Product 521889

521889 Active holder with cig-plug With cig-plug adapter. With tilt swivel. For charging, no data transmission.

The active holder charges your battery when it is in the holder. The charging device connects to the d62

automatically when you put the device in the holder.

The holder is equipped with a tilt swivel so you can easily adjust the angle for better viewing, or switch between

portrait and landscape mode. Tilts 20° and swivels 360°. Mounting plate 42x50 mm with predrilled AMPS-holes

+2x3,5 mm centered holes. Made of high grade black ABS/Acetal plastic. Made in Sweden. Attach onto ProClip

Mounting Platform.

Dimensions: 58 x 90 x 53 mm (W x H x D mm)

Weight: 144 g

Cable length (+ connector with plug 9,7 cm): 148,5 cm

This product supports Qualcomm QC 2.0 quick charge (provided the device supports Qualcomm QC 2.0 quick

charge).

EAN: 7320285218895

Item no 521889 fits:

Ascom d62 (For all countries)

Page 1 15 February, 2020, www.brodit.com, © 2020 Brodit AB Product 521889 521889 Active holder with cig-plug With cig-plug adapter. With tilt swivel. For charging, no data transmission. The active holder charges your battery when it is in the holder. The charging device connects to the d62 automatically when you put the device in the holder.
Page 2 INSTALLATION INSTRUCTIONS Please read all of the instructions and look at the pictures before attaching the holder. 1. Loosen the screw in the center of the holder so you can remove the tilt swivel attaching plate on the back. 2. Place the attaching plate onto the desired position. Screw the attaching plate into place with the enclosed screws.
