Hardinge GX Series Electrical Manual page 132

入出力信号一覧 IO Signals
CH： 1 MACID： 1 INPUT
Signal Name 信号名
Spindle OVR DOWN PB 主軸ｵｰﾊﾞｰﾗｲﾄﾞ DOWN PB
Spindle OVR UP PB 主軸ｵｰﾊﾞｰﾗｲﾄﾞ UP PB
Spindle orientation PB 主軸割出 PB
Interlock release ｲﾝﾀｰﾛｯｸ解除 PB
Door interlock RESTART PB ﾄﾞｱｲﾝﾀｰﾛｯｸ 再起動 PB
Machine lock PB ﾏｼﾝﾛｯｸ PB
Block skip PB ﾌﾞﾛｯｸｽｷｯﾌﾟ PB
Optional stop PB ｵﾌﾟｼｮﾅﾙｽﾄｯﾌﾟ PB
Single block PB ｼﾝｸﾞﾙﾌﾞﾛｯｸ PB
Spindle CW PB 主軸正転 PB
Spindle STOP PB 主軸停止 PB
Spindle CCW PB 主軸逆転 PB
Spindle neutral PB 主軸空転 PB
Light PB 照明灯 PB
Coolant all ON/OFF PB ｸｰﾗﾝﾄ全入切 PB
Dry run PB ﾄﾞﾗｲﾗﾝ PB
PULSE HANDLE INPUT DATA 0 第1ﾊﾟﾙｽﾊﾝﾄﾞﾙ入力
PULSE HANDLE INPUT DATA 1 第1ﾊﾟﾙｽﾊﾝﾄﾞﾙ入力
PULSE HANDLE INPUT DATA 2 第1ﾊﾟﾙｽﾊﾝﾄﾞﾙ入力
PULSE HANDLE INPUT DATA 3 第1ﾊﾟﾙｽﾊﾝﾄﾞﾙ入力
PULSE HANDLE INPUT DATA 4 第1ﾊﾟﾙｽﾊﾝﾄﾞﾙ入力
PULSE HANDLE INPUT DATA 5 第1ﾊﾟﾙｽﾊﾝﾄﾞﾙ入力
PULSE HANDLE INPUT DATA 6 第1ﾊﾟﾙｽﾊﾝﾄﾞﾙ入力
PULSE HANDLE INPUT DATA 7 第1ﾊﾟﾙｽﾊﾝﾄﾞﾙ入力
Manual int PB 手動割込み PB
Pulse handle addition PB ﾊﾟﾙｽﾊﾝﾄﾞﾙ重畳 PB
Sequence restart PB ｼｰｹﾝｽ復帰 PB
Rapid feed P PB 早送り + PB
Rapid feed N PB 早送り - PB
Pulse handle ON PB 軸選択 ﾊﾟﾙｽﾊﾝﾄﾞﾙ PB
Jog feed P PB 切削送り + PB
Jog feed OFF PB 切削送り 切 PB
Jog feed N PB 切削送り - PB
Setting conf. display select PB 設定確認表示選択 PB
2010/07/06 17:44:48
IOモニタ IO Monitor デバイスネットユニット DeviceNet Unit 最終接続 Lowest Con.
アドレス ビット ラベル 機器記号 形式
Address Bit Label Symbol Type Connector
000 0 ipSPDWN D101S MPIF-BS-DN *
1 ipSPUP D101S MPIF-BS-DN *
2 ipSORT D101S MPIF-BS-DN *
3 ipITLK D101S MPIF-BS-DN *
4 ipDIRS D101S MPIF-BS-DN *
5 ipMLOK D101S MPIF-BS-DN *
6 ipBLSK D101S MPIF-BS-DN *
7 ipOPST D101S MPIF-BS-DN *
001 0 ipSBLK D101S MPIF-BS-DN *
1 ipSCW D101S MPIF-BS-DN *
2 ipSSP D101S MPIF-BS-DN *
3 ipSCCW D101S MPIF-BS-DN *
4 ipSNTR D101S MPIF-BS-DN *
5 ipLION D101S MPIF-BS-DN *
6 ipALLCL D101S MPIF-BS-DN *
7 ipDRYR D101S MPIF-BS-DN *
003 0 iPHI10 D101S MPIF-BS-DN *
1 iPHI11 D101S MPIF-BS-DN *
2 iPHI12 D101S MPIF-BS-DN *
3 iPHI13 D101S MPIF-BS-DN *
4 iPHI14 D101S MPIF-BS-DN *
5 iPHI15 D101S MPIF-BS-DN *
6 iPHI16 D101S MPIF-BS-DN *
7 iPHI17 D101S MPIF-BS-DN *
004 0 ipMINT D101S MPIF-BS-DN *
1 ipPHAD D101S MPIF-BS-DN *
2 ipRSTR D101S MPIF-BS-DN *
3 ipRPDP D101S MPIF-BS-DN *
4 ipRPDN D101S MPIF-BS-DN *
5 ipPHON D101S MPIF-BS-DN *
6 ipJOGP D101S MPIF-BS-DN *
7 ipJGF D101S MPIF-BS-DN *
005 0 ipJOGN D101S MPIF-BS-DN *
1 ipFSSETC D101S MPIF-BS-DN *
接続器 接続点 接続器 接続点 制御機器
Port Connector Port
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
電線番号
Ctrl. Device Wire Number
PANEL
PANEL
PANEL
PANEL
PHDU1
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
PANEL
IO List W4001-529-925-2 2/10
