Installation Instructions
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this product. Please keep instructions for future reference.

Warranty

This exhaust fan is covered by a 12 month warranty. The warranty is from date of purchase, not the date of
installation.
If this exhaust fan is not assembled and installed by a licensed electrician the warranty will be void.
Please retain proof of purchase and evidence of installation by a licensed electrician for any warranty enquires.
Warranty will be void if there is any damage due to improper usage or modification to the fan.
Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void warranty.

Safety Precautions

Read the Safety Precautions below before use and caring out installation.
Always ensure the power is OFF and the fan has cooled down before performing any maintenance, cleaning or
making any adjustment to the fan.
Means of all-pole disconnection must be incorporated in the fixed wiring.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
WARNING: If unusual oscillating movement is observed, immediately stop using the product and contact the
manufacturer, its service agent or suitably qualified persons.
Do not allow any foreign object to enter the grille opening as which may damage the product.
Ensure that the fan does not come in contact with corrosive chemicals solvents or abrasive cleaners etc.
Clean the grilles regularly. To clean, wipe with a damp clean cloth. Do NOT soak or immerse the product in
water or other liquids.

Installation Requirements

A licensed electrician is required to install this unit to the mains supply.
All wiring and installation of the exhaust fan must adhere to the local council regulation and latest local and national
wiring rules, eg. AS/NZS 3000 electrical installations. If unsure, contact a licensed electrician.
This exhaust fan must be installed to an isolation switch in accordance with the current AS/NZS 3000, also known
as wiring rules.
This product is suitable for indoor use only. It is rated IPX2 which is protected against vertically falling water drops
when the enclosure tilted up to 15°.
This exhaust fan is a Class II product and must be maintained during wiring and installation.
The mounting point must be able to support at least 2 times of the weight of the product.
Ensure all the clearance value to the structural building element are maintained according to the clearance diagram
in Fig.4.
Do not install the inlet of the exhaust fan in canopies over stoves etc., as excessive heat will damage the product.
This product is designed for installation on a flat ceiling only. Do not mount it on a sloping ceiling or a vertical wall.
Any duct attached to the product must be installed horizontally in the ceiling and with the same height or lower than
the exhaust fan.
1 | P a g e
METT INLINE EXHAUST FAN
SKU# 209040
Rated Voltage 220-240V~ 50Hz
v 1 . 0 ( 1 1 / 2 0 1 9 )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the METT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LUCCI Air METT

  • Page 1 Installation Instructions METT INLINE EXHAUST FAN SKU# 209040 Rated Voltage 220-240V~ 50Hz Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all instructions carefully before assembly, installation and use of this product. Please keep instructions for future reference.
  • Page 2 Installation Instructions • Ensure the duct is not bent otherwise the performance will be reduced. • Where applicable, precautions must be taken to avoid the back-flow of gases into the room from the open flue of gas or other fuel-burning appliances. •...
  • Page 3 Installation Instructions Fig.4 Clearance diagram STEP III - Wiring 9. Install the 3-speed wall switch (provided) in the desired location. 10. Open the cover of the terminal box by unscrewing the four screws. 11. Insert the supply cable through the cable entry and connect the wirings according to the wiring diagram. (Fig.5) NOTE: The terminals marked ‘X’...
  • Page 4 Installation Instructions N H X X Fig.5 Circuit diagram Specifications SKU # 209040 Colour White Insulation class Class II IP rating IPX2 Rated voltage 220-240V~, 50Hz Rated wattage H: 45W, M: 30W, L: 14W Max. Airflow H: 464 M /H, M: 365 M /H, L: 199 M Overall dimensions H: 248mm W: 300mm D: 200mm...
