOR Unit) for Asia Asia...
Page 33
14.14 14.14 14.14 14.14 ・・・ ・・・ ・・・ ・・・Power Supply Unit Power Supply Unit Power Supply Unit Power Supply Unit PART No. ITEM DESCRIPTION QY. Supply 310-670 1 Power (RS-75-12 ) Supply 2 Power (SP-320-24 ) 310-671 Supply 3 Power (RD-125A ) 310-672 Supply Power...
Page 34
14.15 14.15 14.15 14.15 ・・・ ・・・ ・・・ ・・・PC Box Unit PC Box Unit PC Box Unit PC Box Unit ITEM DESCRIPTION QY. PART No. 1 Pc Board(JMGB-M03: VIA NANO 1.0GHZ/WITH 1GB ) 2 I/O Board(JMGB-I04 V1.0 ) 310-675 3 Fan(40x40x20T-DC12V ) 310-676 4...
