Humanscale Thin Client Holder Installation Instructions page 2

STEP 1:
Using the included 5mm hex key, loosen the
adjustment screw to pull the two halves apart.
STEP 2:
Insert your thin client into the holder with the front
facing the same side as the Humanscale logo.
Squeeze the two halves of the holder together and
re-tighten the adjustment screw.
STEP 3:
Remove the mounting cleat from
the thin client holder.
STEP 4 (If using Surface Mount):
Using the included screws, attach
the mounting cleat under the desk
in the desired location. Ensure that
there is enough clearance on all
sides for the thin client and holder.
STEP 4 (If using Beam Mount):
Using the two M5 screws, attach the mounting cleat to the beam
bracket.
Then, using the 4 mounting screws, attach the beam bracket under the
desk in the desired location. Ensure that there is enough clearance on
all sides for the thin client and holder.
STEP 5:
Slide the thin client and holder onto the
mounting cleat until it clicks into place.
