DRV2605L Multiple ERM, LRA Haptic Driver Kit
1
Introduction
The DRV2605L device is a haptic driver designed for linear resonant actuators (LRA) and eccentric
rotating mass (ERM) motors. The device has many features that help eliminate the design complexities of
haptic motor control including:
•
Reduced solution size
•
High-efficiency output drive
•
Closed-loop motor control
•
Quick device startup
•
Embedded waveform library
•
Auto-resonance frequency tracking
The DRV2605LEVM-MD evaluation module (EVM) is an evaluation platform for the DRV2605LDGS. The
kit includes 8 DRV2605L devices, MSP430F5510 microcontroller (MCU), terminal output support for up
eight LRAs or ERMs, DRV2605L-integrated waveforms licensed from Immersion, and capacitive touch
buttons which demonstrate the capabilities of the DRV2605L.
This user's guide contains instructions for setting up and operating the DRV2605LEVM-MD.
Code Composer Studio is a trademark of Texas Instruments.
All other trademarks are the property of their respective owners.
SLOU400 – November 2014
Submit Documentation Feedback
Figure 1. DRV2605LEVM-MD
Copyright © 2014, Texas Instruments Incorporated
SLOU400 – November 2014
DRV2605L Multiple ERM, LRA Haptic Driver Kit
User's Guide
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DRV2605L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Texas Instruments DRV2605L

Summary of Contents for Texas Instruments DRV2605L

  • Page 1 DRV2605L Multiple ERM, LRA Haptic Driver Kit Introduction The DRV2605L device is a haptic driver designed for linear resonant actuators (LRA) and eccentric rotating mass (ERM) motors. The device has many features that help eliminate the design complexities of haptic motor control including: •...

  • Page 2: Getting Started

    Code Composer Studio™ software. The board receives power in two ways. For applications that require two or less active DRV2605L devices device at the same time, the board can be powered through a USB port. For applications that require more than two drivers, the use of the external power supply terminals with a current rating of 1.6 A is...
  • Page 3 • B1: The DRV2605L devices are setup individually and RTP mode is configured. Sequential button presses activate the next DRV2605L device in sequential order starting at driver 1, ending at driver 8, and then looping back to driver 1. •...
  • Page 4 3.2.1 Mode 1 Mode 1 allows the user full access to all of the DRV2605L devices on the board by enabling them and connecting all of the I C lines. An external host processor can be connected to the I C headers to allow communication to the DRV2605L devices without having to use the on-board MSP430F5510.
  • Page 5 The four DRV2605L devices are sent the same default initialization settings for ERM actuators (Mode 4) and LRA actuators (Mode 5). When the settings are received by the DRV2605L devices, each DRV2605L device is individually enabled sequentially and setup for RTP mode with magnitude 0x7F at a 500-ms interval.
  • Page 6 Measurement and Analysis—Waveform Sequences The DRV2605L device uses PWM modulation to create the output signal for both ERM and LRA actuators. To measure and observe the DRV2605L output waveform, connect an oscilloscope or other measurement equipment to the filtered output test points, OUT+ and OUT–.
  • Page 7 (trace Math) is trace C1-CT the ERM was operated in open-loop mode. The peak acceleration for the waveform is 156.1 mV or 1.37 G. Figure 7. Pulsing Strong waveform for ERM in Open-Loop Mode SLOU400 – November 2014 DRV2605L Multiple ERM, LRA Haptic Driver Kit Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 8 Figure 8. Strong Buzz Waveform for LRA in Auto-Resonance Mode Figure 9. Strong Buzz Waveform for LRA in Open-Loop Mode DRV2605L Multiple ERM, LRA Haptic Driver Kit SLOU400 – November 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 9 Table 2 Table 3 show exact I C transactions with slave addresses, registers, and values to enable one DRV2605L device and to enable three or more DRV2605L devices. Table 2. TCA9554 I C Transaction for Enabling driver 1 Slave Address (7-bit)
  • Page 10 The TCA9554 device is first configured for output ports for drivers 6 and 7 with a value of 1 at the output. The TCA9548A device is switched to driver 7 (channel 8) and sent a read command to the DRV2605L device to verify communication with the haptic driver.

  • Page 11: Power Supply Selection

    Power Supply Selection The DRV2605LEVM-MD can be powered by USB or an external power supply (VBAT). Jumpers DRV and MSP are used to select USB or VBAT for the DRV2605L and MSP430F5510 devices, respectively. Table 6 lists the different supply configurations and supply voltages that the DRV2605L devices and MSP430 device could have.
  • Page 12 8. Put the device in low-power mode by deasserting the EN pin through the TCA9554 device to set the STANDBY bit. NOTE: To send the same commands to multiple DRV2605L devices at the same time, configure the TCA9554 and TCA9548A devices to the appropriate channel selections. I...
  • Page 13 7. Cycle the power on the board to restart the firmware. SLOU400 – November 2014 DRV2605L Multiple ERM, LRA Haptic Driver Kit Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 14 6. If no errors exist, select RUN → DEBUG in the title bar. 7. Exit the debugger when the firmware has been uploaded to the board. Figure 14. Build Properties of Firmware Project DRV2605L Multiple ERM, LRA Haptic Driver Kit SLOU400 – November 2014 Submit Documentation Feedback...
  • Page 15 P2.5/TA2.2 P2.6/RTCCLK/DMAE0 P2.7/UCB0STE/UCA0CLK P3.0/UCB0SIMO/UCB0SDA P3.1/UCB0SOMI/UCB0SCL P3.2/UCB0CLK/UCA0STE P3.3/UCA0TXD/UCA0SIMO P3.4/UCA0RXD/UCA0SOMI DVSS2 DVCC2 3.3 V P4.0/PM_UCB1STE/PM_UCA1CLK P4.1/PM_UCB1SIMO/PM_UCB1SDA SDA_IN P4.2/PM_UCB1SOMI/PM_UCB1SCL SCL_IN P4.3/PM_UCB1CLK/PM_UCA1STE P4.4/PM_UCA1TXD/PM_UCA1SIMO P4.5/PM_UCA1RXD/PM_UCA1SOMI SLOU400 – November 2014 DRV2605L Multiple ERM, LRA Haptic Driver Kit Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 16 B2LED PJ.2/TMS USER LED1, can be disconnected PJ.3/TCK USER LED2, can be disconnected nRST/NMI/SBWTDIO ResistorET button, SBW programmer QFN PAD DRV2605L Multiple ERM, LRA Haptic Driver Kit SLOU400 – November 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 17 Layout Figure 15. Xray Image of Top and Bottom Layer Traces Figure 16. Top Layer Figure 17. Middle Power Layer SLOU400 – November 2014 DRV2605L Multiple ERM, LRA Haptic Driver Kit Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 18 Layout www.ti.com Figure 18. Middle Ground Layer Figure 19. Bottom Layer DRV2605L Multiple ERM, LRA Haptic Driver Kit SLOU400 – November 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 19 DRV2605L Haptic Driver Haptic Driver TCA9554 I2C IO Expander DRV2605L DRV2605L Haptic Driver Haptic Driver Figure 20. Schematic Block Diagram SLOU400 – November 2014 DRV2605L Multiple ERM, LRA Haptic Driver Kit Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 20 ENABLE8 OUT7- OUT8- 1.5k Green 1.5k Green DRV2605LDGS DRV2605LDGS OUT7- OUT8- 100k 100k 470pF 470pF Figure 21. Schematic Page 1 DRV2605L Multiple ERM, LRA Haptic Driver Kit SLOU400 – November 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 21 PJ.2 P6.2 USER SW PJ.3 P6.3 P6.4 0.68µF P6.5 +3.3V +3.3V P6.6 P6.7 VBAT VBAT Figure 22. Schematic Page 2 SLOU400 – November 2014 DRV2605L Multiple ERM, LRA Haptic Driver Kit Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 22 3.3k 3.3k 3.3k 3.3k 3.3k 3.3k 3.3k Note: Slave Addr for TCA9548A - 0x70 (7-bit) Figure 23. Schematic Page 3 DRV2605L Multiple ERM, LRA Haptic Driver Kit SLOU400 – November 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...

  • Page 23: Bill Of Materials

    Header, 8 × 1, 100-mil, TH TE Connectivity PORT5_J 5-146278-4 Header, 100-mil, 4 × 1, Tin, TH Header, 4 × 1, 100-mil, TH TE Connectivity SLOU400 – November 2014 DRV2605L Multiple ERM, LRA Haptic Driver Kit Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 24 3.2 × 0.8 × 2.5-mm Abracon Corportation MS3V-T1R 32.768KHZ ±20PPM 12.5PF Crystal, 32.768-kHz, 12.5-pF, SMD 1.4 × 1.4 × 5-mm SMD MicrCrystal AG DRV2605L Multiple ERM, LRA Haptic Driver Kit SLOU400 – November 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
