Summary of Contents for Fisher & Paykel ACTIVESMART RS80
- Page 1 ACTIVESMART™ INTEGRATED FRENCH DOOR REFRIGERATOR FREEZER RS80 and RS90 models INSTALLATION GUIDE NZ AU GB IE HK SG IN 862068A 06.19...
-
Page 3: Table Of Contents
CONTENTS SAFETY AND WARNINGS COMPONENTS TOOLS APPLIANCE AND CAVITY DIMENSIONS CABINETRY OPTIONS CUSTOM DOOR PANEL INSTALLATION DIMENSIONS CUSTOM DOOR PANEL INSTALLATION TEMPLATE DOOR CLEARANCE ELECTRICAL AND PLUMBING BEFORE INSTALLATION CAVITY PREPARATION WATER SUPPLY CONNECTION POWER SUPPLY CONNECTION INSTALLATION PREPARATION POSITIONING INTO CABINETRY ALIGNING INSIDE CABINETRY DOOR PANEL INSTALLATION — STAINLESS STEEL DOOR PANEL INSTALLATION — CUSTOM... -
Page 5: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT! WARNING! It is very important for the installer to follow the instructions in this installation guide ● to ensure proper installation and operation of the appliance. Ensure that you read the Electric Shock Hazard installation guide thoroughly and understand all information. Read and follow the safety and warnings The water connection to your Ice and water appliance must be installed by a qualified ●... - Page 6 COMPONENTS Internal box (Installation kit) External box Located inside appliance Taped to back panel of appliance Anti-tip bracket Door panel attachment Door / d rawer trim A A Z Z assembly kit install kit Door side trim Toe kick grille Anti-tip bracket Side bracket Dual adhesive tabs (6 per each strip) (10)
-
Page 7: Components
COMPONENTS Miscellaneous items (MI) pack Located inside the appliance ACTIVESMART™ ACTIVESMART™ INTEGRATED INTEGRATED REFRIGERATOR SLIDE-IN REFRIGERATOR RS90A, RS9120W, RS90 & RS90AU models RS36A72, RS36A80 & RS36W80 models SERVICE & WARRANTY SERVICE ET GARANTIE ΣΈΡΒΙΣ ΚΑΙ ΕΓΓΎΗΣΗ SERVIZIO E GARANZIA SERVICE & GARANTIE HUOLTO JA TAKUU SERVICE OG GARANTI INSTALLATION GUIDE... -
Page 8: Tools
COMPONENTS TOOLS Door panel set Required tools Not supplied and must be purchased separately Not included with appliance Stainless steel (Fisher & Paykel) door panel set: Custom door panel set: Includes 2x French door panels and 1x drawer panel. Supplied by customer to match their cabinetry. Applicable for non water-dispensing models. -
Page 9: Appliance And Cavity Dimensions
APPLIANCE AND CAVITY DIMENSIONS IMPORTANT! For ease of installation, ensure cavity width is consistent top to bottom and height is consistent left to right. Flush with front of cabinetry PLAN VIEW Flush install Flush install Framed: Finished return top and sides Frameless: Finished return top and sides FRONT VIEW PROFILE VIEW... -
Page 10: Cabinetry Options
CABINETRY OPTIONS FRAMELESS CABINETRY FRAMED CABINETRY (Aligns the appliance with the cabinetry) (Aligns the appliance with the frame of the cabinetry) Flush Proud installation installation Note: Drawings are only for reference and not the actual cavity width of the cabinetry. - Page 11 DOOR PANEL DIMENSIONS IMPORTANT! Custom door panels can only be used for non-Water dispensing models. RS80 RS90 DOOR PANEL DIMENSIONS (STAINLESS STEEL/CUSTOM Height of each top door panel 1096 1096 Width of each top door panel Gap between top door panels Height of bottom drawer panel Height from bottom of appliance to top of drawer panel Width of bottom drawer panel...
-
Page 12: Custom Door Panel Installation Dimensions
CUSTOM DOOR PANEL INSTALLATION DIMENSIONS — RS80 Dimensions apply for the preparation and installation of custom door panels. For Dwg and Dxf files of the below panel preparation download the folder on thekitchentools.fisherpaykel.com. 342.3mm 54.8mm Ø 2mm REF 12x Pilot holes recommended for bracket attachment. (Do not penetrate front surface). - Page 13 CUSTOM DOOR PANEL INSTALLATION DIMENSIONS — RS90 Dimensions apply for the preparation and installation of custom door panels. For Dwg and Dxf files of the below panel preparation download the folder on thekitchentools.fisherpaykel.com. 392.3mm 54.8mm Ø 2mm REF 12x Pilot holes recommended for bracket attachment. (Do not penetrate front surface).
-
Page 14: Custom Door Panel Installation Template
CUSTOM DOOR PANEL INSTALLATION TEMPLATE This template is a single double-sided sheet used as a guide to drill screw holes for installing your Custom door and drawer panels. The actual template is included with this installation guide. HANGING BRACKET HANGING BRACKET HANGING BRACKET HANGING BRACKET HOLES... -
Page 15: Door Clearance
DOOR CLEARANCE Insert hinge limiting pin WARNING! Before opening the doors, ensure that the appliance is ● stable. Follow these steps to avoid risks that can cause serious ● injury or death. Wall Wall 115° DOOR OPENING 90° DOOR OPENING For 90°... -
Page 16: Electrical And Plumbing
ELECTRICAL AND PLUMBING IMPORTANT! WARNING! Electrical connection should be located in an adjacent cabinet to either side Electrical shock hazard. Assume all parts are live. ● ● of the appliance or above the appliance cavity. Disconnect supply before servicing and installation. ● We recommend to use an isolating switch that is easily accessible to the user ●... - Page 17 ELECTRICAL AND PLUMBING Maximum distance of hose and power cord Water inlet hose* — 2250mm Power cord (excl.plug) — 800mm LEFT HAND SIDE RIGHT HAND SIDE Water inlet hose* — 3180mm Water inlet hose* — 3930mm Power cord (excl.plug) — 2050mm Power cord (excl.plug) — 2050mm * Applicable to Ice and Water models only.
-
Page 18: Before Installation
BEFORE INSTALLATION IMPORTANT! Be careful when unpacking to prevent damage to the surface of your appliance. Ensure that the feet of the appliance are retracted. ● ● Ensure that the appliance is stable to prevent from tipping over when unpacking. If the appliance is damaged, contact your Fisher &... - Page 19 BEFORE INSTALLATION IMPORTANT! Your appliance is fitted with front and rear rollers designed for moving the appliance All connections for water, electrical power and grounding must comply with local codes ● ● forward and backward. Do not move the appliance sideways as this may damage the and ordinances and be made by licensed personnel when required.
-
Page 20: Cavity Preparation
CAVITY PREPARATION IMPORTANT! WARNING! Internal box The anti-tip bracket and fittings supplied must be fitted to the wall Read the following before fastening with masonry plugs and / o r screws: ● of the finished enclosure to withstand 100kg load. Ensure the screws avoid electrical, gas and water conduits. Anti tip ●... -
Page 21: Water Supply Connection
WATER SUPPLY CONNECTION IMPORTANT! Water fittings kit (Ice and Water The water connection instructions below are intended only for Ensure there is enough tubing for the water connection and to pull ● ● models only) the professional installer. the appliance out for service, if required. The appliance comes with a pre-connected plastic water tubing. -
Page 22: Power Supply Connection
POWER SUPPLY CONNECTION DETAIL B SCALE 1 : 5 Internal box Connect to power supply Alternative water and electrical connection (above the cavity) Connect the water fittings to the water supply (C). Locate the power cord and connect the fitted plug to the electrical supply Miscellaneous (230VAC, 50Hz). -
Page 23: Installation Preparation
INSTALLATION PREPARATION WARNING! Internal box Be careful when working with the appliance outside of the finished enclosure. ● Ensure that the appliance is secured to prevent tipping forward. Tipping of appliance can lead to serious injury or death. Install ● fasteners kit Remove hinge end caps M5x10 cross-head screw Open the French doors carefully. -
Page 24: Positioning Into Cabinetry
POSITIONING INTO CABINETRY IMPORTANT! Your appliance is fitted with front and rear rollers designed for moving the appliance in the Ensure the hose is not run over by the appliance when pushing into the cabinetry to ● ● forwards and backwards direction. prevent damage and possible water leaks. -
Page 25: Aligning Inside Cabinetry
ALIGNING INSIDE CABINETRY IMPORTANT! Supplied tools Ensure all four corners of the appliance is supported firmly onto the floor If using a powered driver, use low torque setting to avoid the nut ● ● to eliminate any movement. disengaging from the rod and damaging the leveling system. If the nut DO NOT install the appliance on a soft, uneven, or unlevelled floor disengages, use the hex key to realign with rod. - Page 26 DOOR PANEL INSTALLATION — STAINLESS STEEL IMPORTANT! Internal box Follow these steps to avoid difficulties in door panel adjustment and cosmetic cap fitment. ● Ensure to protect the finish of the Stainless steel door panels. Door panel ● For non-water dispensing door panels: Leave the protective film on the panels when hanging and remove the film only when installation is complete. attachment kit ●...
- Page 27 DOOR PANEL INSTALLATION — STAINLESS STEEL IMPORTANT! Ice and Water display (Ice and Water models Failure to follow these steps can lead to difficulties in door panel adjustment and cosmetic cap fitment. ● only) For water dispensing door panels: Remove the protective film from the appliance doors before hanging door panels. ●...
- Page 28 DOOR PANEL INSTALLATION — STAINLESS STEEL Tools Attach the door panels Open the door and loosen the M5x10 cross-head screws (do not remove) at the sides of the doors (A). Hang the door panel by inserting the M8 studs through the holes of the hanging bracket (B). Cross-head screwdriver Slide the forks of the side brackets onto the screws of the door (C).
- Page 29 DOOR PANEL INSTALLATION — STAINLESS STEEL IMPORTANT! Door panel Follow these steps to avoid difficulties in door panel adjustment and cosmetic cap fitment. ● attachment Adjust the door panels 8x16 mush washer screw Push the appliance into the cavity until the door panels are flush with adjacent cabinetry surface.
- Page 30 DOOR PANEL INSTALLATION — CUSTOM DRAWER PANEL TOP EDGE IMPORTANT! External box back side of front side of The template is a single sheet with one side used for the left door ● door panel door panel DRAWER PANEL TOP EDGE panel / d rawer panel and the other side for the right door panel. The template should be placed on the back side of the door panel.
- Page 31 DOOR PANEL INSTALLATION — CUSTOM DRAWER PANEL TOP EDGE IMPORTANT! front side of back side of Flip the template over to use for the right top door panel. ● door panel door panel DRAWER PANEL TOP EDGE The template should be placed on the back side of the door panel. ●...
- Page 32 DOOR PANEL INSTALLATION — CUSTOM IMPORTANT! Use left door panel template to use for the drawer panel. back side of front side of ● drawer panel door panel Place the template at the back side of the drawer panel. ● DRAWER PANEL TOP EDGE DRAWER PANEL TOP EDGE Using the installation template DRAWER PANEL TOP EDGE...
- Page 33 DOOR PANEL INSTALLATION — CUSTOM Internal box Remove hanging brackets Attach the door and drawer handles (C) Remove the M8 washers and M8 nuts from the Align the handle holes with the door panel Door panel M8 studs at the top the door (A) using the hex holes and secure with M5x25 pan head socket attachment kit key and spanner.
- Page 34 DOOR PANEL INSTALLATION — CUSTOM Tools Attach the door panels Open the door and loosen the M5x10 cross-head screws (do not remove) at the sides of the doors (A). Hang the door panel by inserting the M8 studs Hex key through the holes of the hanging bracket (B). Slide the forks of the side brackets onto the screws of the door (C).
- Page 35 DOOR PANEL INSTALLATION — CUSTOM IMPORTANT! Door panel Follow these steps to avoid difficulties in door panel adjustment and cosmetic cap fitment. ● attachment Adjust the door panels 8x16 mush washer screw Push the appliance into the cavity until the door panels are flush with adjacent cabinetry.
- Page 36 FIXING TO CABINETRY IMPORTANT! Internal box Lower the feet until it engages the floor to provide more stability to the appliance and prevent back and forth movement. Install fasteners kit #8Gx19 twin thread screw (2) Tools Cross-head screwdriver #8 x 19 Countersunk Twin Thread Posi Screw...
- Page 37 WATER FILTER INSTALLATION IMPORTANT! Miscellaneous items pack The water filter head must be firmly pushed into the appliance and secured. incorrect installation can lead to water leaks. ● Water filter Filter handle Filter cartridge tool FRONT VIEW Filter in locked position Install the water filter Align the filter removal tool over the filter handle and turn 90°...
- Page 38 TOE KICK INSTALLATION MI Pack Install the toe kick filter and grille Fit the filter onto the rails and push until it clips securely (A). Align the top grille clips to the top plinth slots. Ensure the top grille is in the correct orientation (B). Push the grille firmly onto the appliance until the clips engage (C).
- Page 39 COVERS AND TRIMS INSTALLATION Internal box Attach the covers Attach the drawer top and side trims Open the French doors. Peel off two dual adhesive tabs and press them together Door / d rawer Attach the top covers (A) firmly to form a pair (E).
- Page 40 FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER All models Ensure all internal and external packaging is removed from the appliance before use. Check all parts are installed. Ensure the appliance is level. Ensure the appliance is securely fastened to the cabinetry with the supplied anti-tip bracket and fittings.
