Certification
6.2 EMC and Environmental Type Tests
61000-4-6
61000-4-8
61000-4-11
61000-4-12
61000-4-16
61000-4-17
61000-4-29
IEC 60255-5
38
Test
IEC Induced (Conducted) RFI
IEC Magnetic Field
IEC Voltage Dips and Interrupts
IEC Damped Oscillatory
IEC Mains Frequency Voltage
IEC Ripple on DC Power Supply
IEC Voltage Dips and Interrupts
Dielectric Strength
HV Impulse
Description
AC Pow-
er Ports
Signal Ports
DC Pow-
er Ports
AC Pow-
er Ports
Earth
Ground Ports
Enclo-
sure Ports
AC Pow-
er Ports
Signal Ports
DC Pow-
er Ports
AC Pow-
er Ports
Signal Ports
DC Pow-
er Ports
DC Pow-
er Ports
DC Pow-
er Ports
Signal Ports
DC Pow-
er Ports
AC Pow-
er Ports
Signal Ports
DC Pow-
er Ports
AC Pow-
er Ports
Test Levels
± 4 kV Line-to-Ground
± 2 kV Line-to-Line
10 V
10 V
10 V
10 V
40 A/m Continuous
1000 A/m for 1 s
100% for 5 Periods
100% for 50 Periods
2.5 kV Common
Mode @ 1 MHz
1 kV Differential
Mode @ 1 MHz
2.5 kV Common
Mode @ 1 MHz
1 kV Differential
Mode @ 1 MHz
2.5 kV Common
Mode @ 1 MHz
1 kV Differential
Mode @ 1 MHz
30 V Continuous
300 V for 1 s
30 V Continuous
300 V for 1 s
10%
30% for 0.1 s
60% for 0.1 s
100% for 0.05 s
2 kV (Failsafe Relay Output)
2 kV
2 kV
5 kV (Failsafe Relay Output)
5 kV
5 kV
