INSYS GPRS 5.1 serial
Set SMS text mode
The SMS service center number of the network provider
may be omitted if the number is stored on the SIM card.
Enter the destination phone number
Wait for the prompt ">", enter the text
The SMS is dispatched using the key combination Ctrl and Z.
Prior to the confirmation message you will be informed
about the amount of SMS that have already been sent.
6.7

Digital Inputs and Potential-Free Outputs

The INSYS GPRS 5.1 serial has digital inputs and outputs. The outputs can be switched via
AT commands to control external functions. The inputs can be used to trigger an action
of the INSYS GPRS 5.1 serial. The inputs can be used to dial a connection to an AutoDial
destination or to send an SMS. The action is triggered through a change of the input
from HIGH (inactive) to LOW/GND (active). The level change is accepted after 0.3 sec-
onds, i.e. the input is debounced. In addition, there is the possibility for IO tunnelling, i.e.
transmit the input states via a TCP connection to another INSYS GPRS 5.1 serial or a serv-
er.

6.7.1 Automatic SMS Dispatch Via Switch Input

The INSYS GPRS 5.1 serial can send a predefined SMS via a level change of the digital in-
puts UI. The SMS is triggered through the connection of the input with ground (GND).
The alarm input is on HIGH potential by a pull-up resistor in open state (inactive).
The SMS is triggered through a change of the input from HIGH (inactive) to LOW/GND
(active). The level change is accepted after 0.3 seconds (debounce).
To resend the SMS, the input must be set to HIGH (inactive). If the input state at both
inputs changes at the same time, the input state 1 will be evaluated first. If the state
Note:
The service center phone number must be written in international
format, e.g. for a German provider starting with "+49".
Note
To enable the automatic sending of SMS messages, the device must
know the number of a SMS service center. Make sure that the ser-
vice center number is entered and stored in the device via AT com-
mands.
Functions
AT+CMGF=1
AT+CSCA=<nr>
AT+CMGS=<nr>
><text><Ctrl+Z
>
CMGS: <Num>
ok
