Hardinge GX Series Electrical Manual page 140

CH： 1 MACID： 3 OUTPUT
Signal Name 信号名
Magazine unit manual CW oparati ﾏｶﾞｼﾞﾝﾕﾆｯﾄ 手動正転運転
Magazine unit manual CCW opara ﾏｶﾞｼﾞﾝﾕﾆｯﾄ 手動逆転運転
Spindle tool in cylinder unclamp 主軸工具(内ｼﾘﾝﾀﾞ)ﾕﾙﾒ YV
Spindle air blow YV 主軸ｴｱﾌﾞﾛｰ YV
Work air blow (nozzle) YV ﾉｽﾞﾙｴｱﾌﾞﾛｰ YV
Chip flush-out motor on KM 切粉洗流ﾓｰﾀ入 KM
MG POT CHANGE POSITION YV MGﾎﾟｯﾄ交換位置 YV
MG POT TURN POSITION YV MGﾎﾟｯﾄ旋回位置 YV
Air purge SOL ｴｱｰﾊﾟｰｼﾞ SOL
Attachment spindle air blow ｱﾀｯﾁﾒﾝﾄｴｱﾌﾞﾛｰ YV
Spindle tool unclamp 主軸工具ﾕﾙﾒ HL
Spindle tool clamp 主軸工具ｼﾒ HL
Spindle tool change cycle 工具交換準備 HL
Working fin buzzer KA 作業完了ﾌﾞｻﾞｰ KA
Touch sensor air blow YV ﾀｯﾁｾﾝｻｰｴｱﾌﾞﾛｰ YV
Spindl-head cooling unit ON 主軸頭冷却ﾕﾆｯﾄ入り
Oil hole motor on KM ｵｲﾙﾎｰﾙﾓｰﾀ入 (ｽﾙｰSP) KM
4th axis clamp YV A/C(第4)軸ｸﾗﾝﾌﾟ YV
Work washing gun motor on KM ﾜｰｸ洗浄ｶﾞﾝﾓｰﾀ入 KM
Touch probe power on KA ﾚﾆｼｮｰﾀｯﾁﾌﾟﾛｰﾌﾞ入/切
External M command 1 (M181) K 外部Mｺｰﾄﾞ信号 1 (M181) KA
External M command 2 (M182) K 外部Mｺｰﾄﾞ信号 2 (M182) KA
2010/07/06 17:44:49
IOモニタ IO Monitor デバイスネットユニット DeviceNet Unit 最終接続 Lowest Con.
アドレス ビット ラベル 機器記号 形式
Address Bit Label Symbol Type Connector
001 0 oMCW D1033
1 oMCCW D1033
2 oISUC D1033
3 oSPAR D1033
4 oNSAR D1033
5 oCPFL D1033
6 oRSSP D1033
7 oRSMG D1033
002 0 oARPG D1034
1 oATAR D1034
2 oSPUL D1034
3 oSPCL D1034
4 oTCRL D1034
5 oBUZZ D1034
003 0 oTSAR D1034
1 oSHCOL D1034
2 oOHLM D1034
5 oACL4 D1034
6 oWSGN D1034
7 oPPON D1034
* 004 0 oEXM1 D1035
* 1 oEXM2 D1035
接続器 接続点 接続器
Port Connector
DN-OC-16PC X2 A1 X2-D1033-8
DN-OC-16PC X2 A2 X2-D1033-9
DN-OC-16PC X2 A3 X2-D1033-A
DN-OC-16PC X2 A4 X2-D1033-B
DN-OC-16PC X2 A6 X2-D1033-C
DN-OC-16PC X2 A7 X2-D1033-D
DN-OC-16PC X2 A8 X2-D1033-E
DN-OC-16PC X2 A9 X2-D1033-F
DN-OC-16PC X1 A1 X1-D1034-0
DN-OC-16PC X1 A2 X1-D1034-1
DN-OC-16PC X1 A3 X1-D1034-2
DN-OC-16PC X1 A4 X1-D1034-3
DN-OC-16PC X1 A6 X1-D1034-4
DN-OC-16PC X1 A7 X1-D1034-5
DN-OC-16PC X2 A1 X2-D1034-8
DN-OC-16PC X2 A2 X2-D1034-9
DN-OC-16PC X2 A3 X2-D1034-A
DN-OC-16PC X2 A7 X2-D1034-D
DN-OC-16PC X2 A8 X2-D1034-E
DN-OC-16PC X2 A9 X2-D1034-F
DN-OC-16PC X1 A1 X1-D1035-0
DN-OC-16PC X1 A2 X1-D1035-1
接続点 制御機器 電線番号
Port Ctrl. Device Wire Number
A1 X4-K9 X4-K9.
A1 X4-K10 X4-K10.
A1 X4-K11 X4-K11.
A1 X4-K12 X4-K12.
A1 X4-K13 X4-K13.
A1 X4-K14 X4-K14.
A1 X4-K15 X4-K15.
A1 X4-K16 X4-K16.
A1 X5-K1 X5-K1.
A1 X5-K2 X5-K2.
A1 X5-K3 X5-K3.
A1 X5-K4 X5-K4.
A1 X5-K5 X5-K5.
A1 X5-K6 X5-K6.
A1 X5-K9 X5-K9.
A1 X5-K10 X5-K10.
A1 X5-K11 X5-K11.
A1 X5-K14 X5-K14.
A1 X5-K15 X5-K15.
A1 X5-K16 X5-K16.
A1
A1
IO List W4001-529-925-2 10/10
