- Page 1 Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di istruzioni...
- Page 2 Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.
-
Page 3: Table Of Contents
Table of Contents Transmitter Setup Table ........4 Troubleshooting Guide ........11 Installing the Flight Battery ........6 Exploded View........... 13 Transmitter and Receiver Binding ......6 Replacement Parts ..........14 Control Tests ............7 Recommended Parts ......... 14 Understanding the Primary Flight Controls .... 8 Optional Parts ........... -
Page 4: Transmitter Setup Table
Transmitter Setup Table A setup fi le for the Spektrum DXe transmitter is available for download at www.spektrumrc.com. DX6i SETUP LIST ADJUST LIST Model Type HELI TRAVEL ADJ D/R & Expo Swash Type 1 servo 90 Channel Travel Chan Sw Pos Expo THRO 100/100... - Page 5 DX6, DX6e FUNCTION LIST SYSTEM SETUP Servo Setup Model Type HELI Chan Travel Reverse Chan Travel Reverse Swash Type Normal 100/100 Normal 100/100 Normal 100/100 Normal 100/100 Normal F-Mode Setup 100/100 Normal 100/100 Normal Switch 1 Switch B Throttle Cut -130%1 Throttle Curve D/R &...
-
Page 6: Installing The Flight Battery
NOTICE: The throttle will not arm if the transmitter’s throttle control is not put at the lowest position and the stunt mode switch is not in the 0 position. If you encounter problems, refer to the troubleshooting guide for other instructions. If needed, contact the appropriate Horizon Hobby Product Support offi ce. -
Page 7: Control Tests
Control Tests Ensure the throttle hold is ON when doing the direction control tests. Test the controls prior to the fi rst fl ight to ensure the servos, linkages and parts operate correctly. If the controls do not react as shown in the illustrations below, confi rm the transmitter is programmed correctly. -
Page 8: Understanding The Primary Flight Controls
Understanding the Primary Flight Controls If you are not familiar with the controls of your mCP X BL, take a few minutes to familiarize yourself with them before attempting your fi rst fl ight. Throttle Left Side View Left Side View Descend Climb Throttle up... -
Page 9: Flight Modes
Flight Modes With the transmitter programmed as shown in the 3D Mode (switch position 2 ) Red LED Transmitter Setup Table section, the fl ight mode 3D Mode is intended for pilots with experience with switch gives the pilot the choice between the collective pitch helicopters. -
Page 10: First Flight Preparation
First Flight Preparation Flying Checklist • Remove and inspect contents • Always turn the transmitter on fi rst • Begin charging the fl ight battery • Plug the fl ight battery into the lead from the ESC • Program your computer transmitter •... -
Page 11: Drift Calibration
The red and blue instructions. LEDs fl ash rapidly to indicate the calibration To calibrate the Blade mCP X BL 2: process has begun. Hold the hover for approximately 15 seconds, using as little control 1. - Page 12 Problem Possible Cause Solution Power off transmitter, move transmitter a Transmitter is too near aircraft larger distance from aircraft, disconnect during binding process and reconnect fl ight battery to aircraft and follow binding instructions LED on receiver fl ashes rapidly and aircraft will Bind switch or button was not not bind to transmitter held while transmitter was...
-
Page 13: Exploded View
Exploded View... -
Page 14: Replacement Parts
SERVICE OR REPLACEMENT the Product, (iv) attempted service by anyone other AS PROVIDED UNDER THIS WARRANTY IS THE than a Horizon Hobby authorized service center, (v) PURCHASER’S SOLE AND EXCLUSIVE REMEDY. Product not purchased from an authorized Horizon... - Page 15 asserted. As Horizon has no control over use, setup, and phone number where you can be reached during fi nal assembly, modifi cation or misuse, no liability shall business hours. When sending product into Horizon, be assumed nor accepted for any resulting damage or please include your RMA number, a list of the included injury.
-
Page 16: Warranty And Service Contact Information
Sales 800-338-4639 Hanskampring 9 Horizon Technischer Service service@horizonhobby.eu D 22885 Barsbüttel, Sales: Horizon Hobby GmbH +49 (0) 4121 2655 100 Germany FCC Information Contains FCC ID: BRWWACO1T NOTE: This equipment has been tested and found to comply with the limits for a Class B digital This device complies with part 15 of the FCC rules. -
Page 17: Ic Information
Compliance Information for the European Union EU Compliance Statement: Horizon Hobby, LLC hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the RED and EMC Directives. - Page 18 Blade, the Blade logo, SAFE, the SAFE logo, BNF, the BNF logo, DSM, DSM2, DSMX, ModelMatch, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
