Texas Instruments LOGIC PD ZOOM DM3730 SOM-LV Quick Start Manual

Items used in this QuickStart Guide.
(Complete kit contents provided on the included Packing List.)
Baseboard
SD Cards
(Android, Linux,
& Windows CE
Demos) Power Supply & Cord
Important baseboard locations.
(Numbers correspond to steps on the right.)
5
6
3
DM3730
SOM-LV
4.3" LCD
Power Converter
(use dependent upon region)
2
1
Demo setup.
(Setup development kit to sample OS demos.)
1
2
Connect DM3730
SOM-LV (use outline on
baseboard for positioning),
press straight down over
connectors
4 5
Connect power cord
and supply
7 8
GUI will appear on LCD
screen (Android demo
shown)
3
Connect 4.3" LCD, Choose OS demo and
insert SD card
remove protective
plastic covering
6
Connect power to Switch power on
baseboard and electric
outlet
Next steps
To sample the other OS
demo: power off
kit, remove SD card,
and repeat Steps 3 and
6 using the other SD
card
