- Page 1 Single-axle wheels-in trailer Operating MACHT’S MÖGLICH Instructions Part 2 - HU, HN 1000 Series...
-
Page 2: Notes On Use/Target Group
This specific operating instruction manual (Part 2) for your trailer is on the enclosed CD. You can also download it from www.humbaur.com under the section: Download - Operating Instructions. PART 1 - "Trailers up to 3.5 to" (General Points) For all other general information on car trailers, see the operating instruction manual, "Car Trailers"... -
Page 3: Table Of Contents
Table of Contents Notes on use/Target group Identification Declaration of Conformity Product Description Optional accessories Components Intended Use Foreseeable Misuse General Safety Instructions Loading and Unloading Load distribution Load securing 6.2.1 Projecting goods Load securing with extension and accessories 6.3.1 Wood/aluminium cover 6.3.2 Flat cover 6.3.3 High cover 6.3.4 H-frame... -
Page 4: Identification
► ► P ut a cross next to the type of trailer you have acquired. Humbaur GmbH hereby confirms that all relevant EU directives for the registration and safe use of ► ► trailers of the 1000 series with accessories Please read the general operating instruction have been complied with. -
Page 5: Product Description
Product Description 2.1 HU The HU is equipped with anodised aluminium drop sides. All of the drop sides can be folded down and removed. The locks are recessed in the drop sides. The 15-mm floor plate is made of multiple layers of laminated wood. - Page 6 2.2 HN The HN is equipped with anodised aluminium drop sides. All of the drop sides can be folded down and removed. The locks are recessed in the drop sides. The 18-mm floor plate is made of multiple layers of lami- nated wood.
-
Page 7: Optional Accessories
2.3 Optional accessories HU (Model 1450) HU / HN HU / HN HU / HN 13/7-pin adapter 7/13-pin adapter Loose spare wheel Shock absorbers HU / HN Telescopic prop stands Automatic jockey wheel Cover net H-frame HU / HN HU / HN Steel grid construction Flat cover / side wall extension Side wall extension 700 mm... -
Page 8: Components
2.4 Components 1. Coupling ball 2. Drawbar support 3. V-drawbar 4. Electric plug 5. Safety cable 6. Overrun hitch with handbrake lever, brake linkage, spring mechanism 7. Jockey wheel 8. Front drop side (facing drop side) 9. Front reflector / white reflector or front position lamp 10. -
Page 9: General Safety Instructions
General Safety Instructions Loading and Unloading Single-axle trailers may only be loaded and WARNING unloaded with goods after being coupled to the Driving with folded down / unsecured towing vehicle. drop sides / side wall extensions. 6.1 Load distribution Folded down / unsecured drop sides and side wall extensions may be torn off and flung away while driving - risk of impact / CAUTION crushing! - Page 10 0 km/h ► ► Counteract the potential release of forces by: 100 kg • Correct load distribution • Using adequate means to secure the load in accordance with its weight (tie-down equipment, tie-down points) • Using anti-skid materials (anti-slip mats) •...
-
Page 11: Load Securing
6.2 Load securing ► ► Preferably secure the load as a combination of form-fitting and force-fitting: - Force-fitted by: direct tie-down of the load. - Form-fitted by: supporting the various components of the load against each other, against the drop sides and against the cargo-bed extensions, without spaces in-be- tween. -
Page 12: Projecting Goods
6.2.1 Projecting goods 6.3 Load securing with extension and accessories Goods that project over the cargo bed or drop sides must be marked in accordance with Section Tying down goods 22 of the StVO (German Road Traffic Act). > 1 m Marking goods HU - tie-down points 1. -
Page 13: Wood/Aluminium Cover
6.3.1 Wood/aluminium cover Functional explanation • The wood/aluminium cover is used for the protected transport of sensitive goods. • The wood/aluminium cover can be locked with a key and thus protects your goods against theft. • The loading volume is increased by the internal height of the wood/aluminium cover, i.e. - Page 14 Operating the cover Risk areas CAUTION Wood/aluminium cover with rail Worn gas strut! 1. Cover Where a gas strut is leaking / worn, the cover may 2. Lock fold down on its own and hit / bump you. 3. Handle ►...
-
Page 15: Flat Cover
Closing 6.3.2 Flat cover HN / HU trailers with a flat cover have an addition- al lateral bracing. The lateral bracing supports the centre of the flat cover. Any water / load accumulating on the flat cover may cause it to sag and damage it. ... -
Page 16: High Cover
6.3.3 High cover 6.3.4 H-frame The HN / HU trailers are attached to the stanchions The HN / HU trailers are attached to the front with a hoop frame and high cover and secured to stanchions with an H-frame and secured. the drop sides on all sides. -
Page 17: Loading / Unloading The Trailer
6.4 Loading / unloading the trailer Opening Make sure that the trailer is secured so that it cannot roll away. ► ► Make sure that road traffic safety is not impaired when loading and unloading the trailer. ► ► If necessary, use additional signalling devices, e.g. - Page 18 Mount side wall extensions Drop sides folded down / stanchions removed 1. Stanchions, removed 2. Lateral drop side, folded down 3. Rear drop side, folded down ► ► The drop sides can be folded down, depending on the loading / unloading process. ►...
- Page 19 Remove the main drop sides Mounting Mount / secure the main drop side ► ► Slide the drop side onto its hinges in a horizontal position. ► ► Push the securing split pin into one of the hinges and open the securing split pin slightly. Remove the main drop side ►...
-
Page 20: Driving
6.4.2 Telescopic prop stands Driving HN / HU trailers can be optionally equipped with swivelling telescopic prop stands. Before driving off, make sure that the maximum The supports may only be retrofitted at the permissible loads (load capacity and drawbar load) attachment points provided. -
Page 21: Cleaning/Maintenance/Servicing
9.2.2 Gas strut Cleaning/Maintenance/Servicing 9.1 Care/Cleaning WARNING Remove gas struts! Observe the safety instructions and instructions for The gas struts are subject to high pressure! general cleaning/care of trailers in the operating Improper fitting / removal may result in injury to persons instruction manual, "Car Trailers"... -
Page 22: Troubleshooting
Troubleshooting Decommissioning/Disposal For causes of faults and rectification measures, Observe the safety instructions for decommission- see the operating instruction manual, "Car ing / disposal of trailers in the operating instruction Trailers" (General Points - Part 1). manual, "Car Trailers" (General Points - Part 1). 11.1 Decommissioning the trailer ►... - Page 23 HU, HN Operating Instruction Manual (Part 2) Version 2019/01...
- Page 24 MACHT’S MÖGLICH No liability is accepted for errors or printing errors. All illustrations are representative. Deviations and modifications are subject to the model type. Subject to technical modifications. Copying prohibited. Printed in Germany. Version 2019/01...
