  • Page 1 OPERATOR’S MANUAL...
  • Page 2 Copyright 2003 NAMCO AMERICA INC. - All rights reserved No part of this publication may be reproduced by any mechanical photographic, or...

  • Page 3: Table Of Contents

    FLAMIN’ FINGER™ Operator’s Manual TABLE OF CONTENTS SPECIFICATIONS INTRODUCTION PRECAUTIONS Installation Handling INSTALLATION Linking SCREEN DESCRIPTIONS GAME PLAY TROUBLESHOOTING APPENDIX A: PARTS LIST APPENDIX B: WIRING DIAGRAM APPENDIX C: LINKING WIRING DIAGRAMS...

  • Page 5: Specifications

    (in coin box) Note: Specifications subject to change without prior notice. Modifications and/or ™ alterations of the FLAMIN’ FINGER game with kits or parts not supplied by NAMCO may void the warranty. WARNING REMOVAL OF SERIAL NUMBERS AND/OR BAR-CODES FROM PRODUCT OR...

  • Page 6: Introduction

    FLAMIN’ FINGER™ Operator’s Manual INTRODUCTION ™ Namco’s FLAMIN’ FINGER is a 1-player (linkable up to 64 players) redemption game featuring randomly generated mazes on a touch-screen. Complete the maze within the time allowed and win the JACKPOT! PRECAUTIONS Installation This game is designed for indoor use only.

  • Page 7: Installation

    FLAMIN’ FINGER™ Operator’s Manual INSTALLATION Note: Shipping damage may void the warranty. In case of shipping damage, contact your distributor and the transportation carrier immediately. Unpack the game. With the game in its installation position, lower the leveler pads as required to eliminate any tilting of the game.

  • Page 8: Screen Descriptions

    FLAMIN’ FINGER™ Operator’s Manual SCREEN DESCRIPTIONS Enter the MAIN MENU options screen by pressing the SERVICE button located on the service panel inside the coin door. The MAIN MENU screen includes the following choices: MAIN MENU OPTIONS ACCOUNT DIAGNOS Press the red on-screen boxes to choose that item. Use the red on-screen slider to adjust the selection.
  • Page 9 FLAMIN’ FINGER™ Operator’s Manual SET 0-10 MIN TICK PER TRY This sets the minimum number of tickets a player will receive regardless of their performance. (Default setting is “3") NOTE: The player will receive an amount of tickets somewhere between the “min tick per try” and the “max tick per try”...
  • Page 10 MEMORY TEST SMC FAIL This screen informs you that the memory inside of the memory card has been corrupted. NOTE: Contact Namco Customer Service. This animation is intended to burn-in all of the red and yellow led’s and you should...

  • Page 11: Game Play

    FLAMIN’ FINGER™ Operator’s Manual miniature #259 bulbs located behind the red caps will flash once to confirm their operation. Press the SERVICE button to exit the test. Press the SERVICE button to return to the MAIN MENU options screen. Other screen messages that may appear are as follows: MEMORY CARD NOT SELECTED Check to see if the memory card is fully inserted in the proper direction.

  • Page 12: Troubleshooting

    FLAMIN’ FINGER™ Operator’s Manual The starting game time ranges in time allowed to complete the maze from 9 to 30 seconds, depending on the length of the maze, as well as an internal difficulty set by the skill level of the players that have won the jackpot. The game time is not adjustable by the operator.

  • Page 13: Appendix A: Parts List

    FLAMIN’ FINGER™ Operator’s Manual Problem Probable Cause Solution No motion sound. No AC power. Check AC input plug on switching power supply. Verify PS switch is ON. Check DC output voltage at 9- pin connector. RED to BLK should be 5+/-.15VDC.
  • Page 14 FLAMIN’ FINGER™ Operator’s Manual CABINET ASSEMBLY Part Number Description FI63-10974-00 CABINET, FLAMIN’ FINGER FI40-10911-00 MARQUEE VG57-10972-00 SOCKET, LAMP, COMPACT FLUORESCENT FI57-10922-00 STROBE LENS, RED FI95-10973-00 PLEX, PLAYFIELD FI40-10914-00 DECAL, GAME INSTRUCTIONS FI05-10918-00 CPU, MAIN LOGIC VG88-08776-00 POWER SUPPLY, 200W, ATX STYLE FI45-10919-00 MANUAL, FLAMIN’...
  • Page 15 FLAMIN’ FINGER™ Operator’s Manual...

  • Page 16: Appendix B: Wiring Diagram

    FLAMIN’ FINGER™ Operator’s Manual APPENDIX B: WIRING DIAGRAM...
  • Page 17 FLAMIN’ FINGER™ Operator’s Manual APPENDIX C: LINK DIAGRAMS...
  • Page 19 Namco America Inc. parts or accessories. Namco America Inc. cannot be responsible for the quality, suitability or safety of any non-Namco America Inc. part or any modification including labor that is performed by such distributor.
  • Page 20 NAMCO AMERICA INC. 890 Service St. # C San Jose, CA 95112 (408) 383-3900 FAX: (408) 436-9554 Technical Assistance (USA) (408) 383-3973 Fax: (408) 436-9554 Reorder Number FI45-10919-00 REV. A NOVEMBER 2003 The specifications of this machine and the instructions in this Operation Manual are subject to change...
