Model No.
230V AC 50Hz 1.26A
MP716
230V AC 50Hz 1.7A
MP730
230V AC 50Hz 2.1A
MP750
In order to ensure correct and safe usage of your battery charger, you should read these instructions
SAFETY
Ensure that cables are regularly inspected and kept in good condition.
Never use the battery charger if the mains lead or plug is damaged.
Never use the battery charger if the output leads or crocodile clips are damaged.
Never use the battery charger if it has been dropped or damaged in any way.
WARNING: Battery charging produces explosive gases. Prevent flames and sparks. Provide adequate
ventilation during charging.
For indoor use and storage only, do not expose to rain or any other forms liquid or moisture.
The charger must not be used as a DC power source or for any purposes other than those listed.
The charger must not be used for the charging of non-rechargeable batteries.
It is not recommended that a charging battery be left unattended for long periods or overnight.
Replacement of the mains cable should only be carried out by the manufacturer, its service agent or a suitably
qualified electrician / electrical technician in order to avoid a hazard. There are no user-serviceable parts in
this product. Modifications or attempted repairs by unsuitable persons will render the product warranty void.
GENERAL SAFETY
These battery chargers can be used by children aged from 8 years and above, and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliances in a safe way, and understand the hazards involved.
Children must not play with these battery charger. Cleaning and user maintenance shall not be carried out by
children without supervision.
GASES
The charging process produces flammable and explosive gases - the area in which charging takes place
should be kept well ventilated. Only connect and disconnect the battery leads when the mains supply is
disconnected. Avoid flames or sparks! Do not smoke!
MP716 / MP730 / MP750 12V/24V Battery Chargers
Instruction and information manual
Rated Input
1.1A
2.5A
3.8A
carefully. Please store these instructions for future reference.
EN Rated Output
12V DC 11.4 Amp
24V DC 5 Amp
12V DC 16 Amp
24V DC 16 Amp
12V DC 25 Amp
24V DC 25 Amp
Peak
Battery
Output
Type
12V/24V
12 Amp
Lead-acid
12V/24V
20 Amp
Lead-acid
12V/24V
30 Amp
Lead-acid
Battery
Capacity
30-180Ah
90-250Ah
120-320Ah
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MayPole MP716
Summary of Contents for MayPole MP716
- Page 1 MP716 / MP730 / MP750 12V/24V Battery Chargers Instruction and information manual Peak Battery Battery Model No. Rated Input EN Rated Output Output Type Capacity 230V AC 50Hz 1.26A 12V DC 11.4 Amp 12V/24V MP716 12 Amp 30-180Ah 1.1A 24V DC 5 Amp Lead-acid 230V AC 50Hz 1.7A...
- Page 2 WORKING WITH LEAD ACID BATTERIES Use of safety goggles and gloves when working with lead acid batteries is strongly advised. Avoid contact with the electrolyte as this is acidic and is likely to cause burns to the skin or clothes. If this occurs you should rinse the affected area with plenty of water immediately.
- Page 3 3. VOLTAGE SELECTION AND CHARGING RATE WARNING! All selections & connections must be made before the battery charger is switched on. MP716 Set the 12V/24V switch to match the voltage of the battery. If you are charging a small battery or you only require a slower rate of charge, set the switch on the front panel to “MIN”.
- Page 4 3) Check to see that the positive and negative leads are connected to the correct terminals. DECLARATION OF CONFORMITY We declare that the product conforms to the following directives 73/23 CEE, 93/68 CEE, 2004/108/EC, 2002/95/EC (ROHS), EN60335-1, EN60335-2-29, EN50366 Technical Manager Maypole Ltd January, 2015 EMAIL : SALES@MAYPOLE.LTD.UK WEB : WWW.MAYPOLE.LTD.UK...
