Riello RS 300/E BLU Installation, Use And Maintenance Instructions
Gas burners, modulating operation
Hide thumbs
Also See for RS 300/E BLU:
- Installation, use and maintenance instructions (56 pages) ,
- Installation, use and maintenance instructions (56 pages)
Related Manuals for Riello RS 300/E BLU
Summary of Contents for Riello RS 300/E BLU
- Page 1 Installation, use and maintenance instructions Gas burners Modulating operation CODE MODEL TYPE 3809098 RS 300/E BLU 09098 D 3809097 RS 400/E BLU 09097 D 3809099 RS 500/E LN 09099 D 2543947 (2) - 06/2007...
-
Page 2: Table Of Contents
CONTENTS Technical data........page 2 Accessories ......... 2 List of available models . -
Page 3: Technical Data
PT 100 3010110 0...36.3 PSI (0...2,5 bar) Output probe 3010213 Pressure 0...232 PSI (0...16 bar) 4...20 mA 3010214 • KIT SOFTWARE INTERFACE: code 3010388 Note. Riello S.p.a. declines all responsibility for the addition of safety devices not provided for herein. -
Page 4: List Of Available Models
230V / 50-60Hz 110/50/60 110V / 50-60Hz 3/400/50 230/50/60 BASIC DESIGNATION EXTENDED DESIGNATION LIST OF AVAILABLE MODELS Designation Electrical supply Starting Code RS 300/E BLU 460V-60Hz Direct 3809098 RS 400/E BLU 460V-60Hz Star/Delta 3809097 RS 500/E BLU 460V-60Hz Star/Delta RS 500/E LN... -
Page 5: Burner Description
BURNER DESCRIPTION (A) 1 Lifting eyebolts 2 Fan 3 Fan motor 4 Air gate valve servomotor 5 Gas pressure test point 6 Combustion head 7 Ignition pilot 8 Flame stability disk 9 Electric panel board - cover 10 Servomotor for gas butterlfy valve 11 Air inlet to fan 12 Manifold 13 Thermal insulation screen for securing... -
Page 6: Packaging - Weight
PACKAGING - WEIGHT (A) - Approximate measurements • The burners stands on a wooden base which inch can be lifted by fork-lifts. Outer dimensions of RS 300/E BLU 77 “ 37 “ 38 “ 11 / 64 1 / 64 3 / 16 packaging are indicated in (A). -
Page 7: Firing Rates
MAXIMUM OUTPUT must be selected in the hatched area of the diagram. MINIMUM OUTPUT must not be lower than the minimum limit shown in the diagram: RS 500/E BLU MODEL RS 300/E BLU 500 kW 1893 MBtu/hr RS 400/E BLU 800 kW 3030 MBtu/hr... -
Page 8: Installation
INSTALLATION BOILER PLATE (A) Drill the combustion chamber locking plate as inch shown in (A). The position of the threaded holes RS 300-400/E BLU 13 can be marked using the thermal screen sup- 25 / 32 “ 17 51 / 64 “... -
Page 9: Position Of Electrodes
For operation on flame-reversal boilers, gas pipes must be adjusted RS 400/E BLU to hole position 4, see Fig. (E). RS 300/E BLU ROTATION OF FAN MOTOR Look at the fan motor's cooling fan from the front and make sure it turns anticlockwise. -
Page 10: Gas Line
GAS LINE (A) The gas train is to be connected on the right of the burner, by flange 1) (A). If it is necessary to connect it on the left of the burner, loosen nuts and screws 3) and 4), remove blind flange 2) together with its gasket and fit them to flange 1) tightening the nuts and screws. -
Page 11: Adjustment Before First Firing
ADJUSTMENTS BEFORE FIRST FIRING Adjustment of the combustion head has been illustrated on page 8. In addition, the following adjustments must also be made: - open manual valves up-line from the gas train. - Adjust the minimum gas pressure switch to the start of the scale. -
Page 12: Combustion Air Adjustment
COMBUSTION AIR ADJUSTMENT Fuel/combustion air must be synchronized with the relevant servomotors (air and gas) by stor- ing a setting curve by means of the electronic cam. To reduce pressure loss and to have a wider adjustment range, it is best to set the servomo- tor to the maximum output used, as near to maximum opening (90°) as possible. -
Page 13: Air Pressure Switch
AIR PRESSURE SWITCH (A) AIR PRESSURE SWITCH CO CHECK Adjust the air pressure switch after having per- formed all other burner adjustments with the air pressure switch set to the start of the scale (A). With the burner running at maximum output, measure CO emission in the flue gases, then progressively obstruct the air intake with the aid of the regulating grille (see fig. -
Page 14: Maintenance
MAINTENANCE Combustion The optimum calibration of the burner requires an analysis of the flue gases. Significant differ- ences with respect to the previous measure- ments indicate the points where more care should be exercised during maintenance. Gas leaks Make sure that there are no gas leaks on the pipework between the gas meter and the burner. -
Page 15: Burner Operation
BURNER OPERATION (A) NORMAL FIRING (seconds) 1 - Thermostat 2 - Motor 3 - Air gate valve 4 - Ignition transformer 5 - Valve pilot 6 - Main valve 7 - Flame 8 - Lock-out BURNER FLAME GOES OUT DURING OPER- ATION If the flame should accidentally go out during operation, the burner will lock out within 1s. -
Page 16: Air/Fuel Control And Power Modulation System
AIR/FUEL CONTROL POWER MODULATION SYSTEM • GENERAL INFORMATION The air/fuel and power modulation system installed on RS burner series provides, a set of integrated functions ensuring top level energy and operational performance from the burner, both for single and grouped burners (e.g. boiler with a double combustion chamber or several generators in parallel). -
Page 17: Appendix
Appendix Layout of electric panel board CONTENTS References layout RS 300/E Layout of unifilar output RS 400/E RS 500/E RS 300/E Star/delta starter operational layout RS 400/E RS 500/E LMV51.100... operational layout LMV51.100... operational layout LMV51.100... operational layout Gas train operational layout LMV51.100... - Page 18 RS 300/E...
- Page 19 - 13HP RS 400/E - 500/E...
- Page 20 RS 300/E...
- Page 21 RS 400/E - 500/E...
- Page 29 RS 300/E - 400/E - 500/E...
-
Page 31: Key To Electrical Layouts
Key to electrical layouts Electronic cam Display and operating unit DC input 4...20 mA DC input 4...20 mA for modifying the remote setpoint Load indicator DC input 4...20 mA Pressure probe Pressure probe Probe Pt100 with 3 wires Probe Pt100 with 3 wires PT/LG-Ni1000 probe DC voltage input 0...10 V DC voltage input 0...10 V for modifying the remote setpoint... - Page 32 RIELLO S.p.A. I-37045 Legnago (VR) Tel.: +39.0442.630111 http:// www.rielloburners.com Subject to modifications...
