T1K-5Cbl-Ll(-1) Expansion Cable; T1K-5Cbl-Rr(-1) Expansion Cable - Automation Direct Terminator Installation And I/O Manual

T1K-5CBL-LL(-1) Expansion Cable

Specification
Cable Description
Cable Length
Cable Diameter
Shielding
Temperature Range
Jacket Material
Auxiliary 24VDC
Cable

T1K-5CBL-RR(-1) Expansion Cable

Specification
Cable Description
Cable Length
Cable Diameter
Shielding
Temperature Range
Jacket Material
Auxiliary 24VDC
Cable
NOTE: Please refer to Chapter 2 for application examples using the different types of expansion
cables that are available.
Specifications
T1K-05CBL-LL
Left-to-left Side Expansion Cable
50cm (1.64 ft.)
8.5 mm
None
-25!C to 80!C (-13!F to 176!F)
PVC
Cable Diameter N/A
Insulation Voltage N/A
Specifications
T1K-05CBL-RR
Right-to-right Side Expansion Cable
50cm (1.64 ft.)
8.5 mm
None
-25!C to 80!C (-13!F to 176!F)
PVC
Cable Diameter N/A
Insulation Voltage N/A
30 (1.18)
8.1 (0.32)
Side View
Terminator Installation and I/O Manual, 3rd Edition, Rev. B
Chapter 3: I/O Wiring and Specifications
T1K-05CBL-1-LL-1
Two 1.42 mm cables
used in a 6mm sheath
2000VAC /1 minute
T1K-05CBL-1-RR-1
Two 1.42 mm cables
used in a 6mm sheath
2000VAC / 1 minute
mm (in.)
Cable Length: 50 cm
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
3-119
