- Page 1 Newport Corporation TSP Stage Series TSP Series Precision Linear Stages Newport Corporation 1791Deere P.O. Box 19607 Irvine, CA 92606-92623 Tel: 949-863-3144 Fax: 949-253-1800 www.newport.com...
-
Page 2: Warranty Limitations
(for standard product) or specifi- cations in the quotation (for custom/special product). For warranty service requiring return of a product to Newport, the item(s) must be re- turned to our Service Center, with all shipping, taxes, or duty charges prepaid unless special arrangements have been approved beforehand by Newport. -
Page 3: Statement Of Calibration
The information in this document has been checked and is believed to be entirely reliable. However, no responsibility is assumed for inaccuracies or inadvertent omissions. Furthermore, Newport Corp. reserves the right to make changes to any product herin to improve reliability, function or design. - Page 4 Newport Corporation TSP Stage Series Abbildung 1. Quetschgefahr Figura 1. Riesgo de Aplastamiento Figue 1. Risque d’écrasement In Figure 2 below, is the Electrical Hazard warning label. This is to indicate that injury, such as electric shock, burns or permanent damage to the equipment could occur if the component comes into contact with other objects or with the user.
- Page 5 Newport Corporation TSP Stage Series Achtung Die Stromversorgung motorbetriebener Geräte is in folgenden Situationen zu unterbrechen: · Wenn das Gerät Regen oder übermäßigerFeuchtigkeit ausgesetzt ist, oder wenn Flüssigkeiten in das Gerät geraten sind. · Wenn das Gerät fallengelassen wurde oder das Gehäuse beschädigt ist.
-
Page 6: Unpacking And Inspection
Report any such damage to the shipping agent immediately. Retain the original packaging materials in case reshipment becomes necessary. If a Newport product must be returned, the following information is needed for proper shipment back to Newport: Unit Model Number Unit Serial Number Reason for return. -
Page 7: Environmental Considerations
Newport Corporation TSP Stage Series Figure 3 Environmental Considerations Temperature For optimum performance, the stage should be maintained at a temperature of C (68 F +/- 2 Vibration The stage should not be set up within the vicinity of vibration or shock. Outside forces, such as forklifts, compressors and other machinery, can induce unwanted motion in the stages via the floor on which the whole system is resting. - Page 8 Newport Corporation TSP Stage Series Stage Installation Allow clearance for the 25 pin connector. Bolting the Stage to the Surface Plate Clean the surface plate prior to mounting the stage. The stage should be attached at all four corners to the surface plate. To allow access to the counter bores, move the stage alternately to one end-of-travel limit and then to the other.
-
Page 9: Initial Operation
However, it is highly recommended that initial verifications of proper limit switch operation and of proper configuration of the controller are performed. Note: If using a controller other than a Newport controller, the stage may not work properly. Contact Newport technical assistance for modification instructions. - Page 10 Newport Corporation TSP Stage Series Verification of Proper Controller Configuration Before using the stage for any application, the controller should be specifically configured and programmed for operation with the TSP stage. Refer to the manufacturer’s manual for the controller to find the relevant procedures. Fine tuning of the controller may also be required.
- Page 11 Newport Corporation TSP Stage Series Attaching to the Stage Components’ Surface Flatness The mating surfaces of components being attached to the stage should be flat to within 2.5um (0.0001 inch) overall. Screw Specifications Use an M6X1 or 1/4-20 screw, depending on whether the mounting holes are metric or english to attach other components.
-
Page 12: Maintenance
Newport Corporation TSP Stage Series MAINTENANCE The frequency of required cleaning, lubrication and testing is highly user dependent. Refer to Table 2 below to establish a maintenance schedule for your unit. Table 2... - Page 13 Newport Corporation TSP Stage Series Lubrication When applying lubricant, do not use either a harsh applicator which may scratch or damage the stage surfaces, or a fragile applicator, which may generate particles to contaminate the compo- nent. The recommended lubricant is Lamora® D68 Oil.
- Page 14 Newport Corporation TSP Stage Series Inspect the bearing rails for signs of damage or corrosion. Consult Newport’s technical assistance group if damage or corrosion has occured. Use the manual knob to move the stage to one end-of-travel limit. Clean the exposed bearing rail v-grooves on both upper and lower rails with Isopropyl alcohol and a lint free cloth.
- Page 15 Newport Corporation TSP Stage Series Apply light file of the lubricant to the exposed part of the ballscrew (Figure 10). Manually run the stage from one end-of-travel limit to the other to distribute the lubricant evenly along the ballscrew. Wipe off any access lubricant with a lent free cloth.
- Page 16 Newport Corporation TSP Stage Series...
- Page 17 Newport Corporation TSP Stage Series DIMENSIONS (SEE CHARTS ON NEXT PAGE)
- Page 18 Newport Corporation TSP Stage Series Linear Encoders Non-Contact Encoder .1 um Resolution TTL Quad AB Output (Differential) 4 um Signal Period Home (Origin) at negative end of travel...
- Page 19 Ensure that all cables are clear of the moving Obstruction to motion than specifications equipment Entangled cables If roller creep is suspected, contact Newport for assistance Roller creep Refer to Setup, Environmental consider- Stage does not meet ations in this manual...
- Page 20 Newport Corporation TSP Stage Series Cause Problem Corrective Action Object contacting the manual operation Remove object Stage makes un- knob usual noise Tighten screws Loose covers Entangled cables Ensure that all cables are clear of the mov- ing equipment Contact Newport for assistance...
- Page 21 Newport Corporation TSP Stage Series HOME & LIMIT SWITCHES TROUBLESHOOTING GUIDE Transmissive Sensor Testing Perform this procedure for the following sensors: • Clockwise • Counterclockwise • Home Find a thin strip of flexible material, such as heavy paper or thin cardboard, to use as a flag.
-
Page 22: Pinout Connections
Newport Corporation TSP Stage Series PINOUT CONNECTIONS The circuit board connector interfaces to the motion controller. Refer to the below pinout chart for pinout numbers. DC Servo Motor Pin No. + Tachometer Generator + Tachometer Generator - Tachometer Generator - Tachometer Generator...
