Summary of Contents for Horizon Hobby BLADE 330 X
- Page 1 ® Instruction Manual Bedienungsanleitung ® Manuel d’utilisation Manuale di Istruzioni...
-
Page 2: Safety Precautions And Warnings
This product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. -
Page 3: Table Of Contents
® ® Box Contents: • Blade 330X • 3S 11.1V 2200mAh 30C Li-Po Battery (RTF Only) • DC Li-Po Balancing Charger (RTF Only) • Spektrum DXe Transmitter (RTF Only) • 4 AA Batteries (RTF Only) Table of Contents Safety Precautions and Warnings .................2 Pre-Flight Checklist ....................9 Table of Contents ....................3 Pre-Flight Checklist ....................10... -
Page 4: First Flight Preparation
First Flight Preparation Flying Checklist ❏ • Remove and inspect contents Always turn the transmitter on fi rst ❏ • Begin charging the fl ight battery Plug the fl ight battery into the lead from the ESC ❏ • Install the fl ight battery in the helicopter (once it has been fully charged) Allow the ESC to initialize and arm properly ❏... -
Page 5: Dxe Transmitter Control (Rtf)
Installing the DXe Transmitter Batteries (RTF) The LED indicator fl ashes and the transmitter beeps progressively faster as the battery volt- age drops. Replace the transmitter batteries when the transmitter begins to beep. DXe Transmitter Control (RTF) Fli ght Mode Switch Bind 0 = Normal Mode Throttle Hold... - Page 6 DX7s, DX8 SYSTEM SETUP FUNCTION LIST Model Type HELI Servo Setup Timer Chan Travel Reverse Chan Travel Reverse Swash Type 1 servo 90 Mode Count Down 100/100 Normal 100/100 Normal Time 4:00 Tone F-Mode Setup 100/100 Normal 100/100 Normal Start Throttle Out Flight Mode F Mode...
-
Page 7: Installing The Flight Battery
Installing the Flight Battery 1. Lower the throttle. 7. Do not move the helicopter until the receiver initializes. The swashplate will center, indicating that the unit is ready. The receiver will also emit a solid 2. Power on the transmitter. orange Status LED when it is ready. -
Page 8: Control Tests
Control Tests CAUTION: You must complete the Tail Rotor and Cyclic tests prior to every fl ight. Failure to complete the tests and ensuring the sensor corrects in the proper direction can cause the helicopter to crash, resulting in property damage and injury. Tail Rotor 4. -
Page 9: Understanding The Primary Flight Controls
Electronic Speed Controller Governor Operation The Blade 330 X Electronic Speed Controller (ESC) utilizes a head speed gover- The default throttle curve settings listed in the transmitter setup tables should be nor to maintain a constant head speed during fl... -
Page 10: Pre-Flight Checklist
Flying WARNING: Do not use wooden main blades with the Blade 330 X or in- jury and/or property damage could occur. Only use Blade 330 X replace- The helicopter lifts off the ground when the rotor head reaches a suitable speed. -
Page 11: Post-Flight Inspections And Maintenance
Post-Flight Inspections and Maintenance Make sure the plastic ball link holds the control ball, but is not tight (binding) on the ball. When a link is too loose on the ball, it can separate Ball Links from the ball during fl ight and cause a crash. Replace worn ball links before they fail. Make sure the battery is not connected before cleaning. - Page 12 Entering Gain Adjustment Mode DX7s / DX7 G2 / DX8 / DX8 G2 / DX9 / DX18 / DX20 Users: 1. Lower the throttle stick to the lowest position. DX6G2, DX6e and DX6i Users: 1. Lower the throttle stick to the lowest position. 2.
-
Page 13: Servo Adjustment
Servo Adjustment Your Blade 330 X was setup at the factory and test fl own. The servo adjustment 7. Release the sticks and proceed to Adjusting the Servo Neutral Position to make steps are usually only necessary in special circumstances, such as after a crash or any desired changes. -
Page 14: Troubleshooting Guide
What this Warranty Covers Limitation of Liability Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL (the “Product”) will be free from defects in materials and workmanship at the date of DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY WAY, purchase. -
Page 15: Warranty And Service Contact Information
Compliance Information for the European Union EU Compliance Statement: Horizon Hobby, LLC hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the RED and EMC Directives. A copy of the EU Declaration of Conformity is available online at: http://www.horizonhobby.com/content/support-render-compliance. - Page 16 Dieses Produkt eignet sich nicht für die Verwendung durch Kinder ohne direkte Überwachung eines Erwachsenen. Versuchen Sie nicht ohne Genehmigung durch Horizon Hobby, LLC, das Produkt zu zerlegen, es mit inkompatiblen Komponenten zu verwenden oder auf jegliche Weise zu erweitern. Diese Bedienungsanleitung enthält Anweisungen für Sicherheit, Betrieb und Wartung.
-
Page 17: Exploded View
Exploded View / Explosionszeichnung / Vue Éclatée / Vista Esplosa... -
Page 19: Parts List
Parts List / Ersatzteile / Pièces de Rechange / Pezzi di Ricambio Part # English Deutsch Français Italiano Blade 450/300x/300CFX: Hauptzahn- B450/300X/300CFX - Couronne principale Ingran. principale elicoidale 1 BLH1901 Helical Main Gear B450/300X/CFX rad schrägverz. hélicoïdale B450/300X/CFX Blade 450/300x/300CFX: Ritzel 10 Z B450/300X/300CFX - Pignon hélicoïdal 2 BLH1902 Helical Pinion 10T B450/300X/CFX... - Page 20 Part # English Deutsch Français Italiano Aluminum Motor Mount Set: B450 Aluminium-Motorbefestigungs-Set: Set de fi xations moteur en aluminium : Set montante del motore in allumino: B450 37 BLH1643 3D/X, B400 B450 3D/X, B400 B450 3D/X, B400 3D/X, B400 Sangles crochet et boucle pour ruban Hook &...
-
Page 21: Optional Parts
Optional Parts / Optionale Bauteile / Pièces Optionnelles / Pezzi Opzionali Part # English Deutsch Français Italiano Blade 450/300x/300CFX: B450/300X/300CFX - Pignon hélicoïdal 11T Pignone elicoidale 11T BLH1903 Helical Pinion 11T B450/300X/CFX Ritzel 11 Z schrägverz. B450/300X/CFX Blade 450/300x/300CFX: Pignone elicoidale 12T BLH1904 Helical Pinion 12T B450/300X/CFX B450/300X/300CFX - Pignon hélicoïdal 12T... - Page 22 Part # English Deutsch Français Italiano Tail Rotor Blade Set, Yellow: B450 3D/X, Heckrotorblatt-Set, gelb: B450 3D/X, Set de pales d'anticouple, Jaune : B450 3D/X, Set pale del rotore di coda, giallo: BLH1671YE B400 B400 B400 B450 3D/X, B400 Tail Rotor Blade Set, Green: B450 3D/X, Heckrotorblatt-Set, grün: B450 3D/X, Set de pales d'anticouple, Vert : B450 3D/X, Set pale del rotore di coda, verde:...
- Page 23 ©2017 Horizon Hobby, LLC. Blade, DSM, DSM2, DSMX, Celectra, ModelMatch, Spektrum AirWare and EC3 are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. Futaba is a registered trademark of Futaba Denshi Kogyo Kabushiki Kaisha Corporation of Japan US 7,391,320.
