C H A R G E S T O R M ®
6. On successful RFID identification will charging start and the blue battery symbol is activated until cable
is unplugged.
7. END
Note
There are many different RFID-tags. If your tags are not coming from CTEK E-Mobility contact
us and we will check if your tags are compatible with the charging station. ISO1443A/Mifare is the
supported RFID-standard.

Status symbols

Figure 2 Status symbols
The following table explains the status symbols.
Symbol
C O N N E C T E D
Symbol color Mode (RFID
/ Open)
Open
Green RFID
blinking Yellow RFID
Blinking Green RFID
Explanation
RFID-symbol not active
Waiting for RFID-tag
Authentication in progress. Wait!
RFID-tag approved. Charging will now start.
User Manual 5
