NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury.
Safety Precautions and Warnings • Always keep a safe distance in all directions around your model to avoid collisions or injury. This model is controlled by a radio signal subject to interference from many sources outside your control. Interference can cause momentary loss of control. •...
First Flight Preparation • Remove and inspect contents • Begin charging the fl ight battery • Install the batteries in the transmitter (RTF only) • Program your computer transmitter (BNF only) • Install the fl ight battery in the helicopter (once it has been fully charged) •...
Charge the Flight Battery NOTICE: Inspect the battery to make sure it is not damaged e.g., swollen, bent, broken or punctured. Only charge batteries that are cool to the touch and are not damaged. Insert the charger into a USB port. SOLID RED LED –Charging Connect the battery to the charger.
9, the mSR S will bind to the DXe, but will not respond to control inputs. If your DXe was included in another Blade Ready To Fly (RTF) helicopter, the transmitter software will have to be updated using the appropriate programming cable and either the PC or mobile app available at www.spektrumrc.com.
Page 9
Once bound, the LED in the helicopter should glow blue for fl ight modes 0 and 1 (Stability, Low-Angle and High-Angle Modes), and glow red for fl ight mode 2 (Agility mode). If the LED glows blue in all three fl ight modes, channel 6 has not been reversed correctly. Use the directions above to reverse channel 6.
Page 10
DX7s SYSTEM SETUP Model Type SW Select Trainer Aux 1 Acro Flap Gear All Others FUNCTION LIST Servo Setup Chan Travel Reverse Chan Travel Reverse 100/100 Normal 100/100 Normal 100/100 Normal 100/100 Reverse 100/100 Normal 100/100 Normal 100/100 Normal D/R & Expo D/R &...
Page 11
SYSTEM SETUP Model Type SW Select Trainer Aux 1 Acro F Mode Gear All Others FUNCTION LIST Servo Setup Chan Travel Reverse Chan Travel Reverse 100/100 Normal 100/100 Normal 100/100 Normal 100/100 Reverse 100/100 Normal 100/100 Normal 100/100 Normal D/R & Expo D/R &...
Page 12
DX6, DX6e, DX7 (Gen 2), DX8 (Gen 2), DX9, DX18, DX20 SYSTEM SETUP Model Type Channel Assign Acro Channel Input 1 Throttle F-Mode Setup 2 Aileron Switch 1 Switch B 3 Elevator Switch 2 Inhibit 4 Rudder 5 Gear 6 AUX 1 FUNCTION LIST Servo Setup Chan...
Installing the Flight Battery 1. Lower the throttle stick to the lowest position (A) and center all trims. 2. Set the Flight Mode Switch to Stability Mode (FM0) 3. Power ON the transmitter (B). 4. Slide the fl ight battery fully into the mount of the helicopter frame (C). 5.
Transmitter and Receiver Binding Your RTF transmitter comes prebound to the model. If you need to re-bind, follow the directions below. MLP4DSM Binding Procedure (RTF) 1. Disconnect the fl ight battery from the helicopter. 2. Center all trims on your transmitter. 3.
RTF Transmitter Controls Flight Mode Bind / Panic Mode LED indicator On/Off Switch Mode Aileron (Left/Right) Throttle Aileron Rudder Elevator Rudder (Left/Right) Throttle (Up/Down) Trim Trim Trim Trim Elevator (Up/Down) Mode Aileron (Left/Right) Elevator Aileron Rudder Throttle Rudder (Left/Right) Elevator (Up/Down) Trim Trim Trim...
Control Tests Test the controls prior to the fi rst fl ight to ensure the servos, linkages and parts operate correctly. Ensure the throttle is in the low position when doing the control tests. Elevator (Forward and Backward Cyclic) Left Side View Forward Cyclic Backward Cyclic Aileron (Left and Right Cyclic)
Page 17
Descend Throttle down Rudder (Yaw) Top View Nose Yaws Left Rudder left Nose Yaws Right Rudder right Elevator (Forward and Backward Cyclic) Left Side View Forward Cyclic Forward Backward Cyclic Backward...
Aileron (Left and Right Cyclic) Rear View Left Left Cyclic Right Right Cyclic Flying the mSR S Consult your local laws and ordinances before choosing a location to fl y your aircraft. We recommend fl ying your aircraft outside in calm winds (3 MPH or less) or inside a large gymnasium.
If the model is free of damage, follow the calibration procedure below. Fully charge the fl ight battery before beginning the calibration procedure. To Calibrate the Blade mSR S: 1. Power on the transmitter. 2. Power on the helicopter.
Replace damaged parts before fl ying. Verify both main rotor blades Rotors have the correct and equal tension in the blade grips. When the helicopter is held up sideways, the main blades should support their own weight. When the helicopter is shaken lightly, the blades should fall.
Page 21
Damaged rotor blades, Check main rotor blades, blade grips, spindle, blade grips, main gear and main shaft for cracks, main gear teeth or chips or missing teeth. Replace damaged Helicopter vibrates cracked main shaft.
Page 22
Problem Possible Cause Solution Verify the receiver is properly attached Model does not to the helicopter. Verify that no wires are hold level/Panic contacting the receiver. Inspect and bal- recovery does not ance all rotating components. Verify the Vibration level. Random main shaft and tail rotor adapter are not movements in damaged or bent.
Damping Plate 3 BLH2408 Damper 4 BLH2901 Blade FBL 3-in-1 Unit 5 BLH2902 Blade Complete Canopy with Vertical Fin 6 BLH2903 Blade Main Frame with Hardware 7 BLH2904 Blade Tailboom assembly without motor 8 BLH2905 Blade Coreless Main Motor with Pinion...
12 BLH3209 Complete Precision Swashplate 13 BLH3212 Main Rotor Hub w/Hardware 14 BLH3213 Spindle and Dampers 15 BLH3214 Main Blade Grip Set w/Hardware 16 BLH3215 Rotor Head Linkages(4) 17 BLH3216 Main Rotor Blades w/hardware 18 BLH3217 Tail Rotor 19 BLH3506...
Page 25
AND FITNESS FOR A PARTICULAR PURPOSE. THE PURCHASER ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY MEET THE REQUIREMENTS OF THE PURCHASER’S INTENDED USE. Purchaser’s Remedy Horizon’s sole obligation and purchaser’s sole and exclusive remedy shall be that Horizon will, at its option, either (i) service, or (ii) replace, any Product determined by Horizon to be defective.
Warranty Requirements For Warranty consideration, you must include your original sales receipt verifying the proof-of-purchase date. Provided warranty conditions have been met, your Product will be serviced or replaced free of charge. Service or replacement decisions are at the sole discretion of Horizon.
FCC Information FCC ID: BRWDXMTX10 and BRWBLH2401 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Compliance Information for the European Union EU Compliance Statement: RTF: BNF: Horizon Hobby, LLC hereby declares that Horizon Hobby, LLC hereby declares that this product is in compliance with the this product is in compliance with the essential requirements and other relevant essential requirements and other relevant provisions of the R&TTE, RED, and EMC provisions of the RED and EMC Directives.
