Permobil ROHO Smart Check Setup Instructions

Smart Setup Instructions
Smart Check will find and save the inflation setting for you, on your cushion, in your
chair. NOTE: Results may vary based on body type.
• Perform the following steps in the usual environmental conditions.
• The cushion MUST be overinflated to start Smart Setup. You may
temporarily feel unstable; if so, proceed with caution.
• The individual MUST be seated on the cushion in the chair before using
Smart Check.
Sensor Ready
1. Place the cushion
in the chair. Place
the nozzle of the
pump over the
inflation valve.
If a cushion cover
Quick Disconnect
is used, place the
Hybrid
cover on the
Elite SR
cushion before
inflating.
Quick Disconnect
2. Open the inflation valve. Overinflate the cushion
until it bulges.
Close the inflation valve. Remove the pump.
Sensor Ready
Cushion
Hybrid
Elite SR
Cushion
1
Cushion Cover
Inflation Valve
1
Cushion Cover
Inflation Valve
2
Open
2
Close
3
3. Sit in the chair in your usual position.
Pull to remove the tab (first-time use only).
4
4. Make sure the inflation valve is closed.
Attach Smart Check to the cushion. You will
hear a "click" when the connection is secure.
7
Symbols and Lights for Smart Setup
Setup
Button
Red Light
"Remove air."
Check
Button
Green Light
"Setup is complete."
Red Light
"Add air."
Quick Disconnect
