E-1608 User's Guide

Screw terminal connector

Parameter
Connector type
Wire gauge range
Pin Signal name
1 CH0H
2 CH0L
3 AGND
4 CH1H
5 CH1L
6 AGND
7 CH2H
8 CH2L
9 AGND
10 CH3H
11 CH3L
12 AGND
13 AOUT0
14 AGND
15 AOUT1
16 AGND
Table 23. Screw terminal connector specifications
Specification
Screw terminal
16 AWG to 30 AWG
Table 24. Screw terminal pinout
Pin description
Channel 0 high (SE channel 0)
Channel 0 low (SE channel 1)
Analog ground
Channel 1 high (SE channel 2)
Channel 1 low (SE channel 3)
Analog ground
Channel 2 high (SE channel 4)
Channel 2 low (SE channel 5)
Analog ground
Channel 3 high (SE channel 6)
Channel 3 low (SE channel 7)
Analog ground
Analog output 0
Analog ground
Analog output 1
Analog ground
www.MicroDAQ.com
Pin Signal name
17 DIO0
18 DIO1
19 DIO2
20 DIO3
21 DIO4
22 DIO5
23 DIO6
24 DIO7
25 GND
26 +VO
27 GND
28 AICKO
29 AICKI
30 CTR
31 TRIG
32 GND
27
(603) 746-5524
Specifications
Pin description
Digital I/O bit 0
Digital I/O bit 1
Digital I/O bit 2
Digital I/O bit 3
Digital I/O bit 4
Digital I/O bit 5
Digital I/O bit 6
Digital I/O bit 7
Digital ground
User voltage output
Digital ground
External clock pacer output
External clock pacer input
Counter input
Digital trigger input
Digital ground
