Instructions for use
INTRAflex LUX 2 program 2307 LN - 0.535.6190, 2320 LN -
0.535.6180, 2329 LN - 0.535.6200, 2313 LN - 0.535.6220, 2325 LN -
0.535.6210

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INTRAflex LUX 2 Series and is the answer not in the manual?

Questions and answers

Related Manuals for KaVo INTRAflex LUX 2 Series

Summary of Contents for KaVo INTRAflex LUX 2 Series

  • Page 1 Instructions for use INTRAflex LUX 2 program 2307 LN - 0.535.6190, 2320 LN - 0.535.6180, 2329 LN - 0.535.6200, 2313 LN - 0.535.6220, 2325 LN - 0.535.6210...
  • Page 2 Distributed by: Manufacturer: KaVo Dental GmbH Kaltenbach & Voigt GmbH Bismarckring 39 Bismarckring 39 D-88400 Biberach D-88400 Biberach Phone +49 7351 56-0 www.kavo.com Fax +49 7351 56-1488...

  • Page 3: Table Of Contents

    Contents 3 / 88 Table of contents 1 User instructions............................7 2 Safety................................ 9 2.1 Description of safety instructions....................... 9 2.2 Safety instructions........................... 12 3 Product description..........................18 3.1 Purpose – Intended use........................20 3.2 Technical Specifications........................22 3.2.1 Reducing shank 2307 LN....................22 3.2.2 Reducing shank 2320 LN....................
  • Page 4 Contents 4 / 88 4.1 Mount the MULTIflex (LUX) / MULTIflex LED coupling..............30 4.2 Checking the amount of water......................31 4.3 Checking the pressures........................33 4.4 Checking the O-rings........................35 5 Operation..............................36 5.1 Attaching the medical device......................36 5.2 Removing the medical device......................
  • Page 5 Automated external and internal disinfection..............62 7.4 Care products and systems - Servicing................... 62 7.4.1 Servicing with KaVo Spray....................64 7.4.2 Care with KaVo SPRAYrotor....................66 7.4.3 Servicing with KaVo QUATTROcare 2104 / 2104A............67 7.4.4 Servicing with KaVo QUATTROcare PLUS 2124 A............70...
  • Page 6 Contents 6 / 88 7.4.5 Servicing with KaVo QUATTROcare 2140 A..............75 7.5 Packaging............................77 7.6 Sterilisation............................78 7.7 Storage............................80 8 Tools and consumables.......................... 81 9 Terms and conditions of warranty......................84...

  • Page 7: User Instructions

    1 User instructions 7 / 88 1 User instructions Dear User Congratulations on purchasing this KaVo quality product. By following the instructions below you will be able to work smoothly, economically and safely. © Copyright by KaVo Dental GmbH Symbols...
  • Page 8 1 User instructions 8 / 88 Action request CE mark (European Community). A product bearing this mark meets the requirements of the applicable EC directive. Can be steam sterilizes at 134 C -1 C / +4 C (273 F -1,6 +7,4 Target group This document is intended for dentists and their assistants.

  • Page 9: Safety

    2 Safety 9 / 88 2 Safety 2.1 Description of safety instructions Warning symbol Structure DANGER The introduction describes the type and source of the haz‐ ard. This section describes potential consequences of non-compliance. ▶ The optional step includes necessary measures for hazard prevention.
  • Page 10 2 Safety 10 / 88 Description of hazard levels The safety instructions listed here, together with the three levels of danger will help avert property damage and injury. CAUTION CAUTION indicates a hazardous situation that can cause damage to property or mild to moderate injuries.
  • Page 11 2 Safety 11 / 88 WARNING WARNING indicates a hazardous situation that can lead to serious or fatal injury. DANGER DANGER indicates a maximal hazard due to a situation that can directly cause death or fatal injury.

  • Page 12: Safety Instructions

    2 Safety 12 / 88 2.2 Safety instructions WARNING Hazards for the care provider and the patient. In the case of damage, irregular running noise, excessive vibration, un- typical warming or when the cutter or grinder cannot be held. ▶ Do not use further and notify Service.
  • Page 13 2 Safety 13 / 88 WARNING Hazard from incorrectly reconditioned products. An infection hazard exists from contaminated products. ▶ Take suitable personal protective measures. CAUTION Risk of burn injury from hot handpiece head or hot hand‐ piece lid. Burn injuries in the mouth may be caused if the handpiece overheats. ▶...
  • Page 14 2 Safety 14 / 88 CAUTION Hazard from use as a light probe. Do not use the device as a light probe since the rotating cutters or grind‐ ers can cause injury. ▶ Use an appropriate light probe for additional illumination of the oral cavity or site of preparation.
  • Page 15 2 Safety 15 / 88 CAUTION Risk due to incorrectly stored instrument. Injury and infection caused by chucked cutters or grinders. Damage to clamping system from dropping the instrument. ▶ After treatment, place the instrument properly in the cradle, without the cutter or grinder.
  • Page 16 2 Safety 16 / 88 CAUTION Premature wear and malfunctioning from improper storage during long periods of nonuse. Reduced product life. ▶ The medical device should be cleaned, serviced and stored in a dry lo‐ cation, according to instructions, before long periods of nonuse. Note For safety reasons, we recommend that the tool holder system be checked annually after the warranty period expires.
  • Page 17 To ensure proper function, the medical device must be set up according to the reprocessing methods described in the KaVo Instructions for Use, and the care products and care systems described therein must be used. KaVo recommends specifying a service interval at the dental office for a licensed shop to clean, service and check the functioning of the medical device.

  • Page 18: Product Description

    3 Product description 18 / 88 3 Product description INTRAflex LUX base 2307 LN (Mat. no. 0.535.6190) INTRAflex LUX base 2320 LN (Mat. no. 0.535.6180)
  • Page 19 3 Product description 19 / 88 INTRAflex LUX base 2329 LN (Mat. no. 0.535.6200) INTRAflex LUX handpiece 2313 LN (Mat. no. 0.535.6220)

  • Page 20: Purpose - Intended Use

    3 Product description 20 / 88 INTRAflex LUX contra-angle 2325 LN (Mat. no. 0.535.6210) 3.1 Purpose – Intended use Indications for use: This medical device is ▪ intended for dental treatment only. All other types of use or modifica‐ tions of the product are not permitted and can be hazardous. The medical device is intended for the following applications: Removal of carious material, cavity and crown preparations, removal of fillings, processing of tooth and restoration surfaces.
  • Page 21 3 Product description 21 / 88 ▪ A medical device according to relevant national statutory regulations. Proper use: According to these regulations, this medical device may only be used for the described application by a knowledgeable user. You need to comply with the following: ▪...

  • Page 22: Technical Specifications

    3 Product description 22 / 88 ▪ protect him or herself, the patient and third parties from danger, and ▪ avoid contamination from the product. 3.2 Technical Specifications 3.2.1 Reducing shank 2307 LN Identification 1 green ring Transmission ratio 2.7 : 1 Induction air 2.5 to 3.0 bar (29 to 44 psi) Air consumption...

  • Page 23: Reducing Shank 2320 Ln

    3 Product description 23 / 88 INTRA LUX heads can be used. Attachable to all MULTIflex (LUX) / MULTIflex LED couplings. 3.2.2 Reducing shank 2320 LN Identification 1 blue ring Transmission ratio 1 : 1 Induction air 2.5 to 3.0 bar (29 to 44 psi) Air consumption 50 to 60 Nl/min.

  • Page 24: Reducing Shank 2329 Ln

    3 Product description 24 / 88 Attachable to all MULTIflex (LUX) / MULTIflex LED couplings. 3.2.3 Reducing shank 2329 LN Identification 2 green rings Transmission ratio 7.4 : 1 Induction air 2.5 to 3.0 bar (29 to 44 psi) Air consumption 50 to 60 Nl/min.

  • Page 25: Handpiece 2313 Ln

    3 Product description 25 / 88 3.2.4 Handpiece 2313 LN Identification 1 green ring Transmission ratio 2.7 : 1 Induction air 2.5 to 3.0 bar (29 to 44 psi) Air consumption 50 to 60 Nl/min. Speed range 5,000 to 12,000 min Idle torque at 3.0 bar (44 psi) = 3.2 Ncm Handpiece drills can be used.

  • Page 26: Contra-Angle Handpiece 2325 Ln

    3 Product description 26 / 88 3.2.5 Contra-angle handpiece 2325 LN Identification 1 red ring Transmission ratio 1 : 4 Drive air 2.5 to 3.0 bar (29 to 44 psi) Air consumption 50 to 60 Nl/min Speed range 60,000 to 140,000 min Idle torque at 3.0 bar (44 psi) = 0.32 Ncm Handpiece cutters or grinders can be used.
  • Page 27 3 Product description 27 / 88 CAUTION It is hazardous to start up the medical device after it has been stored strongly refrigerated. This can cause the medical device to malfunction. ▶ Prior to start-up, very cold products must be heated to a temperature of 20 C to 25 C (68...
  • Page 28 3 Product description 28 / 88 Air pressure: 700 hPa to 1060 hPa (10 psi to 15 psi) Protect from moisture...

  • Page 29: Start Up And Shut Down

    4 Start up and shut down 29 / 88 4 Start up and shut down WARNING Hazard from non-sterile products. Infection hazard for care provider and patient. ▶ Before first use and after each use, prepare and sterilise the medical device and accessories accordingly.

  • Page 30: Mount The Multiflex (Lux) / Multiflex Led Coupling

    4 Start up and shut down 30 / 88 CAUTION Damage from contaminated and moist cooling air. Contaminated and moist cooling air can cause malfunctions. ▶ Make sure that the supply of cooling air is dry, clean, and uncontami‐ nated according to EN ISO 7494-2. 4.1 Mount the MULTIflex (LUX) / MULTIflex LED coupling ▶...

  • Page 31: Checking The Amount Of Water

    4 Start up and shut down 31 / 88 ▶ Rotate the spray ring on the MULTIflex (LUX) / MULTIflex LED cou‐ pling in order to regulate the fraction of water. 4.2 Checking the amount of water CAUTION Overheating of the tooth due to lack of cooling water. Thermal damage to the dental pulp.
  • Page 32 4 Start up and shut down 32 / 88...

  • Page 33: Checking The Pressures

    4 Start up and shut down 33 / 88 4.3 Checking the pressures CAUTION Compressed air connection on devices. Contaminated and humid compressed air leads to premature wear and tear. ▶ Ensure that the cooling air is dry, clean and uncontaminated in accord‐ ance with EN ISO 7494-2.
  • Page 34 4 Start up and shut down 34 / 88 ▶ Insert the test gauge (Mat. no. 04118731) between the hose and the MULTIflex (LUX) / MULTIflex LED coupling and check the following pressures: ð - Drive air: 2.5 to 3.0 bar (29 to 44 psi), recommended: 3.0 (44 bar psi) ð...

  • Page 35: Checking The O-Rings

    4 Start up and shut down 35 / 88 4.4 Checking the O-rings CAUTION Missing or damaged O-rings. Malfunctions and premature failure. ▶ Make sure that all O-rings are on the coupling and undamaged. Number of available O-rings: 5...

  • Page 36: Operation

    5 Operation 36 / 88 5 Operation 5.1 Attaching the medical device WARNING Release of the medical device during treatment. A medical device that is not properly locked in place can release from the MULTIflex (LUX) / MULTIflex LED coupling during treatment. ▶...
  • Page 37 5 Operation 37 / 88 CAUTION Damage from inaccurate coupling. Inaccurate coupling (especially during the afterglow period) can destroy the high-pressure lamp or the LED of a MULTIflex (LUX) / MULTIflex LED coupling or reduce its service life. ▶ Pull on the medical device to make sure that it is securely affixed to the coupling.

  • Page 38: Removing The Medical Device

    5 Operation 38 / 88 ▶ Pull on the medical device to make sure that it is securely affixed to the coupling. 5.2 Removing the medical device Hold the coupling tight, and pull the medical device off while twisting slight‐...

  • Page 39: Insert Intra Lux Head In Bases 2307 Ln, 2320 Ln Or 2329 Ln

    5 Operation 39 / 88 5.3 Insert INTRA LUX head in bases 2307 LN, 2320 LN or 2329 LN CAUTION Loosening of the medical device during treatment. If the head is not properly locked in place, it can fall out during treatment. ▶...

  • Page 40: Remove Intra Lux Head From Bases 2307 Ln, 2320 Ln Or 2329 Ln

    5 Operation 40 / 88 ▶ Insert the head to the stop. Make sure that the catches are properly seated. ▶ Rotate the clamping ring in the opposite direction (-> close) and tight‐ en it. 5.4 Remove INTRA LUX head from bases 2307 LN, 2320 LN or 2329 LN ▶...

  • Page 41: Insert Handpiece Or Contra-Angle Drill In Handpiece 2313 Ln

    5 Operation 41 / 88 5.5 Insert handpiece or contra-angle drill in handpiece 2313 Note Only use handpiece or contra-angle handpieces that correspond to ISO 1797-1 type 1 and type 2, are made of steel or hard metal and meet the following criteria: - Shaft diameter: 2.334 to 2.35 mm In contra-angle drills with drill bur stop:...
  • Page 42 5 Operation 42 / 88 - Overall length: max. 44.5 mm WARNING Use of impermissible cutters or grinders. Injury to the patient or damage to the medical device. ▶ Observe the instructions for use, and use the cutter or grinder proper‐ ▶...
  • Page 43 5 Operation 43 / 88 CAUTION Injury from using worn drill bits or burs. Drill bits or burs could fall out during treatment and injure the patient. ▶ Never use drill bits or burs with worn shafts. CAUTION Injury hazard from cutters or grinders. Infections or cuts.
  • Page 44 5 Operation 44 / 88 CAUTION Hazard from defective chucking system. The cutter or grinder could fall out and cause injury. ▶ Pull on the cutter or grinder to check that the chucking system is okay and the cutter or grinder is securely held. When checking, inserting and removing, use gloves or a fingerstall to prevent an injury or infec‐...

  • Page 45: Remove Handpiece Or Contra-Angle Drill From Handpiece 2313 Ln

    5 Operation 45 / 88 5.6 Remove handpiece or contra-angle drill from handpiece 2313 LN WARNING Hazard from rotating cutter or grinder. Lacerations and damage to the chucking system. ▶ Do not touch the cutter or grinder when it is rotating! ▶...

  • Page 46: Modification Of The Handpiece 2313 Ln For Contra-Angle Drills

    5 Operation 46 / 88 ▶ Turn the clamping ring back into its initial position. 5.7 Modification of the handpiece 2313 LN for contra-angle drills Note The handpiece must be converted to use contra-angle handpiece drill bits. ▶ Open the handpiece chuck. ▶...

  • Page 47: Insert The Milling Cutters Or Diamond Grinders In Contra-Angle 2325 L

    5 Operation 47 / 88 ▶ To remove the drill bit stop, use the accompanying hook. 5.8 Insert the milling cutters or diamond grinders in contra- angle 2325 L Note Only use dental burs or diamond drill bits that correspond to ISO 1797-1 type 3, are made of steel or hard metal and meet the following criteria: - Shaft diameter: 1.59 to 1.60 mm - Overall length: max.
  • Page 48 5 Operation 48 / 88 CAUTION Use of unauthorised cutters or grinders. Injury to the patient or damage to the medical device. ▶ Observe the instructions for use and use the cutter or grinder properly. ▶ Only use cutters or grinders that do not deviate from the specified da‐ CAUTION Injury from using worn cutters or grinders.
  • Page 49 5 Operation 49 / 88 CAUTION Danger of injury from cutters or grinders. Infections or cuts. ▶ Wear gloves or fingerstalls.
  • Page 50 5 Operation 50 / 88 CAUTION Hazard from defective chucking system. The cutter or grinder could fall out and cause injury. ▶ Pull on the cutter or grinder to check that the chucking system is okay and the cutter or grinder is securely held. When checking, inserting and removing, use gloves or a fingerstall to prevent an injury or infec‐...

  • Page 51: Removing The Cutting Tools Or Diamond Grinder From The Contra-Angle 2325 Ln

    5 Operation 51 / 88 ▶ Check that the cutter or grinder is seated by pulling on it. 5.9 Removing the cutting tools or diamond grinder from the contra-angle 2325 LN WARNING Hazard from rotating cutter or grinder. Lacerations and damage to the chucking system. ▶...
  • Page 52 5 Operation 52 / 88 ▶ After the cutter or grinder has stopped rotating, press the press-but‐ ton with your thumb and simultaneously pull out the drill bit or bur.

  • Page 53: Troubleshooting

    Hazard from improper care of the O-rings. Malfunctions or complete failure of the medical device. ▶ Do not use Vaseline or other grease or oil. Note The O-ring on the coupling may only be lubricated with a cotton ball wet with KAVO spray.

  • Page 54: Cleaning The Spray Nozzle

    6 Troubleshooting 54 / 88 ▶ Press the O-ring between your fingers to form a loop. ▶ Shove the O-ring to the front, and remove it. ▶ Insert new O-rings into the grooves. 6.2 Cleaning the spray nozzle CAUTION Hazard from insufficient amount of spray water. Overheating of the medical device and damage to the tooth.
  • Page 55 6 Troubleshooting 55 / 88 ▶ Clean and free the water passage in the spray nozzles by using the nozzle needle Mat. no. 0.410.0931.

  • Page 56: Reprocessing Methods According To Iso 17664

    7 Reprocessing methods according to ISO 17664 56 / 88 7 Reprocessing methods according to ISO 17664 7.1 Preparations at the site of use WARNING Hazard from nonsterile products. There is a risk of infection from contaminated medical devices. ▶ Take suitable personal protective measures. ▶...

  • Page 57: Cleaning

    7 Reprocessing methods according to ISO 17664 57 / 88 ▶ The medical device must be dry when transported for reprocessing. ▶ Do not place it in solutions or the like. 7.2 Cleaning CAUTION Malfunctions from cleaning in the ultrasonic unit. Defects in the product.

  • Page 58: Automated External Cleaning

    7 Reprocessing methods according to ISO 17664 58 / 88 ▪ Brush, e.g. medium-hard toothbrush ▶ Brush off under flowing tap water. 7.2.2 Automated external cleaning Not applicable. Do not wash the product in thermodisinfectants. 7.2.3 Manual internal cleaning Not applicable. 7.2.4 Automated internal cleaning Not applicable.

  • Page 59: Disinfection

    7 Reprocessing methods according to ISO 17664 59 / 88 7.3 Disinfection WARNING Hazard due to incomplete disinfection. Principally, KaVo recommends carrying out an final disinfection of the un‐ packaged item if complete disinfection cannot be guaranteed without this measure.

  • Page 60: Manual External Disinfection

    Defects in the product. ▶ Disinfect manually only! 7.3.1 Manual external disinfection KaVo recommends the following products based on compatibility of the materials. The microbiological efficacy must be ensured by the disinfec‐ tant manufacturer and proven by an expert opinion.

  • Page 61: Manual Internal Disinfection

    7 Reprocessing methods according to ISO 17664 61 / 88 ▪ FD 322 made by Dürr ▪ CaviCide made by Metrex Consumables required: ▪ Cloths for wiping off the medical device. ▶ Spray the disinfectant on a cloth, then thoroughly wipe down the medical device and leave the disinfectant to soak in according to the instructions from the disinfectant manufacturer.

  • Page 62: Automated External And Internal Disinfection

    7 Reprocessing methods according to ISO 17664 62 / 88 7.3.3 Automated external and internal disinfection Not applicable. Do not wash the product in thermodisinfectants. 7.4 Care products and systems - Servicing WARNING Sharp cutters or grinders in the medical device. Risk of injury from sharp and/or pointed cutters or grinders.
  • Page 63 Reduced product life. ▶ Perform regular proper care and maintenance! Note KaVo only guarantees that its products will function properly when the care products are used that are listed as accessories since they were tes‐ ted for proper use on our products.

  • Page 64: Servicing With Kavo Spray

    7 Reprocessing methods according to ISO 17664 64 / 88 7.4.1 Servicing with KaVo Spray KaVo recommends servicing the product as part of the reprocessing after each use, i.e. after each cleaning, disinfection, and before each sterilisa‐ tion. ▶ Remove drill or grinder and close the clamping rings on handpiece 2313 LN.
  • Page 65 Servicing of the clamping chuck Note Only possible for the INTRAflex contra-angle. KaVo recommends cleaning and servicing the chuck system once a week. ▶ Remove the cutter or grinder, place the spray nipple tip in the open‐ ing and spray.

  • Page 66: Care With Kavo Sprayrotor

    ▶ Remove drill or grinder and close the clamping rings on handpiece 2313 LN. ▶ Place the product on the appropriate coupling of the KaVo SPRAYro‐ tor and cover it with a Cleanpac bag. ▶ Servicing the product. See also:...

  • Page 67: Servicing With Kavo Quattrocare 2104 / 2104A

    7 Reprocessing methods according to ISO 17664 67 / 88 2 Instructions for use KaVo SPRAYrotor 7.4.3 Servicing with KaVo QUATTROcare 2104 / 2104A Note QUATTROcare 2104 / 2104 A is no longer included in the current delivery programme. Follow-up products: ▶...
  • Page 68 68 / 88 (no validated cleaning of the interior in accordance with German RKI re‐ quirements) KaVo recommends servicing the product as part of the reprocessing after each use, i.e. after each cleaning, disinfection, and before each sterilisa‐ tion. ▶ Remove drill or grinder and close the clamping rings on handpiece 2313 LN.
  • Page 69 7 Reprocessing methods according to ISO 17664 69 / 88 Servicing of the clamping chuck Note Only possible for the INTRAflex contra-angle. KaVo recommends cleaning and servicing the chuck system once a week. See also: 2 Instructions for use KaVo QUATTROcare 2104 / 2104A...

  • Page 70: Servicing With Kavo Quattrocare Plus 2124 A

    ▶ Subsequently treat with the specified care products and systems. See also: 2 Servicing with KaVo QUATTROcare 2104 / 2104A 7.4.4 Servicing with KaVo QUATTROcare PLUS 2124 A Servicing and cleaning device with expansion pressure for the interior...
  • Page 71 71 / 88 (no validated cleaning of the interior in accordance with German RKI re‐ quirements) KaVo recommends servicing the product as part of the reprocessing after each use, i.e. after each cleaning, disinfection, and before each sterilisa‐ tion. ▶ Remove the milling tool or grinder, and close the chuck in the case of handpiece 2313 LN.
  • Page 72 Servicing the clamping chuck Note Only possible for the INTRAflex contra-angle. KaVo recommends cleaning and servicing the chuck system once a week using the collet servicing program integrated in the device. See also: 2 Instructions for Use KaVo QUATTROcare PLUS 2124 A...
  • Page 73 7 Reprocessing methods according to ISO 17664 73 / 88 Note Handpieces must be taken off the service couplings before the chuck service can be started and performed. ▶ Remove the service coupling chuck from the side hatch of the QUAT‐ TROcare PLUS and attach it to coupling service point four, on the far right.
  • Page 74 Option 1: Place the dental handpieces in the QUATTROcare PLUS 2124 A, close the front door and start theservice procedure. Option 2: After three minutes with no service procedure running, the de‐ vice automatically switches back to normal service mode. See also: 2 Servicing with KaVo QUATTROcare PLUS...

  • Page 75: Servicing With Kavo Quattrocare 2140 A

    7.4.5 Servicing with KaVo QUATTROcare 2140 A Programme-controlled cleaning and servicing device for perfect servicing of handpieces and turbines. KaVo recommends servicing the product as part of the reprocessing after each use, i.e. after each cleaning, disinfection, and before each sterilisa‐ tion.
  • Page 76 Servicing the chuck Note Only possible for the INTRAflex contra-angle. KaVo recommends cleaning and servicing the chuck system once a week using the collet servicing program integrated in the device. See also: 2 Instructions for use KaVo QUATTROcare CLEAN 2140 A...

  • Page 77: Packaging

    7 Reprocessing methods according to ISO 17664 77 / 88 7.5 Packaging Note The sterilisation bag must be large enough for the handpiece so that the bag is not stretched. The quality and use of the sterilisation packaging must satisfy applicable standards and be suitable for the sterilisation procedure! ▶...

  • Page 78: Sterilisation

    Sterilisation in a steam steriliser (autoclave) in accordance with EN 13060 / ISO 17665-1 CAUTION Premature wear and malfunctions from improper servicing and care. Reduced product life. ▶ Before each sterilisation cycle, service the medical device with KaVo care products.
  • Page 79 Damage to product. ▶ Immediately remove the product from the steam steriliser after the sterilisation cycle! The KaVo medical device has a maximum temperature resistance of up to 138 ℃ (280.4 °F). Select a suitable procedure (depending on the available autoclave) from the following sterilisation processes: ▪...

  • Page 80: Storage

    7 Reprocessing methods according to ISO 17664 80 / 88 ▪ Autoclave using the gravity method: - at least 10 minutes at 134 °C -1 °C / +4 °C (273 °F -1.6 °F / +7.4 °F) ▶ Use according to the manufacturer's Instructions for Use. 7.7 Storage Prepared products must be stored, protected from germs (as far as possi‐...

  • Page 81: Tools And Consumables

    8 Tools and consumables 81 / 88 8 Tools and consumables Available from dental suppliers. Material sum‐ Mat. No. INTRAflex INTRAflex INTRAflex mary LUX reducing LUX hand‐ LUX contra- shanks piece angle hand‐ piece 2307 LN 2313 LN 2325 LN 2320 LN 2329 LN Instrument...
  • Page 82 8 Tools and consumables 82 / 88 Material sum‐ Mat. No. INTRAflex INTRAflex INTRAflex mary LUX reducing LUX hand‐ LUX contra- shanks piece angle hand‐ piece 2307 LN 2313 LN 2325 LN 2320 LN 2329 LN Cellulose pad 0.411.9862 100 units Cleanpac 10 0.411.9691 units...
  • Page 83 LUX contra- shanks piece angle hand‐ piece 2307 LN 2313 LN 2325 LN 2320 LN 2329 LN Drill stop 0.524.0892 Hook 0.410.1633 Material summary Mat. no. KaVo Spray 2112 A 0.411.9640 ROTAspray 2142 A 0.411.7520 QUATTROcare plus Spray 2140 P 1.005.4525...

  • Page 84: Terms And Conditions Of Warranty

    12 months from the date of the invoice, subject to the following condi‐ tions: In case of justified complaints, KaVo will honour its warranty with a free re‐ placement or repair. Other claims of any nature whatsoever, in particular with respect to compensation, are excluded.
  • Page 85 85 / 88 cal or electrical factors deemed abnormal or impermissible in accordance with KaVo's instructions for use or other manufacturer's instructions. The warranty granted does not usually extend to lamps, light conductors made of glass and glass fibres, glassware, rubber parts, and the colourfastness of plastic parts.
  • Page 86 9 Terms and conditions of warranty 86 / 88...
