Appendix B

Antennas

Integrated 19 dBi Antenna (for P5055M-19-xx)
Frequency range:
Gain:
Front/Back Ratio
E-Plane Beamwidth:
H-Plane Beamwidth:
Polarization:
Port/Port Isolation:
Cross Pol Rejection:
VSWR:
Package:
Dimensions:
Weight:
Mounting Provisions:
Azimuth/El Adjust:
Sealing:
Temp Range:
Wind speed operational: 100 mph (160 km/hr)
Wind speed survival :
Integrated 23 dBi Antenna (for P5055M-23-xx)
Frequency range:
Gain:
Front/Back Ratio
E-Plane Beamwidth:
H-Plane Beamwidth:
Polarization:
Port/Port Isolation:
Cross Pol Rejection:
VSWR:
Package:
Dimensions:
Weight:
Mounting Provisions:
Azimuth/El Adjust:
Sealing:
Temp Range:
Wind speed operational: 100 mph (160 km/hr)
Wind speed survival :
FCC Certified External Antennas (for P5055M-EXT-xx)
Radiowaves models:
See Radiowaves, Inc. for specifications and details
Trango Broadband Wireless — TrangoLINK-45
4950-5850 MHz
19 dBi +/- 1 dB
>30 dB
> 18 degrees typical
> 18 degrees typical
Vertical and Horizontal
20 dB typ
20 dB typ
<1.7:1
Alumininum backplate with plastic radome.
8.5" x 7.75" x 1.25" (216mm x 197mm x 32mm)
2 lbs (.91Kg)
Mounting kit supplied for up to 3"diam pole or flat surface
+/-30 degrees
Water tight to 1 meter IEC 529/IP67
-40 deg F to +160 deg F (-40 deg C to +60 deg C)
140 mph (220 km/hr)
4950-5850 MHz
23 dBi +/- 1 dB
>35 dB
> 9 degrees typical
> 9 degrees typical
Vertical and Horizontal
40 dB typ
25 dB typ
<1.7:1
Alumininum backplate with plastic radome.
14.6"x 14.6"x 1.58" (371mm x 371mm x 40mm)
5.5 lbs (2.5 kg)
Mounting kit supplied for up to 3"diam pole or flat surface
+/-30 degrees
Water tight to 1 meter IEC 529/IP67
-40 deg F to +160 deg F (-40 deg C to +60 deg C)
140 mph (220 km/hr)
SPD4-5.2, SPD3-5.2, SPD2-5.2, SPD1-5.2
Specifications
page 54
