Management

SNMP Setup

Trango Broadband provides only the MIB portion of the SNMP Management system. The radios act as individual agents, and
it is up the user to provide SNMP Manager software from a third party vendor. Below is an example of the setup process for
SNMPc from Castle Rock™.
1. Unzip trangopkg.zip file to a local temporary directory.
2. Go to your local temporary directory, you will see 4 files shown below.
a. trango_P5830Sap_1p0.mib – M5800S MU MIB file
b. trango.ico – P5830S MU icon
c. autoico.txt – instruction file (Selects Trango icon automatically during initial set-up.)
3. Copy trango_P5830Smu_1p0.mib file to C:\Program Files\SNMPc Network Manager\mibfiles
4. Copy autoico.txt file to C:\Program Files\SNMPc Network Manager\mibfiles
5. Copy trango.ico file to C:\Program Files\SNMPc Network Manager\bitmaps
6. The MIB needs to be compiled into the SNMPc database
By default, the Read Community is set to "public," and Write Community is set to "private" in the MU. The Trap
Community is "SNMP_trap." The manager needs to have the same settings in order to communicate with the MU
successfully.
Note: The Trap Community cannot be set via HTTP or CLI.
To send traps from the MU, set the following:
•
trap destination IP (Trango MIB object trapconfig–trapconfigInfo)
•
trap community string (Trango MIB object trapconfig–MutrpTable-MutrpEntry)
•
enable each trap (Trango MIB object traponfig–mutrpTable-MutrpEntry)
For all set operations, set object SaveAndActivate at musystem-musystemInfo to write the information to FLASH.
