Mircom UDACT-100A Installation And Operation Manual page 11

ITEM Access Menu Category
Number Level
30 II Account (#1)
31 II Account (#1)
32 II Account (#1)
33 II Account (#1)
40 II Account (#2)
41 II Account (#2)
42 II Account (#2)
43 II Account (#2)
50 II Report Priority
51 II Report Priority
52 II Report Priority
53 II Event Logging
54 II Event Logging
55 II Report Priority
60 II Phone Line (1/2)
61 II Phone Line (1/2)
62 II Configuration
63 II Phone Line(1&2)
64 ll Phone Line 2
NOTE: All configurable items have default values assigned by the "Restore-to-Default" operation. All items must have a (non-zero)
value assigned unless specifically identified as OPTIONAL within the table(s) above.
Menu Label Description
Account ID #1 Assign 4-6 numeric Account ID to be identified with Account #1
monitoring station receiver.
Dial-Prefix #1 (OPTIONAL) Set up-to-8-digits to be first dialed by UDACT when
attempting to call Account #1 monitoring station receiver.
Local Number #1 Set up-to-8-digits to be dialed (after Dial-Prefix #1 digits) by UDACT
when attempting to call Account #1 monitoring station receiver.
Report Format #1 Choose report format (Contact ID or SIA) to be generated by
Default Contact ID UDACT when reporting with Account #1 monitoring station receiver.
Account ID #2 Assign 4-6 numeric Account ID to be identified with Account #1
monitoring station receiver
Dial-Prefix #2 (OPTIONAL) Set up-to-8-digits to be first dialed by UDACT when
attempting to call Account #2 monitoring station receiver.
Local Number #2 Set up-to-8-digits to be dialed (after Dial-Prefix #2 digits) by UDACT
when attempting to call Account #2 monitoring station receiver.
Report Format #2 Choose report format (Contact ID or SIA) to be generated by
Default Contact ID UDACT when reporting with Account #2 monitoring station receiver.
<ALARM> Events Choose which Account # (1 or 2) will be the first to be attempted to
be reached by the UDACT, when an ALARM event is to be
Default is Account 1 reported. This is designated as the "primary" account and the other
will become the "secondary". If the UDACT cannot report to the
primary, it will then attempt to report to the secondary. This cycle will
normally continue until the event is eventually sent or the
<MAXIMUM Attempts> has been achieved.
<TROUBLE> Events Choose which Account # (1 or 2) will be the first to be attempted to
Default is Account 1 be reached by the UDACT, when a TROUBLE event is to be
reported. (See ITEM 50 for a description of the UDACT report-
attempt operation).
<SUPVSRY> Events Choose which Account # (1 or 2) will be the first to be attempted to
Default is Account 1 be reached by the UDACT, when a SUPERVISORY event is to be
reported. (See ITEM 50 for a description of the UDACT report-
attempt operation).
Ignore <SUPVSRY> This selection allows the overriding of the "normal' reporting of the
Events supervisory events when set to 1. The UDACT will report
Default is Non- supervisory events when set to 2.
Addressable Panel
Fire Alarm Protocol Select FA for CONVENTIONAL Fire Alarm or FX for
Selection ADDRESSABLE Fire Alarm.
Note: for panel FX-2000 user, please check the software version
number on the FX-2000 panel. If the software version number starts
with 2, choose 16 bit checksum, otherwise, choose 8 bit checksum.
Max. Attempts Set the "normal" upper limit for UDACT attempts (call-attempt pairs)
to report to monitoring station receivers. One attempt is registered
Range is 5 to 10, when the UDACT tries to access both (i.e. the pair of) "primary" and
Default is 6 Attempts "secondary" Accounts #'s. (See ITEM 50 for a description of the
UDACT report-attempt operation). After this count has been exceed,
the UDACT will assert the TROUBLE-SEND signal (and BUZZER)
to the connected Fire-Panel. Only a UDACT power reset will remove
this condition.
Dial-type Line 1 Configure Line 1 for DTMF (Tone) or Rotary (Pulse) dialling.
Dial-type Line 2 Configure Line 2 for DTMF (Tone) or Rotary (Pulse) dialling.
Reboot UDACT Reset entire UDACT (configuration is not affected).
Deaf Dialling To wait and listen for dial tone select 1 (default) or Ignore Dial Tone
Default dial tone(1) for use with "Cellular Telephone" select 2
Set Testing Date This command applies only when the 2nd line is a cellular
Default testing date for Phone Line 2 is the 1 day of the month.
Selection can be made from 1 to 28 day of the month.
Whenever Line 2 is used for a cellular phone, then the Deaf Dialling
should be set to 2 (Item 63 set to Ignore Dial Tone).
Page 9
phone.
st
st th
