Hardinge GX Series Electrical Manual

Vertical machining center

page of 141

/ 141
Bookmarks

Quick Links

Download this manual

GX SERIES

VERTICAL MACHINING CENTER

OKUMA

OSP-P200M-R

ELECTRICAL MANUAL

Issue：A4

Dec, 2011

GX 000822P200

荷蘭商哈廷國際科技股份有限公司台灣分公司

Hardinge Machine Tools B.V., Taiwan Branch

Need help?

Do you have a question about the GX Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hardinge GX Series

Page 1 GX SERIES VERTICAL MACHINING CENTER OKUMA OSP-P200M-R ELECTRICAL MANUAL Issue：A4 Dec, 2011 GX 000822P200 荷蘭商哈廷國際科技股份有限公司台灣分公司 Hardinge Machine Tools B.V., Taiwan Branch...
Page 2 GX SERIES ELECTRICAL MANUAL THIS MANUAL CONSISTS OF FOLLOWINGS: ● OKUMA OSP-P200M-R ELECTRIC DIAGRAM……………………………. GX 822P200E Issue：A4 PARTS LIST………………………………………... GX 822P200P Issue：A2 ADDENDUM-1...
Page 3 GX SERIES VERTICAL MACHINING CENTER OKUMA OSP-P200M-R ELECTRICAL DIAGRAM Issue：A4 Dec, 2011 GX 822P200E 荷蘭商哈廷國際科技股份有限公司台灣分公司 Hardinge Machine Tools B.V., Taiwan Branch...
Page 4 ELECTRICAL DIAGRAM 電路圖 FOR:GX 600 GX 800 GX 1000...
Page 5 ELECTRIC DIAGRAM DWG NO. TITLE VERSION GX 822P200-EAA1 OKUMA SYSTEM DIAGRAM GX 822P200-EAA2 OKUMA SYSTEM DIAGRAM GX 822P200-EAA3 OKUMA SYSTEM DIAGRAM(with 4th axis) GX 822P200-EAA4 SYSTEM DIAGRAM FOR I/O MODULE GX 822P200-EAA5 SERVO SYSTEM GX 822P200-EAA6 SERVO SYSTEM(with 4th axis) GX 822P200-EAB1 POWER DIAGRAM 1(WITH TRANSFORMER) GX 822P200-EAB2...
Page 6 ELECTRIC DIAGRAM DWG NO. TITLE VERSION GX 822P200-EAH1 POWER SUPPLY WITH BUILT-IN ACL GX 822P200-EAH2 ALL-IN-ONE DESIGN INVERTER SPINDLE GX 822P200-EAH3 ALL-IN-ONE DESIGN INVERTER FEED AXES GX 822P200-EAH4 SINGLE PURPOSE INVERTER UNIT(4TH) GX 822P200-EAH5 SAFETY SPEED MONITORING 1 GX 822P200-EAH6 SAFETY SPEED MONITORING 2 GX 822P200-EAI1 SYSTEM OF OPERATION PANEL...
Page 7 ELECTRIC DIAGRAM DWG NO. TITLE VERSION GX 822P200-EBA5 DI INTERFACE GX 822P200-EBA6 DI INTERFACE GX 822P200-EBB1 DO INTERFACE GX 822P200-EBB2 DO INTERFACE GX 822P200-EBB3 DO INTERFACE GX 822P200-EBB4 DO INTERFACE GX 822P200-EBB5 DO INTERFACE GX 822P200-EBB6 DO INTERFACE GX 822P200-EBC1 I/O ARRANGEMENT PLAN(1) GX 822P200-EBC2 I/O ARRANGEMENT PLAN(2)
Page 8 DESCRIPTION DATE ECN. GX SERIES SYSTEM DIAGRAM FOR OKUMA OSP-P200M-R X4-KBD X1-KBD KEY BOARD PNC2-15KBV-QI PNC2 A911-3327-01-010 PANEL COMPUTER UNIT PNC2-15V MPIF A911-3323-01-010 X7-F_KEY PANEL COMMUNICATION UNIT MPIF-BS-DNP A911-3450-01-010 X12-RX X11-TX SVDN1 STANDARD PANEL MP-B-MS A911-2756-01-010 SVDN2 POWER ON SEQUENCE UNIT...
Page 9 DESCRIPTION DATE ECN. GX SERIES SYSTEM DIAGRAM FOR OKUMA OSP-P200M-R POWER SUPPLY UNIT PSU-20-ACL U3100-0006-001-00 (DC300V) X4-NCOK TO:X13-POS-12 REF AA1/AD1 SPINDLE MOTRO 11/15 kw 12K r.p.m SERVO SENSOR UNIT E1015-288-*** DRIVER UNIT U3380-0911-001-00 MDUA-22-555-MA U3389-0006-001-00 XBEX X AXIS SERVO MOTOR...
Page 10 DESCRIPTION DATE ECN. GX SERIES SYSTEM DIAGRAM FOR OKUMA OSP-P200M-R POWER SUPPLY UNIT PSU-20-ACL U3100-0006-001-00 (DC300V) X4-NCOK TO:X13-POS-12 REF AA1/AD1 SPINDLE PULSE GENERATER SPINDLE MOTRO DRIVER UNIT 11/15 kw 12K r.p.m MDUA-22-555-MA E1015-288-*** U3389-0006-001-00 SERVO SENSOR UNIT XBEX U3380-0911-001-00 X AXIS SERVO MOTOR...
Page 11 DESCRIPTION DATE ECN. I/O MODULE X1D103S TO:POS X1 TO:REF AA1/AJ1 DN-SLV PCB BOARD D1030 X1D1030 DN-IC X2D1030 TR-20P-V1 D1031 X1D1031 DN-IC X2D1031 MAGAZINE/ATC UNIT TR-20P-V1 X,Y,Z / 4TH LIMIT SWITCH D1032 X1D1032 DN-IC MAGAZINE OP. PANEL X2D1032 LS/SOL/LIGHT TR-20P-V1 (OPTION) HEADSTOCK UNIT LS\PB D1033 X1D1033...
Page 12 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAA5 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 13 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAA6 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 14 DESCRIPTION DATE ECN. 3 AC380V-400V-415V-440V CUSTOMER SIDE 3P 125A GX 600/800/1000 3P 150A GX 1300/1600 RF SF TF TRANSFORMER 380V-400V-415V-440V /200V-220V 3 25 KVA(GX 600/800/1000) 3 35 KVA(GX 1300/1600) (OPTION) R0 S0 LINE FILTER(CE) LOAD 3P20A (FOR 60HZ CTS) 3P16A SET POINT:3.2A (REF/AZ) SET POINT:11.8A(50HZ)(CTS)
Page 15 DESCRIPTION DATE ECN. 3 AC220V CUSTOMER SIDE 3P 125A GX 600/800/1000 3P 150A GX 1300/1600 R0 S0 LINE FILTER(CE) LOAD 3P20A (FOR 60HZ CTS) 3P16A SET POINT:3.2A (REF/AZ) SET POINT:11.8A(50HZ)(CTS) QFB1 SET POINT:11.6A(60HZ)(CTS) MTR1 COOLANT PUMP MOTOR 3 540W 50HZ 3 800W 60HZ 3 2.2KW 50HZ (CTS) 3 4.0KW 60HZ (CTS)
Page 16 DESCRIPTION DATE ECN. 3 AC 220V QFB6 OIL-COOLANT 3P16A UNIT SPINDLE MOTOR OIL COOLANT UNIT 3 700W 50/60 HZ (OP) 3 1600W 50/60 HZ (for BT50 UNIT ZF GEAR BOX) +24E TO:REF/BA410 KARA (REF/AC5) QFB5 2P3A HA-50AF REFRIERATOR OF POWER CASE 1 250W *220V 50/60HZ (OPTION) TO REF:AB1/AB2...
Page 17 DESCRIPTION DATE ECN. 3 AC 220V QFB2 SET POINT:1.84A (50HZ) (REF/AC4) (REF/AC2) 3P2A SET POINT:1.45A (60HZ) X25(1) MTR3 CHIP CONVERYOR MOTOR X25(2) 3 200W 50/60HZ 除屑機馬達 X25(3) (OPTION) RSC3 TO REF:AC1 FRT3 (REF/AC4) X25(4) QFB3 (REF/AC5) 3P10A SET POINT:2.0A MTR6 MAGAZINE ROTATION MOTOR 儲刀倉旋轉馬達...
Page 18 DESCRIPTION DATE ECN. 3 AC 220V (AE202) (AE202) TC/740VA AC 110V KA35A KA35B 201A 210 TO REF:AC4/AC5/AC6 F3/4A F1/6A 220V 110V TO REF:AB4/AB8/AC4 200V TO REF:AC4/AC5/AC6 AC 24V F2/6A F4/4A TO REF:AB9/AC6 (WORK LAMP) 211A N24BR F17/2A N24A (OUTPUT MODULE ) DC 0V(-) F22/1A N24B...
Page 19 DESCRIPTION DATE ECN. AC 220V POWER SUPPLY DC 24V +24P F18/4A +24E (INPUT MODULE) DC 24V (AE202) (AE202) (REF:BA1~6/AC1/AB8) KA35A KA35B F19/4A +24V +24VA +24VZ (SOLENOID) DC 24V(4A) (REF:AC3) +24V (LIGHT & TIMER) (REF:AC1/AC2/AC3) RING CORE( +24P1 F20/4A +24B (REF:AG1/AI2/AJ1) DC 24V (DEVICE NET COMMUNICATION) DC 24V(4A)
Page 20 DESCRIPTION DATE ECN. FUSE UNIT F1 (6A) AC 220V (REF:AB6) +24E +24E (REF:AB7) F2 (6A) (REF:AB6) AC 220V (REF:AB1/AB2) F3 (4A) AC 110V (REF:AB6) F4 (4A) AC 24V FOR WORK LAMP (REF:AB6) (REF:AB6/AC6) (1A) AC 220V FOR SPD. (REF:AH2) F9 (1A) AC 220V FOR SPD.
Page 21 DESCRIPTION DATE ECN. TO REF:AB7 TO REF:AB7 +24V DC24V KARD1 KARSP1 ATC/MAG. MOTOR RELAY 1 X2-A1 X2-B1 刀臂/刀倉馬達繼電器1 A AC2 (REF/AD4) KARSP2 ATC/MAG. MOTOR RELAY 2 刀臂/刀倉馬達繼電器2 A AC2 SQL12 SAK2 POWER CASE DOOR INTERLOCK KAR24A 強電箱門連鎖 A AC4 (for option CE) +24E TO REF:BN...
Page 22 DESCRIPTION DATE ECN. TO:REF/AB7 TO:REF/AB7 +24V X15(1) X15(4) HLP46 ALARM DISPLAY (OP) X4-K2 故障指示燈 (REF/BB1) X15(5) BUZZER X5-K6 蜂鳴器 (REF/BB3) X15(2) HLP47 M02/M30 DISPLAY (OP) X4-K3 工作完了指示燈 (REF/BB1) X15(3) HLP45 CYCLE STRAT LAMP (OP) X4-K4 程式啟動指示燈 (REF/BB1) X16(1) X16(4) HLP60 SPINDLE TOOL UNCLAMP LAMP X5-K3 主軸鬆刀指示燈...
Page 23 DESCRIPTION DATE ECN. TO:REF/AB7 TO:REF/AB7 +24V DC24V KA35A (REF/AE202) +24VB KA35B (REF/AE202) +24VA TO:REF/AB7 YVS1 XT2/X4/X5 X4/X5 SPINDLE AIR PURGE X5-K1 主軸風圈電磁閥 (REF/BB308) VDI1 YVS2 ORIENTATION AIR BLOW X5-K2 主軸定位時清潔刀具V型溝 (REF/BB310) VDI2 YVS5 X13(15) X13(7) SPINDLE TOOL UNCLAMP X4-K11 主軸放刀 (REF/BB212) VDI5 YVS6...
Page 24 DESCRIPTION DATE ECN. TO:REF/AB6 TO:REF/AB6 AC110V COOLING FAN FOR SERVO UNIT 伺服單元冷卻風扇 AUTO POWER OFF (OP) KAR24 自動斷電 (REF/AE3) KAR24A (REF/AC1) (option for CE) K35A (REF/AE2) 210A K35B (REF/AE2) TO:REF/AB6 XT1/X4/X5 X4/X5 COOLANT A AB1(2) KARE 冷卻水 (REF/AC5C3) RCS2 KARF (REF/AC5B3) CHIP FLUSHING (OP) X4-K14...
Page 25 DESCRIPTION DATE ECN. TO:REF/AB6 TO:REF/AB6 AC110V YVS11 COOLANT ON (OP) X4-K1 冷卻水馬達電磁閥 RCS9 (REF/BB108) YVS8 COOLANT THROUGH SPD. X5-K11 中空切屑水(OP) RCS7 (REF/BB412) YVS20 RELEASE AIR KARD (FOR CTS FUNCTION) (REF/AC3) 排氣閥 (中心給水時使用) KARE (REF/AC5) 190A MAG. CW ROTATION X4-K9 (FOR SWING ARM TYPE) RCS25 (REF/BB208) (REF/AB6)
Page 27 DESCRIPTION DATE ECN. X4-NCOK-SSU X13-POS-12 P24A P24A X13-B2 DCOM P24A NC 正常 KANCOK NC OK AD101 X13-B1 AD104 AD902 AD912 AE202 NCOKIN NCOKOUT N24B X13-A1 N24B X11-P24/N24-SSU X13-POS-A1 X13-B3 感應器電源 P24A SENSOR POWER SUPPLY N24B X13-A3 N24B KANCOK X13-A4 NCOKOUT (AD102) X13-B4 NCOKOUTC...
Page 29 DESCRIPTION DATE ECN. TO REF:AD2 TO REF:AD2 AD209 安全繼電器D1 安全繼電器D1 SAFET RELAY D1 SAFET RELAY D1 KAD1 KAD1 (AD405) (AD405) X5-D1 X5-D1 X5-D1 X5-D1 X4-POS-2 AD301 AD303 AD210 AD210 AD209 AD301 AD301 AD302 X3-POS-1 XB-ERR XB-ERR AD209 AD301 AD301 AD302 EM1A-2 EM2A-2 安全速度監視器...
Page 33 DESCRIPTION DATE ECN. N24B X9-POS-1 KA11 NC 極限開關解除 N24B N24B X9-A1 NC-AXIS STROKE END N24B SEN6 X9-B1 SEN1 X9-POS-2 AD802 X9-A2 SEN1 N24B X9-B2 SEN2 NC極限開關解除 X9-POS-3 AD803 X9-A3 軸行程終端 SEN2 NC-AXIS STROKE END X9-B3 軸行程終端解除 BIT7 SEN3 iSTEN_b AXIS STROKE END RELEASE X9-POS-4 AD804 X9-A4...
Page 34 DESCRIPTION DATE ECN. XB-OPR-P1 BIT4 X8-POS-12 KAE1 KA10 KANCOK BIT1 SEN6 AD902 X8-A1 NC軸控制ON (OPR-ON) OPNC1 OPRON-N (AG113) (AD102) NC-AXIS CONTROL ON (AD201) P24A X8-A2 KAE1 P24A OPRON ERPW BIT0 AD904 X8-B1 NC軸電源ON (PW-ON) PWNC1 PWON-N (AD310) NC-AXIS POWER ON (AD201) X8-B2 P24A...
Page 35 DESCRIPTION DATE ECN. X2E1 X12-POS-1 KAE1 X12-POS-9 N24BR AE101 X2-B2 X12-A9 X12-A1 N24BR N24BR (AD201) REF:AB6 AE102 P24A X2-A2 X12-B9 X12-B1 N24BR P24AB X12-POS-10 X12-A10 N24BR X12-B10 N24BR X12-POS-7 AE102 X12-A7 X12-POS-3 AE102 X12-A3 X12-POS-3 P24A X12-B3 P24AB X12-POS-5 X12-B5 P24AB XB-BRC-U1 XB-DC1-U1...
Page 36 DESCRIPTION DATE ECN. P24A X7-POS-12 P24A X7-B2 P24A 控制電源ON-A KA35A KAE1 KA10 KANCOK CONTROL POWER ON-A AE202 X7-A2 AB6/7 AC3/4 PWON (AD201) (AG113) (AD102) AD211 KA35B 控制電源ON-B CONTROL POWER ON-B BIT3 AB6/7 AC3/4 AD211 X5-POS KAE1 P24A X5-B10 BIT5 P24A (AD201) XBFP5 AE205...
Page 37 DESCRIPTION DATE ECN. XB-MC-P1 KMPS AM101 NC軸DC電源裝置ON MS2-COM NC-AXIS DC POWER UNIT ON KAE1 N24B X15-A1 NCCTL (AD201) X15-B1 P24A KAE1 N24B X15-A6 MPOFF (AD201) P24A X15-B6 P24A X15-POS-78 AE309 A100A1 X15-A7 A100A1 AE310 A100A1C X15-B7 A100A1C X15-B8 SHUTOFF (AD114) X15-A8 X15COM1 X15-POS-9...
Page 38 DESCRIPTION DATE ECN. PANEL POWER SUPPLY AG116 X13-B10 P24A FANOK X13-A10 X2-DCIN N24B REF:AB7 N24B +24B 面板電源 +24V PANEL POWER SUPPLY 0VPB X13-POS-78 X5-OPR-12 NC 裝置電源ON AG103 XBFP5 X13-A7 NCPWON PWR.ON1 NC-UNIT POWER ON (AD106) AG104 X13-B7 NCPWONC PWR.ON2(FG) AG105 NC裝置電源OFF X13-A8 NCPWOFF...
Page 40 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAG3 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 41 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAG4 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 42 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAG5 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 43 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAG6 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 44 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAG7 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 48 DESCRIPTION DATE ECN. XB-C-P1 PSRDY-N SVALM-N TO:U1 PSD-N X4-NCOK-SSU XB-DCA-P1 XB-DCB-P1 +24V X8-POS-12 XB-OPR-P1 X8-B2 P24A PWON X8-B1 SWITCH PWNC1 PWON-N X8-A2 P24A OPRON 1 2 3 4 5 X8-A1 OPNC1 OPRON-N XB-ACA-P1 3P5A QFB7 L13C XB-MC-P1 L23C AM101 KMPS L33C AC 110V RCSKMP...
Page 49 DESCRIPTION DATE ECN. TO:U2(OPTION) XB-C1-U1 XB-C2-U1 PSRDY-N PSRDY-N SVALM-N SVALM-N TO:P1 PSD-N PSD-N XB-DCA-U1 XB-DCB-U1 X1-SR1-SSU X2-ST1-SSU XB-SR-U1 XB-ST-U1 SLDI SLD1 SLD1 SLDI-N SLD1-N SLD1-N XB-ST-U1 (option) SWITCH 1 2 3 4 5 XT-U1 XT6M SPINDLE MOTOR XB-MO1 XB-EPG-U1 AA-RT AA-RT XB-RES-U1 XT6M...
Page 52 DESCRIPTION DATE ECN. XB-ST-U6 XB-SR-U6 XB-SR-U1 X2-ST1-SSU SLD1 SLD1 SLD1 SLD1 SLD1-N SLD1-N SLD1-N SLD1-N XB-EIN1 XBEX XB-EOUT1 X AXIS ENCODER XB-E1A-U1 ELD-N ELD-N X-AXIS ELD-N ELD-N ERF:EAH3 XB-EIN2 XBEY XB-EOUT2 Y AXIS ENCODER XB-E1B-U1 ELD-N ELD-N Y-AXIS ELD-N ELD-N ERF:EAH3 XB-EIN3 SWITCH...
Page 53 DESCRIPTION DATE ECN. X18-POS-1 X2-POS-1 安全繼電器D1 SAFETY RELAY D1 X2D1 XB-GURD KAD1 N24A P24A X2-B2 X18-1-2 X2-1-11 N24A P24A N24A P24A (AD405) AD411 AH605 加工模式1 X2-A2 X18-1-1 X2-1-1 D1IN Bit0 MD1P PMODE1 Production Mode 1 iCEPRDMD AH606 設定模式1 X2-1-4 Bit5 Bit1 MD1S SMODE1...
Page 54 DESCRIPTION DATE ECN. 操作箱面板計算機 X2-USB Panel Computer OPERATION BOX X3-USB REF:AI3 X6 - Ether 〈〉 SVDN1 〈〉 X2 - SVDN1 REF:AI3 〈〉 X3 - SVDN1 X4-KBD REF:AJ1 〈〉 X1 - SVDN1 REF:AI3 〈〉 SVDN2 〈...
Page 55 DESCRIPTION DATE ECN. REF:AI16 面板電源面板計算機 Panel Power Supply Panel Computer X1-DCOUT X8-PS-AR1 AI201 　　 +3.3V +3.3V AI202 X2-DCIN +24B AI203 +24V AI204 AI205 0VPB +12V +12V AI206 AI207 PWR_BTN PWR_BTN AI208 PWR_OK PWR_OK AI209 UPS_FAN UPS_FAN AI210 FAIL# FAIL# AI211 +3.3V +3.3V...
Page 56 DESCRIPTION DATE ECN. 面板計算機 Panel Computer REF:AI15 X4-KBDV-AR1 X1-KBD 鍵盤 AI321 Key Board AI322 AI323 AI324 AI325 AI326 網路線中繼器 X6-Ether-AR1 XB1-X32 Adapter AI331 (RJ45) TD+(Pair3) TD+(Pair3) AI332 TD-(Pair3) TD-(Pair3) AI333 RD+(Pair2) RD+(Pair2) AI334 RD-(Pair2) RD-(Pair2) AI335 (Pair1) (Pair1) AI336 (Pair1) (Pair1) AI337...
Page 57 DESCRIPTION DATE ECN. X2-D101S CN1-AP2 D101S 通信基盤標準面板 AI401 通信基板 Communicaion AI402 Board AI403 AI404 AI405 AI406 AI407 AI408 AI409 AI410 AI411 AI412 AI413 AI414 AI415 AI416 复位／复位／ RESET RESET AI417 AI418 AI419 AI420 DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO...
Page 58 DESCRIPTION DATE ECN. 通用開關附加面板(1) X11-D101S X2-AP4 D101S 通信基盤 (MPINOUT) AI501 通信基板 REF:AI1/AI17 Communicaion AI502 Board AI503 AI504 TXSYNC1+ RXSYNC1+ AI505 TXSYNC1- RXSYNC1- AI506 TXD1+ RXD1+ AI507 TXD1- RXD1- X12-D101S X1-AP4 RXSYNC1+ TXSYNC1+ RXSYNC1- TXSYNC1- RXD1+ TXD1+ RXD1- TXD1- 通用開關附加面板(2) X2-AP5 (MPINOUT) AI524 RXD1-...
Page 60 DESCRIPTION DATE ECN. D101S 通信基盤檢查通信基板 CHECK Communicaion Board ： REF:AI18 X3U-D101S D101S 0V 24V ：： OUTA0 OUTCOMA OUTA1 OUTCOMA OUTA2 OUTCOMA OUTA3 OUTCOMA N24B POWERA- P24A POWERA+ POWERA- POWERA+ 0V 24V OUTBOP6 OUTBOPCOM OUTBOP7 OUTBOPCOM OUTBOP7 OUTBOPCOM OUTBOP7 OUTBOPCOM POWERB-...
Page 61 DESCRIPTION DATE ECN. X4-D101S SA37N 通信基盤 D101S 通信基板 Communicaion Board XPHX 脈衝手輪軸 REF:AI19 P1IN9 XB-CPH-MPA Pulse Handle X-Axis XPHY 脈衝手輪軸 P1IN8 Pulse Handle Y-Axis XPHZ 脈衝手輪軸 P1IN7 Pulse Handle Z-Axis XPH4 脈衝手輪第軸 P1IN6 Pulse Handle The Fourth-Axis XPH5 脈衝手輪第...
Page 62 DESCRIPTION DATE ECN. X2-MKEY X8-D101S 通信基盤 D101S 通信基板 AI901 自動運轉 Communicaion Board MIN0 Auto Running AI902 運轉 MIN1 MDI Running AI903 手動運轉 MIN2 Manual Running AI904 程式運轉 MIN3 Program Running AI905 參數 MIN4 Parameter AI906 原點設定 MIN5 Origin AI907 刀具數據 MIN6 Tool Data AI908...
Page 63 DESCRIPTION DATE ECN. 通信基盤 D101S REF:AI15 通信基板 Communication Board 面板計算機 Panel Computer X7-FKEY-AR X6-D101S AI1001 FIN0 AI1002 FIN1 AI1003 FIN2 AI1004 FIN3 AI1005 FIN4 AI1006 FIN5 AI1007 FIN6 AI1008 FIN7 AI1009 FIN8 AI1010 FIN9 AI1011 COM (+5) DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L...
Page 65 DESCRIPTION DATE ECN. CN4-AP2 標準パネル SA4N XFOVA MSR3(A) Jog Feed Override XFOVF MSR3(F) XFOVB MSR3(B) XFOVE MSR3(E) XFOVC MSR3(C) XFOVG MSR3(G) COM(+12V) 標準パネル CN5-AP2 SA3N1 XMFS0 iMFS0 Manual Feed Override XMFS1 iMFS1 XMFS2 iMFS2 XMFS3 iMFS3 XMFS4 iMFS4 XMFS5 iMFS5 XMFS6 iMFS6 XMFS7...
Page 66 DESCRIPTION DATE ECN. X3-SVDN1 X3-CH1-SSU SVDN1 AI1301 SL1DI SL1DO AI1302 SL1DI-N SL1DO-N AI1303 SL1DO SL1DI AI1304 SL1DO-N SL1DI-N AI1305 N.C. N.C. AI1306 N.C. N.C. AI1307 AI1308 open 1 2 3 4 5 DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAI13 VERSION:...
Page 68 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAI15 VERSION: SUNNY-L GX 822P200E APPROVE PART NO TITLE AI15 表單編號 :E40011...
Page 69 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAI16 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE AI16 表單編號 :E40011...
Page 70 DESCRIPTION DATE ECN. X5(PH2) DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAI17 VERSION: SUNNY-L GX 822P200E APPROVE PART NO TITLE AI17 表單編號 :E40011...
Page 72 DESCRIPTION DATE ECN. X5(PH2) DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAI19 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE AI19 表單編號 :E40011...
Page 73 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAI20 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE AI20 表單編號 :E40011...
Page 75 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAI22 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE AI22 表單編號 :E40011...
Page 76 DESCRIPTION DATE ECN. 201A P24A P24A P24A N24B N24B N24B +24B 0VPB DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAI23 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE AI23 表單編號 :E40011...
Page 77 DESCRIPTION DATE ECN. 通信基盤通信基板 X1-SVDN1 XB9-D101S Communicaion Board MPIF-B-DNP Z-DN1 SVDN1 註 1Turn D101S 0VPB (0V) 无内置終端電阻 CANL2 CAN- CAN- DRAIN2 (內藏) (內置) CANH2 CAN+ CAN+ 將扭至 +24B (+24V) 裝置 X1-POS CAN- CAN+ 遠程終端通信裝置 X1D103S X2D103S DN-SLV 0VPB CANL2 CAN- CAN-...
Page 78 DESCRIPTION DATE ECN. 遠程終端通信装置遠程終端通信装置 X1D103S DN-SLV X2D103S X1D104S DN-SLV X2D104S 0VPB CANL2 CAN- CAN- CAN- CAN- DRAIN2 CANH2 CAN+ CAN+ CAN+ CAN+ +24B X4LD103S X4UD103S X4LD104S X4UD104S +24B 0VPB 〈OP時追加〉〈選配追加〉〈〉 Addition OP DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L...
Page 79 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAK1 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 80 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAK2 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 81 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAK3 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 82 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EAK4 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 84 DESCRIPTION DATE ECN. X4LD1030 DN-IC-16C DC 24V D1030 DC 24V POWER SUPPLY +24E X4UD1030 +24E CHECK CH:1 ID:03 X1TR20P-A X1D1030-01 ADR:000 +24E SQL6 SPD. TOOL UNCLAMP POS Bit0 iISUC SQL7 SPD. TOOL CLAMP POS Bit1 iISCL X1D1030-23 SPS1 Bit2 AIR PRESSURE DETECT iADY_b AC MOTOR OVERLOAD Bit3...
Page 85 DESCRIPTION DATE ECN. DN-IC-16C DC 24V D1030 DC 24V POWER SUPPLY +24E CHECK CH:1 ID:03 X1TR20P-B X2D1030-89 ADR:001 +24E CE TYPE HARDWARE TYPE ENABLE Bit0 SQL30 POT SPD. SIDE Bit1 iRSSP X2D1030-AB SQL31 Bit2 POT MAG. SIDE iRSMG REF:AB5 ATC/MAG. MOTOR OVERLOAD Bit3 iTAOC DETECT...
Page 86 DESCRIPTION DATE ECN. X4LD1031 DN-IC-16C DC 24V D1031 DC 24V POWER SUPPLY +24E X4UD1031 +24E CHECK CH:1 ID:03 X2TR20P-A X1D1031-01 ADR:002 +24E SPB46 X16(5) SPINDLE MANUAL TOOL UNCLAMP Bit0 iTUPB BUTTON SPB70 X16(6) SPINDLE MANUAL TOOL CLAMP Bit1 iTCPB BUTTON X1D1031-23 SPB71 X16(7)
Page 88 DESCRIPTION DATE ECN. X4LD1032 DN-IC-16C DC 24V D1032 DC 24V POWER SUPPLY +24E X4UD1032 CHECK CH:1 ID:03 X3TR20P-A X1D1032-01 ADR:004 +24E SP1R Bit0 4TH CLAMP DETECT iACL4 SP2R 4TH UNCLAMP DETECT Bit1 iAUC4 X1D1032-23 CONNECT DEVICE 4TH UNIT CONNECT Bit2 iAON XB4J1-I Bit3...
Page 89 DESCRIPTION DATE ECN. DN-IC-16C DC 24V D1032 DC 24V POWER SUPPLY +24E CHECK CH:1 ID:03 X3TR20P-B X2D1032-89 ADR:005 +24E Bit0 iARM01 Bit1 iARM02 X2D1032-AB Bit2 iARM04 Bit3 iATCST X2D1032-P1 X2D1032-CD +24E Bit4 Bit5 X2D1032-EF Bit6 Bit7 X2D1032-P2 DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L...
Page 90 DESCRIPTION DATE ECN. X4LD1033 DN-OC-16PC DC 24V P24A 4L-1 D1033 DC 24V POWER SUPPLY N24A 4L-2 4L-3 N24A X4UD1033 P24A 4U-1 N24A 4U-2 CHECK 4L-3 N24A CH:1 ID:03 X1D1033-01 X4RBD16 ADR:000 REF:BB2 COOLANT X4-K1 Bit0 切削水 oCOLM COOLANT ON RELAY(OP) KARF 冷卻水電磁閥繼電器...
Page 91 DESCRIPTION DATE ECN. DN-OC-16PC DC 24V D1033 DC 24V POWER SUPPLY CHECK CH:1 ID:03 X2D1033-89 X4RBD16 ADR:001 MAG. CW START X4-K9 Bit8 儲刀倉正轉旋轉啟動 oMCW MAG. CCW START X4-K10 Bit9 儲刀倉反轉旋轉啟動 oMCCW X2D1033-AB TOOL UNCLAMP X4-K11 BitA 主軸放刀 oISUC TOOL UNCLAMP AIR BLOW X4-K12 BitB 主軸放刀吹氣...
Page 94 DESCRIPTION DATE ECN. X4LD1035 DN-OC-16PC2 DC 24V P24A 4L-1 D1035 DC 24V POWER SUPPLY N24A 4L-2 4L-3 N24A CHECK CH:1 ID:03 X1D1035-01 X6RBD16 ADR:004 REF:BB6 X6-K1 Bit0 oTBLOW X6-K2 Bit1 oAOIL X1D1035-23 X6-K3 Bit2 oHOL X6-K4 Bit3 oLUB P24A N24A X1D1035-45 X6-K5 Bit4...
Page 95 DESCRIPTION DATE ECN. DN-OC-16PC2 DC 24V D1035 DC 24V POWER SUPPLY CHECK CH:1 ID:03 X2D1035-89 X6RBD16 ADR:005 X6-K9 Bit8 X6-K10 Bit9 X2D1035-AB X6-K11 BitA X6-K12 BitB P24A N24A X2D1035-CD X6-K13 BitC X6-K14 BitD X2D1035-EF X6-K15 BitE X6-K16 BitF X2D1035-P N24A P24A P24A (OPTION)
Page 96 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EBC1 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 97 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EBC2 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 98 DESCRIPTION DATE ECN. DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EBC3 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 99 DESCRIPTION DATE ECN. +24E +24E +24E +24E +24E +24E +24E +24E +24E DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EBC4 VERSION: APPROVE SUNNY-L PART NO GX 822P200E TITLE 表單編號 :E40011...
Page 100 DESCRIPTION DATE ECN. 210 184 P24A P24A +24V 215 +24V 191 +24V 175 210 192A 210 193A 210 173 210 174 210 190A 210 191A +24VA +24VA +24VA 210 172 +24VA +24VA DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EBC5 VERSION:...
Page 101 DESCRIPTION DATE ECN. +24VA P24A P24A +24VA +24V 230 +24V 231 +24V 232 +24V 177 +24VA 210 176 210 165 190B +24VA +24VA 190A +24VA +24VA 0VF2 FB113 DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GX 822P200-EBC6 VERSION: APPROVE SUNNY-L...
Page 102 DESCRIPTION DATE ECN. 210 171 P24A P24A +24V 215 +24V 191 +24V 175 P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A P24A DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L...
Page 103 DESCRIPTION DATE ECN. RENISHAW SWITCH1 X14-SE3-SSU 紅 24VF2 0VF2 +24V 24VF2 黑 TO:GS8 REF:AB7 0VF2 綠/黃 SENSORV1 1 2 3 4 GN/YE SCREEN 綠 FB104 ERROR SENSOR3 藍 FB105 SENSORV2 SWITCH2 X13-SE2-SSU SENSORV1 水色 LTBU FB107 PROBE STATUS SENSOR2 FB105 SENSORV2 1 2 3 4 黃...
Page 104 DESCRIPTION DATE ECN. OMI-2T FOR OMP40 and OTS (PARTS & TOOL PROBE) 24VF2 0VF2 X14-SE3-SSU SENSORV1 OMI-2T GN綠 FB204 Error (SSR) SENSOR3 SW1-4:N/O GN/BK綠黑 SENSORV2 (REF/AC1) X13-SE2-SSU KARPP Probe Status 1 BU藍 FB205A FB205 (SSR) SENSORV1 SW1-2:N/C BU/BK藍黑 (REF/AC1) KARTP SENSOR2 GY灰...
Page 105 DESCRIPTION DATE ECN. RENISHAW MI-12 X14-SE3-SSU 1 2 3 4 24VF2 0VF2 +24V 24VF2 TO:GS8 REF:AB7 0VF2 SENSORV1 A B C D SCREEN FB104 SIGNAL1/ERROR SENSOR3 1 2 3 4 FB105 SENSORV2 X13-SE2-SSU SENSORV1 水色 A B C D LTBU FB107 PROBE STATUS SENSOR2...
Page 106 DESCRIPTION DATE ECN. ELD-N ELD-N UPB4 VPB4 WPB4 M4J2.A M4J2.B M4J2.C M4J2.H M4J2.I M4J2.N M4J2.I OP:OPTION DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO E01\GXC822P200-EZZ1 VERSION: APPROVE SUNNY-L PART NO GXC822P200E TITLE 表單編號 :E40011...
Page 107 GX SERIES VERTICAL MACHINING CENTER OKUMA OSP-P200M-R PARTS LIST Issue：A2 Dec, 2011 GX 822P200P 荷蘭商哈廷國際科技股份有限公司台灣分公司 Hardinge Machine Tools B.V., Taiwan Branch...
Page 108 PARTS LIST DWG NO. TITLE VERSION GX 822P200-P01 X AXIS SCALE & SERVO MOTOR GX 600/800/1000 GX 822P200-P02 Y AXIS SCALE & SERVO MOTOR GX 600/800/1000 GX 822P200-P03 Z AXIS SCALE & SWITCH GX 600/800/1000 GX 822P200-P04 X/Y AXIS LIMITED GX 600/800/1000 GX 822P200-P05 FRONT VIEW...
Page 109 DESCRIPTION DATE ECN. GX 822P200-P01 PARTS LIST DESCRIPTION ITEM PART NUMBER SPECIFICATION QUANTITY (項目) (零件料號) (規格) (數量) (說明) X AXIS LINER SCALE MSA3706*720(R.S.F) NV 00028340300 (GX 600) X AXIS LINER SCALE MSA3706*920(R.S.F) NV 00028340301 (GX 800) X AXIS LINER SCALE MSA3706*1140(R.S.F) NV 00028340302 (GX 1000)
Page 110 DESCRIPTION DATE ECN. GX 822P200-P02 PARTS LIST PART NUMBER SPECIFICATION DESCRIPTION QUANTITY ITEM (項目) (說明) (零件料號) (規格) (數量) U4404-0005-002-00 NV 00004040000 Y AXIS SERVO MOTOR (OKUMA) Y AXIS LINNER SCALE MSA3706*620 (RSF) NV 00028340303 (GX 600) DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L...
Page 111 DESCRIPTION DATE ECN. GX 822P200-P03 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) SL1-A (YAMATAKE) NV 00102440000 Z AXIS REF.SWITCH SL1-A (YAMATAKE) NV 00102440000 Z AXIS ATC POS. SWITCH SL1-A (YAMATAKE) NV 00102440000 Z AXIS EM SWITCH Z AXIS LINER SCALE MSA3706*620 (R.S.F) NV 00028340303...
Page 112 DESCRIPTION DATE ECN. GX 822P200-P04 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) SL1-A (YAMATAKE) NV 00102440000 X AXIS REF./EM SWITCH SL1-A (YAMATAKE) Y AXIS REF./EM SWITCH NV 00102440000 DRAWN RACHEL-C NC TYPE MT TYPE CHECK SUNNY-L DWG NO...
Page 113 DESCRIPTION DATE ECN. Mist Door C hip C hip Chip A TC colle ctor u nlock conveyor c onv eyor te mp CCW wash Cycle Buzzer Coolant A ir b low Mist stop Water g un MIRROR Auto operation IMAGE shut off GX 822P200-P05 PARTS LIST ITEM...
Page 114 DESCRIPTION DATE ECN. GX 822P200-P06 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) XCS-TE(WITH LOCK) DOOR SWITCH(CE) NV 00102440003 (Telemecanique) (OP) XCS(WITHOUT LOCK) NV 00102440002 DOOR SWITCH (Telemecanique) XCS-TE(WITH LOCK) DOOR SWITCH NV 00102440014 (Telemecanique) (for option CE) MAIN OPERATION CASE POWER CASE...
Page 115 DESCRIPTION DATE ECN. GX 822P200-P07 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) XCS-TE(WITH LOCK) DOOR SWITCH(CE) NV 00102440003 (Telemecanique) (OP) XCS(WITHOUT LOCK) NV 00102440002 DOOR SWITCH (Telemecanique) XCS-TE(WITH LOCK) DOOR SWITCH NV 00102440014 (Telemecanique) (for option CE) MAIN OPERATION CASE POWER CASE...
Page 116 DESCRIPTION DATE ECN. OKUMA GX 822P200-P08 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) TOWER LIGHT & BUZZER DC24V (G/R/Y/BZ) NV 00120450200 (3 COLOR) (OP) BUZZER(STAND) NV 00120450202 DC24V 30mm EGA A type NV 00072020061 RS232C INTERFACE NV 00089150004 AC24V 36W...
Page 117 DESCRIPTION DATE ECN. OKUMA GX 822P200-P09 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) TOWER LIGHT & BUZZER DC24V (G/R/Y/BZ) NV 0012045020 (3 COLOR) (OP) BUZZER(STAND) NV 00120450202 DC24V 30mm EGA A type NV 00072020061 RS232C INTERFACE NV 00089150004 AC24V 36W...
Page 118 DESCRIPTION DATE ECN. GX 822P200-P10 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) U4511-0005-002-00 NV 00004040001 Z AXIS SERVO MOTOR (OKUMA) E1015-288-016 NV 00004040100 SPINDLE MOTOR (OKUMA)(12000r.p.m) SL1-A (YAMATAKE) NV 00102440000 SPD. CLAMP SWITCH SL1-A (YAMATAKE) NV 00102440000 SPD.
Page 119 DESCRIPTION DATE ECN. GX 822P200-P11 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) U4511-0005-002-00 NV 00004040001 Z AXIS SERVO MOTOR (OKUMA) E1015-288-016 NV 00004040100 SPINDLE MOTOR (OKUMA)(12000r.p.m) SL1-A (YAMATAKE) NV 00102440000 SPD. CLAMP SWITCH SL1-A (YAMATAKE) NV 00102440000 SPD.
Page 120 ARMADIO TENSIONE DOOR INTERLOCK GX 822P200-P12 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) 無熔絲開關把手 FG-21E-U4 (TAI AN) NV 00103590002 NFB HANDLE 熱交換器 NV 00115550000 C&H-3AR (高抗) COOLANT & HEAT EXCHANGE UNIT 冷凍機 HA-50AF(HABOR) NV 00034120107 CHILLER (OP) 選擇開關...
Page 121 FILTER KMPS QFB7 KARD KARE KARF GX 822P200-P13 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (說明) (零件料號) (規格) (數量) TO-100EC 3P125A 無熔絲開關 NV 00100170033 (TAI AN) NO FUSE BREAKER NFB 護蓋 V-89447(TAI AN) NV 00108211103 NFB COVER 三相濾波器 NV 00112980208 FN 3258-75A-52 3 PHASE FILTER...
Page 122 POWER SUPPLY POWER SUPPLY TOOL PROBE KARTP KARPP GX 822P200-P14 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) DC 電源供應器 NV 00087760307 NES-100-24 DC24V/4.5A DC POWER SUPPLY MI8 (A-2037-0010) 刀具量測界面 (OP) NV 00028340416 (RENISHAW) TOOL PROBE INTERFACE 接線盤...
Page 123 POWER SUPPLY POWER SUPPLY GX 822P200-P15 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) 變壓器 NV 00087760011 LCP-TBSM-100740 Transformer DC 電源供應器 NV 00087760305 SP-200-24 DC24V/6.5A DC POWER SUPPLY DC 電源供應器 NV 00087760316 NES-15-24 DC24V/0.7A DC POWER SUPPLY 接地銅條...
Page 124 * FOR GX 600/800/1000 SWING ARM MDUA-22-555-MA PSU-20-ACL DRIVE UNIT FOR SP,X,Y,Z POWER SUPPLY QFB3 QFB2 QFB1 POS2A FRT7 FRT6 FRT3 FRT2 FRT1 SPARK SPARK SPARK SPARK SPARK KILLER KILLER KILLER KILLER KILLER DN-SLV DN-IC-16C DN-IC-16C DN-IC-16C DN-OC-16C DN-OC-16C DN-OC-16C KA35 KARSP1KARSP2 KAR24 KAR24A KAR19 KAR19A...
Page 125 GX 822P200-P16 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) NV 00004040400 U3100-0006-001-00 電力模組 *(U3100-0006-001-00) (OKUMA)(PSU-20-ACL) POWER SUPPLY MODULE NV 00004040401 U3389-0006-001-00 主軸伺服驅動器 (OKUMA)(MDUA-22-555-MA) *(U3389-0006-001-00) SPD. SERVO DRIVER Spec. Depend by 伺服驅動器 servo motor type SERVO DRIVER NV 00004040304 A911-2920-01-013...
Page 126 Revise No.20 specification for CTS GX 822P200-P16 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) LR3D086 2.5A ~ 4A NV 00098330019 過載電驛 LR3D166 9.0A ~ 13A (CTS) NV 00098330028 THERMO RELAY 過載電驛 NV 00098330019 LR3D146 2.5-4A THERMO RELAY 過載電驛...
Page 127 GX 822P200-P16 PARTS LIST ITEM PART NUMBER SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) 絕緣配線槽 NV 00108211000 70mm*100mm WIRING DUCT 絕緣配線槽 NV 00108211002 45mm*65mm WIRING DUCT 絕緣配線槽 NV 00108211003 25mm*65mm WIRING DUCT 風扇網 FG-120 41/2" (SAN JUN) NV 00118500000 FAN NET 風扇...
Page 128 GX 822P200-P20 PARTS LIST ITEM PART NUMBER SPECIFICATION QUANTITY DESCRIPTION (項目) (零件料號) (規格) (說明) (數量) TOOL CLAMP/UNCLAMP ASSM NV 000327947AE PANEL SET TOOL CLAMP/UNCLAMP NVA000327947 114*69*2 PANEL PUSH BUTTON ZB4 BW313 (W) BL 00036500017 CONTACTOR OF PUSH BL 00036500019 ZB4 BW0B11-1A BUTTON 22.5mm ZBPA[TE] NV 00072020059...
Page 129 * K TYPE MAGAZINE GX 822P200-P21 PARTS LIST PART NUMBER ITEM SPECIFICATION DESCRIPTION QUANTITY (項目) (零件料號) (規格) (說明) (數量) GEAR MOTOR FOR MAG. 1/2HP,220V/380V PS 0140008 3RG40 12-0AB00 MAG. COUNTER 1 PROXIMITY NV 00028340022 (siemens) 3RG40 12-0AB00 MAG. COUNTER 1 PROXIMITY NV 00028340022 (siemens) SHL-Q2255 (OMRON)
Page 130 GX SERIES VERTICAL MACHINING CENTER OKUMA OSP-P200M-R ADDENDUM-1 附錄-1 Issue：A0 May, 2010 荷蘭商哈廷國際科技股份有限公司台灣分公司 Hardinge Machine Tools B.V., Taiwan Branch...
Page 131 機種　　　　　　 Machine Mode GX1000 資料名称 LIST TITLE I/O表 Input/Output Signal List ＯＳＰ　　　　　 OSP Model OSP-P200M-R プロジェクトNo.　Project No. 529925 作成日　　　　　 Date 2010/07/06 資料番号 LIST No. W4001-529-925-2 ラベルマスター　 LabelMaster LM_P100_MA005S IOﾃﾞｰﾀ結合ﾌｧｲﾙ　 IO DataFile PIOD11-P529925CE.cns デバイスネットユニット一覧 DeviceNet Units ソフト短絡 Masked Inputs ラベル種別信号名...
Page 132 入出力信号一覧 IO Signals CH： 1 MACID： 1 INPUT IOモニタ IO Monitor 　デバイスネットユニット DeviceNet Unit　　　　　最終接続 Lowest Con. アドレス　ビットラベル　　機器記号形式　　　接続器　　　接続点接続器　接続点制御機器電線番号　 Signal Name 信号名 Address Bit　　Label　　　 Symbol Type　　　　　 Connector　 Port Connector Port...
Page 133 CH： 1 MACID： 1 INPUT IOモニタ IO Monitor 　デバイスネットユニット DeviceNet Unit　　　　　最終接続 Lowest Con. アドレス　ビットラベル　　機器記号形式　　　接続器　　　接続点接続器　接続点制御機器電線番号　 Signal Name 信号名 Address Bit　　Label　　　 Symbol Type　　　　　 Connector　 Port Connector Port Ctrl.
Page 134 CH： 1 MACID： 1 INPUT IOモニタ IO Monitor 　デバイスネットユニット DeviceNet Unit　　　　　最終接続 Lowest Con. アドレス　ビットラベル　　機器記号形式　　　接続器　　　接続点接続器　接続点制御機器電線番号　 Signal Name 信号名 Address Bit　　Label　　　 Symbol Type　　　　　 Connector　 Port Connector Port Ctrl.
Page 135 CH： 1 MACID： 1 INPUT IOモニタ IO Monitor 　デバイスネットユニット DeviceNet Unit　　　　　最終接続 Lowest Con. アドレス　ビットラベル　　機器記号形式　　　接続器　　　接続点接続器　接続点制御機器電線番号　 Signal Name 信号名 Address Bit　　Label　　　 Symbol Type　　　　　 Connector　 Port Connector Port Ctrl.
Page 136 CH： 1 MACID： 1 OUTPUT IOモニタ IO Monitor 　デバイスネットユニット DeviceNet Unit　　　　　最終接続 Lowest Con. アドレス　ビットラベル　　機器記号形式　　　接続器　　　接続点接続器　接続点制御機器電線番号　 Signal Name 信号名 Address Bit　　Label　　　 Symbol Type　　　　　 Connector　 Port Connector Port Ctrl.
Page 137 CH： 1 MACID： 1 OUTPUT IOモニタ IO Monitor 　デバイスネットユニット DeviceNet Unit　　　　　最終接続 Lowest Con. アドレス　ビットラベル　　機器記号形式　　　接続器　　　接続点接続器　接続点制御機器電線番号　 Signal Name 信号名 Address Bit　　Label　　　 Symbol Type　　　　　 Connector　 Port Connector Port Ctrl.
Page 138 CH： 1 MACID： 2 INPUT IOモニタ IO Monitor 　デバイスネットユニット DeviceNet Unit　　　　　最終接続 Lowest Con. アドレス　ビットラベル　　機器記号形式　　　接続器　　　接続点接続器　接続点制御機器電線番号　 Signal Name 信号名 Address Bit　　Label　　　 Symbol Type　　　　　 Connector　 Port Connector Port Ctrl.
Page 139 CH： 1 MACID： 3 INPUT IOモニタ IO Monitor 　デバイスネットユニット DeviceNet Unit　　　　　最終接続 Lowest Con. アドレス　ビットラベル　　機器記号形式　　　接続器　　　接続点接続器　接続点制御機器電線番号　 Signal Name 信号名 Address Bit　　Label　　　 Symbol Type　　　　　 Connector　 Port Connector Port Ctrl.
Page 140 CH： 1 MACID： 3 OUTPUT IOモニタ IO Monitor 　デバイスネットユニット DeviceNet Unit　　　　　最終接続 Lowest Con. アドレス　ビットラベル　　機器記号形式　　　接続器　　　接続点接続器　接続点制御機器電線番号　 Signal Name 信号名 Address Bit　　Label　　　 Symbol Type　　　　　 Connector　 Port Connector Port Ctrl.
Page 141 Hardinge Machine Tools B.V., Taiwan Branch Address：4 Tzu Chiang 3 Rd., Nan Tou City, 540 Taiwan Tel：886-49-2260-536 Fax：886-49-2252-203 886-49-2254-167 E-mail：www.hardinge.com.tw...
