Communication Ports
The RUGGEDCOM RS910L can be equipped with various types of communication
ports to enhance its abilities and performance.
1
2
1
2
3
Figure 4.1
4.1
Copper Ethernet Ports
The RUGGEDCOM RS910L supports multiple 10/100Base-TX Ethernet ports that allow
connection to standard Category 5 (CAT-5) shielded or unshielded twisted-pair cables
with RJ45 male connectors.
RUGGEDCOM RS910L
Installation Manual, 02/2020, C79000-G8976-1030-06
Ports 1 and 2
Ports 3 and 4
Port 9
Port Assignment
Port
1 and 2
3 and 4
9
3
Serial Ports
Copper (10/100Base-TX) or Fiber Optic (100Base-FX) Ethernet Ports
EoVDSL Port
Type
4
21
