Power Up Procedures - Mircom UDACT-100A Installation And Operation Manual

1. Unplug Fire Alarm Panel.
2. Connect cable from P2 on the UDACT-100A board to the Fire Alarm Panel. Check the Fire Alarm manual for
the UDACT-100A cable location.
3. Hook up the CFG-100 Configuration Tool to P4 on the UDACT-100A.
4. Hook up the telephone lines and telephone as shown on page 4.
For test purposes only you may tie the output of telephone line 1 into the input of telephone line 2.
5. Power up the Fire alarm and the message of the CFG-100 Configuration Tool should be:
Digital Communicator
[UDACT(1) is idle. . .] for FA-1000 or
[UDACT(2) is idle. . .] for FX-2000
Press any key to start login procedure . . .
6. Press any key to start the login procedure. The CFG-100 display will show the following screen:
Enter Passcode now
Passcode: _ _ _ _ _ _ _ _
Press <#> when done
or <*> to cancel.
7. Enter the passcode, 2222222 for installer.
Enter 2-digit ITEM
number to configure.
To scroll down list of items, press <#> or <*> to scroll up . . .
8. When you try to enter a 2-digit number, the following screen will appear,
Please enter ITEM #
ITEM Number: _ _
Press <#> when done
or <*> to cancel.
9. Set the DATE by entering 20, the following screens will appear,
Enter Date (dd/mm/yy)
Day of Month: _ _
Press <#> when done
or <*> to cancel.
10. Set the TIME by entering 21(Item number), the following screens will appear,
Enter Time (HH/MM/SS)
Seconds (00-59): _ _
Press <#> when done
or <*> to cancel.

POWER UP PROCEDURES

Enter Date (dd/mm/yy)
Month of Year: _ _
Press <#> when done
or <*> to cancel.
Enter Time (HH/MM/SS)
Minutes (00-59): _ _
Press <#> when done
or <*> to cancel.
Page 5
Enter Date (dd/mm/yy)
Year of Century: _ _
Press <#> when done
or <*> to cancel.
Time (HH/MM/SS)
Hours (00-23): _ _
Press <#> when done
or <*> to cancel.
