Appendix A
RF Out:

Configuration Page

IP Address:
Subnet Mask:
Gateway:
Default Opmode:
Peer ID:
Switch:
Auto Rate Shifting
Autoscan MU
RSSI LED
Active Channel/Polarization: The current channel and polarization of the radio when Opmode is \"On\".
Speed:
Power:
Range:
Remarks:
MIR:
ARQ: .
Encrypt: .
Key: .
Activate Opmode On:
Activate Opmode Off:
Trango Broadband Wireless — TrangoLINK-45
Counter for Ethernet packets which exited over-the-air out the radio.
The IP address of this radio; used to manage the radio's application layer.
The subnet mask of the radio.
The default gateway of the radio.
Operation mode of the radio after power cycle. When Opmode is \"On\" the
radio will attempt to make a wireless connection. When Opmode is \"Off\" the
radio is not transmitting, but can be managed from the wired side. In addition
to setting Default Opmode to \"Off\", Opmode can be set to \"Off\" by
interrupting the radios boot-up cycle in the first 30 seconds after power up
User entered MAC address of the partner unit.
Checked means active
When enabled, radio will automatically shift TX rate up or down depending
on link quality.
(RU Only). If this switch is enabled, when not connected to MU, the RU will
automatically automatically scan all available channels and frequencies
Enables and disables RSSI LEDs. Disabling the LEDs provides slight
improvement to radio performance. Typically RSSI LEDs should be enabled
during alignment and disabled during normal operation.
Transmit over-the-air raw data rate.
Transmit RF power setting.
Allowable range of the transmit power based on the current settings of the
active channel and the speed.
A descriptive text field for general use (i.e. the location of the unit). It does
not affect system performance.
Set Maximum Information Rate for network traffic.
Auto Retransmit Request. When enabled, dropped packets are detected at
the receiver and retransmitted by the transmitter.
Encryption. Enables and disables proprietary 128 bit over-the-air encryption.
128 Encryption Key. Must match in both MU and RU.
Activates radio's Opmode to "On"-transmitting.
Activates radio's Opmode to "Off" not-transmitting.
page 44
