STEP 16: Hook Safety Net Springs to Cross Upper Poles
STEP 3: Prepare the FRAME SEGMENTs
11 10
Pick up a FRAME JOINER and a FRAME TUBE, and then insert the larger square end
of the FRAME TUBE into the square tube of the FRAME JOINER to form a FRAME
SEGMENT. Please make sure the holes of the FRAME TUBE are facing upward before
you insert it into the FRAME JOINER. Please be aware the round tubes of the FRAME
JOINER should be vertical to the surface and facing outward.
Repeat this process, and prepare all FRAME SEGMENTs.
10
STEP 4: Join the FRAME SEGMENTs and form a circle
You have successfully installed SPARK trampoline!
Pick up two FRAME SEGMENTs and Insert the small square end (without the FRAME
8
JOINER) of one FRAME SEGMENT into the larger square end (with the FRAME
JOINER) of the other FRAME SEGMENT.
11 10
*If you have any problems by this stage, please do not try to install the trampoline and call 1300 782 661
