Code BIOS POST Error
1 memory refresh is not working
2 parity error in 1st 64KB of memory
3 memory failure in 1st 64KB of memory
4 timer T1 not operational
5 CPU test failed
6 gate A20 failure
7 DMA page/base registers
8 video error (nonfatal)
9 keyboard failure
10 CMOS shutdown register failed
11 external cache is not working
12 chipset initialization failure
13 exhaustive low memory test
14 exhaustive extended memory test
15 CMOS restart byte can't hold data
16 address line test failed
17 data line test failed
18 interrupt controller failure
Tab. 2 Fatal Embedded BIOS POST error-code
Code BIOS POST Progress
00H POST beginning
01H CPU register test about to start
02H NMIs are disabled; delay starts
03H power-on delay finished
04H kbd BAT done; reading kbd SYS bit
05H disabling shadowing & cache
06H calcing ROM cksum, wait kbd ctrlr
07H cksum okay, kbd ctrllr free
08H verifying BAT cmd to kbd ctrllr
09H issuing kbd ctrllr cmd byte
0aH issuing kbd ctrllr data byte
0bH issuing pin 23,24 blocking & unblocking
0cH issuing kbd ctrllr NOP cmd next
0dH testing CMOS RAM shutdown register
0eH checking CMOS cksum, updating DIAG byte
0fH initializing CMOS (if req'd every boot)
10H init CMOS status reg for date/time
11H disabling DMA, interrupt ctrllrs
12H disabling Port B, disabling video display
13H init chipset, start auto-mem detect
14H starting timer tests
