Hardinge GX Series Electrical Manual page 9

GX SERIES SYSTEM DIAGRAM FOR OKUMA OSP-P200M-R
SSU
X4-NCOK
SR1
ST1
SERVO SENSOR UNIT
U3380-0911-001-00
U6
XB-SR
XB-ST
XB-EOUT3
XB-EOUT2
XB-EOUT1
XB-MO1
XB-MI1
XB-EIN3
XB-EIN2
XB-EIN1
SAFETY SPEED MONITOR
A911-2920-01-013
DRAWN RACHEL-C
CHECK SUNNY-L
APPROVE SUNNY-L
TITLE
REF AA2
REV
A1
P1
POWER SUPPLY UNIT
PSU-20-ACL
U3100-0006-001-00
DCA
C
P N
(DC300V)
U1
C1
TO:X13-POS-12
REF AA1/AD1
ST
SR
DRIVER UNIT
MDUA-22-555-MA
U3389-0006-001-00
E1C
E1B
E1A
EPG
SPINDLE PULSE
GENERATER
NC TYPE
DWG NO
PART NO
DESCRIPTION
DCB
DCA
RES
U U1
SPINDLE MOTRO
V V1 11/15 kw 12K r.p.m
W W1
E1015-288-***
G G
X AXIS SERVO MOTOR
BL-ME80-40SN/JF
PA U4404-0005-002-00
POWER
Y AXIS SERVO MOTOR
E1B
BL-ME80-40SN/JF
PB
U4404-0005-002-00
POWER
Z AXIS SERVO MOTOR
E1C
BL-ME200J-30SB/JF
PC
POWER
U4511-0005-002-00
BRC
E2A X AXIS LINEAR SCALE (OP)
Y AXIS LINEAR SCALE (OP)
E2B
E2C
Z AXIS LINEAR SCALE (OP)
MT TYPE
E01\GX 822P200-EAA2
GX 822P200E
DATE ECN.
XBEX
XBEY
XBEZ
VERSION: A1
表單編號 :E40011
