Model No.
MP7414
230V AC 50Hz 48W
MP7416
230V AC 50Hz 75W
In order to ensure correct and safe usage of your battery charger, you should read
these instructions carefully. Please store these instructions for future reference.
SAFETY
Ensure that cables are regularly inspected and kept in good condition.
Never use the battery charger if the mains lead or plug is damaged.
Never use the battery charger if the output leads or crocodile clips are damaged.
Never use the battery charger if it has been dropped or damaged in any way.
WARNING: Battery charging produces explosive gases. Prevent flames and sparks.
Provide adequate ventilation during charging.
Do not leave charging batteries unattended for long periods or overnight.
Do not operate the charger above its rated output for long periods.
Monitor charging to ensure that a decreasing level of charge is occurring.
Electrical repairs or replacement of the mains cable should only be carried out by the
manufacturer, its service agent or a suitably qualified electrician / electrical technician in
order to avoid a hazard.
GENERAL SAFETY
This battery charger can be used by children aged from 8 years and above, and persons
with reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children must not play with this battery charger.
Cleaning and user maintenance shall not be carried out by children without supervision.
GASES
The charging process produces flammable and explosive gases - the area in which charging
takes place should be kept well ventilated. Only connect and disconnect the battery leads
when the mains supply is disconnected. Avoid flames or sparks! Do not smoke!
Rated Input
EN Rated Output
12V DC 2.8 Amp
12V DC 4.2 Amp
1
Peak
Battery
Output
Capacity
4 Amp
12 - 48 Ah
6 Amp
20 - 80 Ah
Advertisement
Table of Contents
Related Manuals for MayPole MP7414
Summary of Contents for MayPole MP7414
- Page 1 Peak Battery Model No. Rated Input EN Rated Output Output Capacity MP7414 230V AC 50Hz 48W 12V DC 2.8 Amp 4 Amp 12 - 48 Ah MP7416 230V AC 50Hz 75W 12V DC 4.2 Amp 6 Amp 20 - 80 Ah In order to ensure correct and safe usage of your battery charger, you should read these instructions carefully.
- Page 2 POINTS TO NOTE When not in use store the charger in a dry place to avoid moisture damage. Your Maypole Battery Charger is suitable for INDOOR USE ONLY. Avoid exposure to rain or liquids at all time. The Battery Charger should not be opened. Any attempt at modification or repair by the user will result in the loss of our guarantee.
- Page 3 D) CHARGING Insert the mains plug into the mains supply (230 Volts AC only). Switch on. Your Battery Charger should now be working and the rate of charge will be shown on the ammeter fitted on the front of the charger. When a flat battery is initially connected to the Battery Charger the charging rate should build up quickly.
- Page 4 3) Check to see that the positive and negative leads are connected to the correct terminals. DECLARATION OF CONFORMITY We declare that the product conforms to the following directives 73/23 CEE, 93/68 CEE, 2004/108/EC, 2002/95/EC (ROHS), EN60335-1, EN60335-2-29 Technical Manager Maypole Ltd, 2013 SALES@MAYPOLE.LTD.UK WWW.MAYPOLE.LTD.UK June 2014...
