Technical Specifications
5.6 Serial Port Specifications
Mode
SM
MM
a
Typical.
5.6

Serial Port Specifications

The following details the specifications for serial ports that can be ordered with the
RUGGEDCOM RS910L.
Copper Serial Ports
Baud Rate
Connector
Isolation
Fiber Serial Ports
Mode
Connector
Typical Distance (km)
Optical Wavelength
(nm)
Cable Size
5.7

Operating Environment

The RUGGEDCOM RS910L is rated to operate under the following environmental con-
ditions.
Ambient Operating Tempera-
ture
Ambient Storage Temperature
Ambient Relative Humidity
Maximum Altitude
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Non-condensing.
32
Connec- Tx λ
a
tor Type (nm)
LC 9/125
LC 50/125
300 to 230 kbps
DB9 or RJ45
2.5 kV
Multimode
ST
5
850
50/125 or 62.5/125
a
b
Tx (dBm)
Cable
Type
Mini- Maxi-
(μm)
mum mum
1300 0 5
1300 -22.5 -14
-40 to 85 °C (-40 to 185 °F)
-40 to 85 °C (-40 to 185 °F)
5% to 95%
2000 m (6562 ft)
Rx Sen- Rx Satu- Dis-
sitivity ration tance
(dBm) (dBm) (km)
-37 0 90
-31 -14 2
Installation Manual, 02/2020, C79000-G8976-1030-06
Power
Budget
a
(dB)
37
8.5
